Introduction

Intended Audience

This documentation is for merchants and developers who want to implement the lynck payment system. Help us improve this guide by contacting us and pointing out errors, misspellings or unclear sections at service@lynck.de.

Getting started

Lynck offers an interface for web-shops to integrate with a variety of payment options by performing just a single integration with the lynck system. Integration with lynck spans into the various shop processes and systems from web-shop to warehouse to accounting.

The lynck interface is suitable for both immediate fulfilment – for example, for transactions involving electronic services or goods that are delivered immediately after the checkout took place – or delayed fulfilment – transactions involving goods ́ delivery (order delivery) to users after a time, possible days from checkout.

So lynck allows the shop to focus on the best shopping experience for its users without having to deal with the hassle of providing a variety of payment options and multiple integrations. The implementation of the multitude of payment options can be realized with just one integration. During checkout, lynck’s payment system is optimized to select the most convenient payment options for the shop’s customer and at the same time satisfy the shop’s needs for secure payments.

Integration options

The lynck platform offers great flexibility for the integration into the web shop's checkout process. In general, there are two types of integration for two versions each. This allows E-commerce merchants with any sales volume to choose the ideal integration type for their requirements.

Identifier	Type	Description	Benefit
API	API	The lynck System is integrated as pure backend API solution without using a Hosted Page or any frontend elements. To transfer credit card data the merchant has to be PCI compliant.	Full design control, seamless page tracking
SecureFields	API with using secure fields	The lynck system is integrated as an API solution using the lynck Secure Fields to transfer credit card data in the shop frontend.	Full design control, seamless page tracking, drastically reduced PCI requirements
HostedPageBefore	PRE-integrated Hosted Page	The Hosted Page, which shows all payment methods/instruments is integrated before the confirmation page of the merchant's shop is shown. The hosted page allows the user the select a payment method and enter payment instruments like credit card and bank account.	Less effort required for frontend integration, drastically reduced PCI requirements
HostedPageAfter	POST-integrated Hosted Page	The Hosted Page, which shows all payment methods/instruments is integrated after the confirmation page of the merchant's shop is shown. The hosted page allows the user the select a payment method and enter payment instruments like credit card and bank account.	Less effort required for frontend integration, drastically reduced PCI requirements
HostedPageAfter	Pay By Link via API	The lynck System creates a payment link which redirects the customer to a hosted payment page to complete the payment.	No integration into the shop front-end required, drastically reduced PCI requirements

API integration

When using complete/self-sufficient API integration, the E-commerce merchant has maximum flexibility when designing and integrating the payment page, but in return he has to fulfil the high security requirements imposed by e.g. PCI-compliance guidelines issued by credit card companies. This integration type is therefore more suited to large companies which want to retain full design and process control.

API integration with secure fields

The API integration with secure fields corresponds to the aforementioned version, however, with the difference that the secure fields library is made available to the E-commerce merchant via the lynck platform. This solution is used to handover credit card and bank details in a secured environment outside of the shop sovereignty and avoids that the E-commerce merchant has to independently fulfil the PCI-compliance guidelines issued by the credit card companies. This integration type therefore tends to be more suited for large companies which want to retain full design and process control yet avoid more strict PCI-requirements.

Integration as Hosted Page (Before / After)

Lynck delivers a complete payment page with the easy and above all fast "Hosted Pages" integration type. It is a complete payment page for all payment types for the E-commerce merchant's shop and ensures that no safety relevant data is stored on the retailer's website. Therefore, the E-commerce merchant automatically fulfils the applicable high safety standards e.g. PCI-compliance imposed by credit card companies.

The standard Hosted Page design is responsive, i.e. depending on the end customer’s terminal (e.g. PC, smartphone or tablet) the payment page is optimised for the terminal's display. A special feature is the easy customization of the Hosted Page: It can be configured independently by the E-commerce merchant which allows them to retain in parts control over the page design. Changes can be checked with the preview function and set "live" with one click. In addition to the visual design of the payment page, the E-commerce merchant can also make content changes. This allows shops to provide individual, multi-lingual texts for every payment method (e.g. as explanatory note or to promote individual payment methods) and to save individual fees or discounts per payment type. This also enables the retailers to have significantly more control with regard to directing the end customer to certain payment methods.

The E-commerce merchant can also specify the point at which the payment page should be shown during the entire checkout process. There is a choice of "before" or "after" purchase confirmation, referred to as the pre-integration (3) or post integration version (4). Therefore, the Hosted Page can be ideally integrated into the checkout process according to the needs and preference of the E-commerce merchant.

Pay By Link integration

Pay By Link via API allows the creation of payment links directly from the merchant's system. These links can be used/delivered in any way to allow customers to pay in an fast and easy fashion. Optionally the lynck system can be instructed to automatically send these payment links in an email to the customer, which further reduces the implementation effort. The payment link redirects the customer to a payment page which is based on the 'Hosted Page After'. Pay By Link transactions require a minimal amount of parameters to be initiated compared to other integration options. Should solvency checks be performed for payment methods such as bill payment and direct debit, the necessary data for the check will be collected on the payment page directly from the customer. This integration type is not meant to be used in a shop checkout, but as an alternative way to collect payments independent of any shop. Possible use cases include, but are not limited to, mail and telephone orders, or offering alternative payment methods on the bill for a customer.

Process description

To understand the lynck system some terms and correlations need to be explained. The following graphic illustrates the relation between transactions and captures

Transactions

If a user initiates the payment process within the checkout process, the merchant’s shop system performs a createTransaction call in the lynck system and transfers all relevant data. A transaction can be referred later on by the shop system (or an ERP system) with the unique identifier orderID. This could be the reference number of the order or an invoice number or anything else, but is has to be unique for the shop. After receiving all necessary data, the lynck system creates a transaction with the status New. The transaction will then pass through different states which are represented by the transaction status.

Status	Description
New	Internal status. Means that a transaction has been created within the lynck system after receiving the user and basket data from the shop system during checkout.
AcknowledgePending	Internal status. The user has confirmed the purchase during checkout by pressing button "Buy" and in case of redirect payment methods lynck is waiting for the response from the shop which contains the success-URL.
FraudPending	This status indicates, that the transaction is suspect due to fraud suspicions and needs to be reviewed manually.
CIAPending	The transaction was created successfully and lynck is waiting for funds to arrive or become available. Relevant for payment methods: AMAZON_PAY, PAYPAL, PREPAID, ZINIA_BNPL, ZINIA_INSTALLMENT
MerchantPending	The transaction was successful. Lynck is waiting for the merchant to capture the transaction when delivering the order or immediately after the checkout process.
InProgress	The transaction was captured successfully. The transaction will remain in this status until all captures are in status paid.
Expired	The transaction was not completed by the user within the duration of the basket-validity.
Cancelled	The transaction was cancelled by the merchant.
FraudCancelled	The transaction was cancelled due to fraud. This can occur if they were in status FraudPending and then declined by the merchant or lynck, or if the merchant reported the user as fraudulent in the MSA or using the reportFraudUser API.
Done	The transaction has been completed. A transaction will change into this status if all of its captures have the status paid.

The transaction status can be affected by the user, the system, the fraud team, the shop or the capture status.

The transaction status remains as New until a reservation is made. This usually happens when the customer clicks the "Buy" button on the web-shop. After confirmation of the purchase the transaction status changes to AcknowledgePending.

The resultCode of a reservation is 0 in case of a successful reservation, but it can also equal 1 regarding of the payment method. This signals that the user needs to be redirected to a payment page of a third party payment supplier (e.g. PayPal). The URL to which they should be redirected is provided by lynck in the response to the reserve call.

After the reservation has been confirmed, the status of the transaction is set to MerchantPending in case the funds are ready to be captured or CIAPending in case the funds are still pending. After the funds have become available the transaction status changes to MerchantPending.

If the shop/ERP system cancels the transaction via cancel call, the status of the transaction is set to Cancelled. If any funds were received before a capture was performed, the lynck system will automatically initiate a refund.

Captures

All transactions with status MerchantPending wait to be captured by the shop/ERP system. A capture can be referred later on by the shop/ERP system by passing the unique identifier captureID via capture call. So whereas the creation of a transaction is triggered by the user during checkout process, the creation of an capture is initiated by the shop/ERP system.

Status	Description
PayPending	The capture or partial capture is waiting to be paid.
Paid	The capture or partial capture was paid successfully. Alternatively the open amount could have been reduced to 0 using a refund on bill and direct debit transactions.
PaymentFailed	This status indicates that the payment failed.
Cleared	The capture or partial capture was booked successfully and cleared.
Chargeback	A chargeback was reported on the capture.
InDunning	This status can only occur if the dunning and collection service has been enabled at lynck. Customer is in the dunning process.
InCollection	This status can only occur if the dunning and collection service has been enabled at lynck. Customer is in the collection process.

The point of time when a capture should be done, depends on the business model:

• shops that want to charge the user with delivery perform the capture as soon as they have delivered or trigger the delivery(more user convenient)
• shops that want to charge the user immediately after ordering - either if they deliver their goods afterwards or because they sell digital goods - will perform the capture directly after a successful transaction creation

Lynck also supports the ability to perform more than one capture e.g for the case of partial delivery.

After a successful capture the status of a transaction is set to

• Done as soon as lynck received funds from the user for the capture so that the capture has the status Paid. In case of several captures the transaction status will be set to Done as soon as all captures are in status Paid
• InProgress when lynck waits for incoming funds (e.g. invoice or direct debit) so that the capture has the status PayPending

The transaction status is therefore dependent on the action of the shop/ERP system up to a certain point in time. As soon as the shop/ERP system creates one or more captures for a transaction, the transaction status will be directly affected by the status of those captures.

Example: If a capture was created for a transaction and the capture was marked as Paid, the transaction status is Done as the capture status is Paid. If a chargeback is reported by the bank or credit card company, the capture status changes from Paid to Chargeback and therefore the transaction status changes back from Done to InProgress. It is possible for the transaction status to move in either direction.

If the merchant does not want to capture the full amount, e.g. because some goods can not be delivered, the finish call should be used to close the transaction. This will refund the overpaid/uncaptured amount to the user in case the transaction was paid in advance, but keep all captured funds.

User

Users will automatically be created at lynck when createTransaction is called with a new userID. Alternatively registerUser can be used to create users without starting a transaction each time. The userID is the unique identifier of a user for a specific store. If a returning user for a store is identified by lynck using the userID, any payment instruments stored for this customer will be displayed when using the hosted pages integration type. This allows returning customers to re-use cards/bank accounts without the need to re-enter all data. Due to the sensitive nature of this data the merchant has to make sure that no userID can be shared between users.

Hosted Pages description

Types of Hosted Payment integration

There are two ways to integrate Hosted Pages. The payment page can be shown before or after the shops order confirmation page. Which option fits better depends on the used web-shop or module.

Hosted Pages Before

1. With the API call createTransaction the shop passes all relevant data to lynck
2. The lynck system returns a URL, which refers to the hosted payment selection page. The shop displays the hosted payment selection page to the user and lynck performs the first risk check before displaying the selectable payment methods
3. The user selects a payment method on the payment selection page, and enters the payment instrument data if necessary
4. In case of an error the lynck system shows the error message on the payment selection page
5. The lynck system redirects the customer to the confirmation URL configured for this shop and informs the shop about the selected payment method. See: callback
6. The shop calculates the final order amount and displays the purchase confirmation page to the user. After the user confirmed the purchase, the merchant reserves the final order amount with the reserve call
7. In case of an error the lynck system returns a new URL in its response with the proper error message and the shop redirects the user back to the updated payment method selection page
8. In case of a positive outcome for the risk check the processing of the payment can start

Hosted Pages After

1. With the API call createTransaction the shop passes all relevant data to lynck
2. In case of an error the lynck system shows the error message on the payment selection page
3. The lynck system returns a URL, which refers to the hosted payment selection page. The shop displays the hosted payment selection page to the user and lynck performs the first risk check before displaying the selectable payment methods
4. The user selects a payment method on the payment selection page. Lynck now validates the data and performs the second risk check
5. In case of an error the lynck system shows the error message on the payment selection page
6. In case of a decline due to a failed second risk check the lynck system shows an error message on the payment selection page
7. In case of a positive outcome for the risk check lynck automatically reserves the full transaction amount. The merchant does not need to perform the reserve call themself

Supported Payment Methods

Name	General notes
Amazon Pay	Amazon Pay is an express checkout option by which the customer may directly pay for a specific product or basket by clicking on an Amazon Pay express button, and does not require the prior creation of a lynck transaction. The user is then redirected to Amazon Pay where they can select their preferred payment method and delivery address, which is communicated to the shop afterwards. The user is then redirected back to the shop where they can confirm their purchase. This payment method is not to be used as a regular checkout payment method, but for express checkouts only. For more details see the Amazon Pay section of the documentation.
Bill	After checkout, the shop has to generate a invoice including the account information and payment reference provided by lynck. The account information and the payment reference are provided in the response to the reserve. Alternatively they can be retrieved by the shop from lynck using the getTransactionStatus call.
Cash in Advance	After checkout, the shop can only deliver the order after payment has been received from the user. Incoming payments are reported to the shop by the Merchant Notification Service.
Cash on Delivery	After checkout, the user makes payment only once he has received the product. This payment is not made via lynck checkout. So lynck cannot process any payment here. As a result, the merchant will have to process ‘Cash on Delivery’ payments separately.
Credit Card	After checkout, the reservation or authorization is processed immediately. The shop receives the outcome of the payment as result of the reserve call
Credit Card with 3D-Secure	If a credit card holder is registered with the 3D Secure process via one of the registration methods, then once the purchase is confirmed, the customer is forwarded to an entry page of their bank where they can enter their password. Payment is carried out only after the correct password is entered. The password is only known to the customer and their bank. For MasterCard this solution is called “MasterCard Secure Code”, for Visa “Verified by Visa”.
Direct Debit	Direct Debit has to be processed by the bank system once it has been transferred to the bank gateway. This can take several days. The order status is PayPending during this period. As a result of the reconciliation process the bank system provides feedback which will be considered automatically within the lynck system: in case of a positive feedback, the status of the order will be set to Paid; in case of a negative return it gets status PaymentFailed. Sometimes lynck does not receive any feedback from the bank. For this rare case the lynck system waits until a so called grace period has been passed. If the lynck system has not received a negative feedback within this grace period the status of the order will be set to Paid. The lynck system sets a grace period, since the bank system only provides feedback if the direct debit is rejected. The order status changes to Paid once the lynck system has not received negative feedback from the bank system after this grace period.
iDEAL	After confirmation, the user is forwarded during checkout to a page on which they may select their bank. This takes them to the entry page of their bank where they have to authenticate themselves with their access data. They then triggers an online bank transfer from this environment. iDEAL will inform lynck about the outcome, after which lynck performs a callback and redirects the user back to the shop.
PayPal	During checkout, the user will be required to login into their PayPal account to authenticate the payment. Depending on the version of the PayPal gateway this authentication happens in a pop-up window within the shop, or by redirecting the customer to PayPal after order confirmation. On purchase confirmation lynck redirects the user to PayPal to login using his credentials. After a successful authentication or cancellation using the redirect method, PayPal informs lynck about the outcome, lynck performs a callback and redirects the user back to the shop. In addition it is possible to offer PayPal as an express checkout option. For more details see the PayPal Express section of the documentation.
Sofort (Online Remittance)	After confirmation, the user is forwarded during checkout to the SOFORTBank website where they can select their bank. This takes them to the entry page of their bank where they have to authenticate themselves with their access data. They then triggers an online bank transfer from this environment. Similar to iDEAL, SofortÜberweisung will inform lynck about the outcome, after which lynck performs a callback and redirects the user back to the shop.
Other Payment methods	From time to time lynck may add payment methods. Consult your lynck representative.

Risk Management

The integrated risk management platform uses a combination of machine learning, sector specific data and fully adjustable criteria in order to decide in real time whether transactions are accepted or rejected, if the end customer only gets offered secure payment methods or if the transaction has to be checked manually. Buyers shopping with online retailers can pay for their goods, services and digital contents using a range of payment methods such as credit cards, PayPal, direct debit, prepayment etc. The payment methods vary in cost and risk (with regards to non-payment risk) for the online retailer on the one hand and with regard to popularity with the customers on the other. If a preferred payment method is missing, then it may lead to an increased rate of purchase cancellations and reduce the so-called retailer conversion rate.

The risk management integrated in the lynck platform controls the payment types for E-commerce retailers actively and dynamically during checkout based on different check algorithms and criteria based on select parameters.

Dynamic control is carried out based on a two-step risk assessment. In advance, it is coordinated with the merchant which payment methods should be available in general and which of those are offered for certain risk assessments.

As seen in the graphic above, the process starts with the merchant initiating a createTransaction request when the customer enters the payment section of the checkout. Using this request the merchant can already decide how to treat the customer based on his own experience. This allows the merchant to:

• Offer all payment methods to VIP customers or business partners without any risk checks taking place. (Trusted customer - low risk)
• Offer only secure payment method to customers known to cause issues or who are suspicious. (Suspicious customer - high risk
• Let lynck decide whether the customer should be treated as high risk customer based on configured risk settings and provided data. (Unknown customer - medium risk)

Furthermore, the merchant is able to provide risk classes for basket items as well. Similar to the first level risk assessment done by lynck, these will only apply if the transaction risk class is medium. See the following table on how the combination of customer and basket items risk class affect the transaction risk class:

Extended Risk Classes

Instead of only providing the main three risk classes low(0), medium(1) and high(2), it is also possible to provide user risk classes with a decimal point from 0-2. This way merchants gain access to a more finely grained risk management of customers in the checkout process based on their past experiences with them.

By default all risk and solvency checks are performed in the risk class range from 0.1 - 1.9. Specifically for limit, velocity, open debt rules and all solvency checks it is possible to define risk class thresholds, which define at which risk class a rule or check becomes active. This means that multiple rules or checks with different thresholds can be configured, whereas the rule/check with the highest threshold that is reached will be applied.

The extended risk classes allow: * Application of different limit, velocity and open debt rules depending on the customer risk class * More control over the offered payment methods for each risk class * Usage of different solvency check products depending on the risk class * Different solvency check result interpretation depending on the risk class

Dunning and collection

Every German and Austrian shop has the option to use the professional dunning and collection service of our partner Accredis.

All orders will automatically be passed to Accredis for processing

• if the due date is reached in case of unpaid bill transactions
• if a direct debit payment bounced.

All orders, which have been passed to Accredis, go into status inDunning. Also the user/debtor gets this status.

If a user is in status inDunning, they are (per default configuration) unable to pay with insecure payment methods like direct debit or bill until they have paid the outstanding amount.

If the dunning process was successful or the Accredis file gets closed, the lynck system is notified about it.

In this case the status of the order will be set to paid even if the debt claim was not fully paid. A file can be closed if the user was not able to pay or just paid a partial amount of the debt claim.

If the dunning process finished without the file being closed as mentioned above the collection process starts. Accredis notifies lynck about the start of the collection process, which triggers the order and the user status to change to inCollection. Similar to inDunning customers with status inCollection will not be able to use insecure payment methods. The order will only switch to paid if the file is closed manually, or an incoming payment is registered.

All orders with status paid will be passed to the clearing, so that the shop gets all payments which have been collected during dunning/collection.

To effectively use this service Accredis at least requires the invoice number of the order created by the merchant. The invoice number can either be passed to lynck and therefore Accredis by providing it in the field captureID when performing a capture, or alternatively it can be passed after capturing by using the updateInvoice.

Implementation Details

General Rules

Data Types

Following data types are used in this documentation:

Type	Description	Comments	Sample
AN (length)	Alpha-Numeric	Sequence of characters (UTF-8 encoded) with maximum length	Test
N (length)	Numeric	Sequence of numbers with maximum length	12356
V	Fixed Value	The possible values can be found in the comments	CC
J (type)	JSON-Object	JSON object of a special type	{ 'id': 'xyz' }
JA (type)	JSON-Array	Array of JSON objects of a special type	['abc', 'xyz']
B	Boolean value	true or false	true
D (format)	DATE	Date with a specified Format like YYYY-MM-DD	2020-02-22

Security and signing of requests

In order to ensure the security of the calls made to the lynck interface, there are certain rules that have to be followed.

• All calls have to be made via HTTPS.
• All parameters shall be passed via POST requests
  • The requests should be sent with Content-Type "application/x-www-form-urlencoded" if not described otherwise in the API
  • The responses will have Content-Type: "application/json"

In order to prevent any tampering with the parameters of the request, all calls have to be signed with what is known as a Message Authentication Code (MAC).

The MAC has to be calculated by the caller and passed along as a further parameter in the request. The algorithm used for this is HMAC (RFC 2104). The HMAC algorithm needs to be a shared secret between parties in order to validate the authenticity of the message. All responses from lynck contain a MAC in the response header which can be used for validation.

Status codes

Successful responses have HTTP status 200 (OK). If there is a problem with the content of the request the http status is 400 (Bad Request). In case of validation errors there is a http status 401 (Unauthorized) returned. Possible causes are:

• wrong or missing merchantID
• wrong or missing storeID
• wrong or missing MAC
• request to a non existing endpoint

Merchant credentials

• The merchant ID you will receive when getting access to our sandbox or production environment acts as a container for shops/stores, meaning a merchant ID may be related to multiple store IDs. Your private key is only valid for this merchant ID and all stores below it.
• Each store ID is bound to exactly one currency. Usually the ID contains the ISO 4217 currency code that it is bound to. For example: teststoreEUR. This means if a single store front-end supports multiple currencies it will require multiple store IDs. For each currency the calls will have to be made with their respective store ID.
• Each store ID is bound to exactly one confirmation, success and failure URL respectively. These URLS are the targets for callbacks which are performed synchronous to the payment process. For more information see: Callback documentation
• Each store ID can be assigned multiple notification-URLs. This URL is the target for transaction status updates. For more information see: Notification documentation
• Risk settings such as velocity rules, blacklists and solvency checks can be configured for each store ID.

MAC calculation

The Message Authentication Code (MAC) is used to ensure data integrity and therefore includes the request parameters with further calculations performed.

The MAC is included in both the request and response.

Request

In requests the MAC is sent as POST parameter

Response

HTTP/1.1 200 OK
Content-Type: application/json;charset=UTF-8
X-Payco-HMAC: 289740cfda1c7f1df1c2ce9562930350e6bcb0a6
Transfer-Encoding: chunked

In the response the mac is part of the HTTP header as X-Payco-HMAC

There are cases where the lynck system can not generate a MAC. For example if the merchantID is missing in the request and the merchant can not be identified. In this case there will be no MAC in the header. This will only happen for error-messages (resultcode 101). Responses for successful calls will always include a MAC

Calculation

The MAC should be computed as follows:

Generate an HMAC-SHA1 key using the merchant's private key. The key can be computed once and stored if the private key is unchanged.

Request

Create the datastring. Build a string containing the calls parameter values alphabetically ordered (a - z). To order the parameters the key is used and not the value. The parameter "mac" is the only one that is not included in the calculation.

• The included strings' parameter values should be identical to the ones sent in the request or received in the response
• If a parameter value is sent as empty, or the parameter is not set at all, then related parameter value for MAC calculation can be an empty string ('') or simply not included at all.
• The datastring should not include any spaces or non-printable control characters ( \n, \r, \t, \f, \v space ), which can easily be found with the regular expression meta character '\s'. Remove all the non-printable characters from the datastring.

Compute the MAC using the HMAC-SHA1 calculation together with the private key on the datastring.

Response

In the response the whole body is the datastring as it contains all the payload, but the process is exactly the same as outlined in the previous paragraph. Keep in mind to remove the parameter 'mac' from the response before calculating and verifying its MAC.

To validate notifications sent from lynck to the merchant, the process is basically the same as described above.

Example

<?php
function getMac($request) {
    global $privateKey;

    // Sort parameters alphabetically by key for MAC calculation
    ksort($request);

    // Create a string from the parameter values for MAC calculation
    $macstring = implode("", $request);

    // Calculate MAC
    return (hash_hmac('sha1', str_replace(array(" ","\t","\s","\r","\n",' '), "", $macstring), $privateKey));
}
?>

import javax.crypto.Mac;
import javax.crypto.spec.SecretKeySpec;

public class MACCalculator {

  public String calculateMAC(String input, String secret) {
    // generate MAC Secret Key (Step a)
    Mac mac = null;

    try {
      SecretKeySpec signingKey = new SecretKeySpec(secret.getBytes(), "HmacSHA1");
      mac = Mac.getInstance("HmacSHA1");
      mac.init(signingKey);
    } catch (Exception e) {  /* handle exception*/}
    return hmac(input, mac);
  }

  // method that applies mac key to the parameters string
  private String hmac(String input, Mac mac) {
    input = input.replaceAll("\\s", "");

    final byte[] hmac = mac.doFinal(input.getBytes());

    final StringBuilder hex = new StringBuilder(2 * hmac.length);

    for (final byte b : hmac) {
      // b & 0xff converts e.g. 0xffffff81 to 0x81
      String hexString = Integer.toHexString(b & 0xff);

      if (hexString.length() < 2) {
        hex.append("0");
      }
      hex.append(hexString);
    }
    return hex.toString();
  }

  public String calculateAndGetMAC(MultiValueMap<String, String> map, final String merchantPassword) {
    StringBuilder macInput = new StringBuilder();
    SortedSet<String> keys = new TreeSet<>(map.keySet());
    for (String key : keys) {
      String value = map.toSingleValueMap().get(key);
      macInput.append(value);
    }
    return calculateMAC(macInput.toString(), merchantPassword);
  }

  /*
  * Main method only includes a simulation to a MAC Calculator client
  */
  public static void main(String[] args) {
    String merchantPassword = "8A!v#6qPc3?+G1on";

    // The input variable below should include the call parameters in alphabetic order
    String input = "123testOrdertestStore";

    MACCalculator macCalculator = new MACCalculator();
    System.out.println((macCalculator.calculateMAC(input, merchantPassword)));
  }
}

To verify if the MAC calculation is implemented properly, please find following sample strings and the respective correctly calculated MAC value:

Assume merchant private key value here is: 8A!v#6qPc3?+G1on

The request is a cancel call with following parameters:

key	value
merchantID	123
storeID	test Store
orderID	testTransaction

Ordered alphabetically:

key	value
merchantID	123
orderID	testTransaction
storeID	test Store

Remove special delimiters:

key	value
merchantID	123
orderID	testTransaction
storeID	testStore

The concatenated parameter string is:

123testTransactiontestStore

The resulting calculated MAC should be:

7aea4cc6313b2814053488079563375bf1544663

API Throttling

To prevent abuse of the API and ensure stability there are restrictions in place which limit the rate of requests per timeframe that can be performed to the lynck system.

Any given API endpoint has an assigned request pool which represents the amount of requests which can be made before the API rejects any further requests. This request pool refills with a set rate and therefore allows for a short burst of multiple requests at once, but limits the overall requests that can be made over longer periods of time.

The size of the request pool and the refill rate may depend on the specific API endpoint and the system which is called. Request pools and the refill rate are independent for each individual API endpoint. For example, even if the limit for the getTransactionStatus API is reached, the createTransaction API would remain unaffected.

Callback

Callbacks are redirects of the customer back to the shop performed by the lynck system to the URLs configured for the merchants shop. For each shop one confirmation, success and failure URL can be defined.

The following GET parameters can be added to the URLs:

Field	Type	Mandatory	Comments
-MERCHANTID-	N 16	yes	This is the merchant ID assigned by lynck.
-STOREID-	AN 60	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
-ORDERID-	AN 30	yes	This is a unique identifier for a transaction which is created by the shop.
-MERCHANTREF-	AN	no	Reference, that additionally can be set by the shop. This parameter is sent back with every call from lynck to the shop
-PAYMENTMETHOD-	V	yes	The identifier of the payment method. See PaymentMethods
-LOCALE-	V	yes	The locale determines the user’s communication language e.g. for e-mails which will be send to the user or for payment pages. See Languages
-PI-	AN 20	no	The unique ID of the payment instrument. This ID is created by lynck.
-MAC-	AN 20	no	Message Authentication Code. See: MAC calculation

Confirmation

After a customer selected his payment method on the hosted page he will be redirected to the confirmation URL. This allows the merchant to display the selected payment method on his order confirmation page and change the final order amount accordingly if required.

Example of a confirmation URL: https://www.example.com/testshop/confirm?merchantID=-MERCHANTID-&storeID=-STOREID-&orderID=-ORDERID-&paymentMethod=-PAYMENTMETHOD-&paymentInstrumentID=-PI-&mac=-MAC-

Successfull payment

For all payment methods which redirect the user to a different web-page the lynck system redirects the customer to the success URL of the shop, in case of a successful payment. For integration type HostedPageAfter this redirection will take place for all payment methods. The available GET parameters for the success URL are identical to those of the confirmation URL.

Example of a success URL: https://www.example.com/testshop/success?merchantID=-MERCHANTID-&storeID=-STOREID-&orderID=-ORDERID-&paymentReference=-PAYMENTREFERENCE-&merchantReference=-MERCHANTREF-&mac=-MAC-

Failed payment

If a customer fails to complete the payment process after they were already redirected to an external payment provider, they will be redirected to the failure URL configured for the shop. This also happens if a negative response or any other error code is returned by the external payment provider. Additionally to the GET parameters available to the success and confirmation URLs, the failure URL receives a link to the hosted payment page as possible parameter, and the resultCode. This allows the shop to redirect the customer back to the hosted payment page after they cancelled the payment process or failed to authorize the payment.

Field	Type	Mandatory	Comments
-PIURL-	V	yes	URL of the hosted payment page
-RESULTCODE-	N	yes	Used to identify the failure reason. See errorcodes
-EXTERNALCODE-	AN	no	Will return the rejection/error code of the credit card acquirer, if provided. Only relevant for CC and CC3D
-EXTERNALMESSAGE-	AN	no	Will return the rejection/error message of the credit card acquirer, if provided. Only relevant for CC and CC3D
-RECOVERABLE-	V	no	Provides information on whether the reservation may be re-attempted. Options: yes no unknown

Example of a failure URL: https://www.example.com/testshop/failure?merchantID=-MERCHANTID-&storeID=-STOREID-&orderID=-ORDERID-&merchantReference=-MERCHANTREF-&piUrl=-PIRUL-&resultCode=-RESULTCODE-&mac=-MAC-

Notification Call

The Merchant Notification System (MNS) is a push notification service for merchants who have integrated one of the payment systems. The MNS allows the merchant to receive a multitude of notifications asynchronously in order to decouple the merchant system from lynck’s payment systems. Integrating the merchant notification system allows the merchant to react to any kind of change in the status of transactions that were processed.

The MNS can provide two types of notifications: status notifications and payment notifications. Details for each type of request are listed below.

The status notification calls will be directed at the Status Notification Target URL that is configured for the shop, while payment notification calls will target the Payment Notification Target URL. Multiple notification-URLs may be configured for a single shop. This allows merchants to inform more than one system, for example shop system and ERP system. It is possible to configure different Status Notification Target URL/s for individual shops, in case the merchant uses multiple shops in the lynck system. By contrast, the Payment Notification Target URL/s must always be identical in all shops. If this URL is modified in one shop, the configuration is automatically applied for all other shops of the merchant. This is done because bank accounts are configured on a merchant-level and multiple shops of a merchant may use the same bank account.

If required it is also possible to configure Status Notification Target URL/s so that they only receive notifications for transactions with a certain context. This enables merchants to allow one system to receive notifications about their online checkouts, while another system could process notifications about their subscriptions.

Status Notification Request

Status notifications are sent by the lynck system whenever the status of a transaction, capture or subscription in the lynck system changes, and they include general related information, such as the transaction/capture/subscription status, transaction balance, the amount ready to be captured, or payment and merchant references. Additionally status notifications are triggered, when an incoming payment is registered, which might not necessarily trigger a transaction or capture status change. For example when an incoming payment does not fully cover the open amount of a capture, then a new capture status notification is triggered which contains the amount of the incoming payment, even though the status of the capture itself did not change. Or if an overpayment is registered for a transaction that is already considered to be paid, a new transaction status notification is triggered, as the incoming payment cannot be associated to a capture. In these cases only the fields amount and transactionBalance will be updated. Due to these incoming partial payments or overpayments, it may be possible to receive multiple notifications with the captureStatus=PAYPENDING or transactionStatus=DONE in a row.

The merchant has four options on which notifications to receive:

• All status changes (exluding INPROGRESS)(Default)
• All status changes (including INPROGRESS)
• Status changes from status PAID or to status PAID
• Changes to status PAID

Field	Type	Mandatory	Comments
merchantID	N 16	yes	This is the merchant ID assigned by lynck.
storeID	AN 60	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN 50	yes	This is a unique identifier for a transaction which is created by the shop.
subscriptionID	AN 50	no	This is a unique identifier for a subscription which is created by the shop. This value is only set for subscription status updates, or if a transaction/capture status update relate to a subscription. Named "subscriptionId" for notifications with version < 2.5.
captureID	AN 50	no	The confirmation ID of the capture. This parameter is only sent for notifications that belong to captures.
merchantReference	AN 30	no	Optional/additional reference for the transaction or subscription. This parameter is returned with every call from lynck to the shop.
paymentReference	AN	no	The reference text to which the user needs to refer within his remittance so that lynck can link the incoming payments with the outstanding amounts of a transaction.
userID	AN 50	yes	The unique user id of the user.
amount	N 16	yes	The amount field is set to a positive value when an incoming payment or a chargeback was matched to a transaction and/or capture, otherwise it is set to 0. What this value represents depends on the context of the notification: transactionStatus = MERCHANTPENDING The field amount is set to the amount of an incoming payment that was matched to the transaction, and is ready to be captured transactionStatus = DONE The field amount is set to the amount of the incoming overpayment that was matched to the transaction captureStatus = PAYPENDING/PAID/INDUNNING/IN_COLLECTION The field amount is set to the current paidAmount of the associated capture captureStatus = CHARGEBACK The field amount is set to the total capture amount plus the chargeback fee
currency	AN 3	no	3 characters, Currency code according to ISO4217. This value matches the currency of the original transaction and is provided when the field "amount" is greater than 0.
transactionStatus	V	no	Current status of the transaction. Possible values: NEW ACKNOWLEDGEPENDING FRAUDPENDING FRAUDCANCELLED CIAPENDING MERCHANTPENDING CANCELLED EXPIRED INPROGRESS DONE
captureStatus	V	no	Current status of the capture. Named "orderStatus" for notifications with version < 2.4. Possible values: PAYPENDING PAID CLEARED PAYMENTFAILED CHARGEBACK DUNNING_PENDING INDUNNING IN_COLLECTION
subscriptionStatus	V	no	Current status of the subscription. Only available with version >= 2.5. Possible values: USER_PENDING START_PENDING PAUSED CANCELLED ACTIVE DONE
transactionBalance	N	No	The sum of all received payments minus the sum of all captured amounts plus all reductions. This value is negative when still waiting for payments, positive in case a transaction was overpaid, and zero when the debt is paid exactly or no capture was performed yet.
additionalData	J	no	Possible keys: accredisStatusCode
timestamp	N	yes	The time when the status change happened in milliseconds since 1970-01-01 (Unix timestamp in milliseconds)
version	AN	yes	Notification version
mac	AN 40	yes	Message Authentication Code see MAC calculation

Payment Notification Request

Payment notifications are specific to bank based payment methods and serve to inform the merchant if payments or refunds, which were registered in their bank account, were processed. The different types of payment notifications are specified below. These notifications contain detailed information about the bank statement related to a payment. They can be used if the merchant wants to keep track of all incoming/outgoing payments and whether they were successfully matched to lynck transactions.

The use of payment notifications is completely optional and has no impact on the checkout or payment process.

Field	Type	Mandatory	Comments
merchantID	N 16	yes	This is the merchant ID assigned by lynck.
storeID	AN 60	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN 50	no	This is a unique identifier for a transaction which is created by the shop. This value is only set if the payment was associated to a lynck transaction.
subscriptionID	AN 50	no	This is a unique identifier for a subscription which is created by the shop. This value is only set, if the payment was associated to a lynck subscription.
merchantReference	AN 30	no	Optional/additional reference for the transaction, as provided by the merchant.
paymentReference	AN	no	The reference text to which the user needs to refer within his remittance so that lynck can link the incoming payments with the outstanding amounts of a transaction. This value is only set if the payment was associated to a lynck transaction.
notificationType	AN	yes	Describes in which context this notification was triggered. For a description of each option, see the table below. Possible values: FAILED IGNORED MATCHED REFUNDED SENTTOACCREDIS MATCHEDBYACCREDIS ACCREDISFEE
gvc	N 3	yes	Transaction code from the bank statement (Geschäftsvorfall-Code) which describes the type of payment.
gvcText	AN	no	Transaction description from the bank statement which describes the type of payment.
accountNo	AN	yes	IBAN from/to which the payment is sent.
sortCode	AN	yes	Bank identifier/SWIFT code
owner	AN	yes	Name of the account holder.
usage	AN	no	Customer reference as provided by the customer in case of incoming payments. Set by lynck in case of refunds.
merchantIBAN	AN	yes	The bank account for which the payment notification was sent.
statementNumber	AN	yes	Sequential number of the associated bank statement.
debitCreditMarker	AN	yes	Indicates whether it is a debit or credit payment. Possible values: C (credit) and D (debit)
valueDate	AN	yes	Value date of the payment in milliseconds since 1970-01-01 (Unix timestamp in milliseconds)
bookingDate	N	yes	Booking date in milliseconds since 1970-01-01 (Unix timestamp in milliseconds)
currency	AN 3	yes	3 characters, Currency code according to ISO4217. Currency of the payment.
amount	N 16	yes	Balance of the payment.
timestamp	N	yes	The time when the payment notification was triggered in milliseconds since 1970-01-01 (Unix timestamp in milliseconds)
version	AN	yes	Notification version
mac	AN 40	yes	Message Authentication Code see MAC calculation

Notification types

Type	Description
FAILED	The automatic payment matching failed and the payment could therefore not be associated to a lynck transaction.
IGNORED	The payment was automatically or manually ignored and is therefore not associated to a lynck transaction.
MATCHED	The payment was matched to a lynck transaction.
REFUNDED	The payment was manually refunded before it was associated to a lynck transaction.
SENTTOACCREDIS	The payment was associated to a lynck transaction for which a dunning or collection process is active. The dunning provider was informed about the payment.
MATCHEDBYACCREDIS	The dunning provider processed a payment for which they were previously notified and matched the payment to a lynck transaction.
ACCREDISFEE	Notification about dunning or collection fees raised by the dunning provider.

Response

Every notification request should be answered by the merchant's system with an HTTP response of status 200. The content is not relevant and will be ignored. If there's no such response from the merchant, the merchant notification system uses a retry mechanism in order to ensure the delivery of notifications to the merchant. The merchant notification system will try to deliver the notifications:

• every 5 minutes for 3 consecutive times and
• every hour for 5 consecutive times

In cases where the notification fails to be delivered successfully after the above tries, the Notification Service will stop any further notifications. The merchant can reactivate the MNS-Service in the 'Merchant Service Area': https://service.lynck.de in the section Settings -> Notification System -> System Notifications, selecting the locked target and then clicking the 'Reactivate' button. Also the last error message or reason why the notifications stopped is listed there.

Payment Methods

Payment Method Overview

Column	Description
Identifier	Payment method identifier as used in API calls
Name	Name of the payment method in the checkout process
Redirect	Specifies whether the customer is required to be redirected to a third party page on transaction reservation
Country	Specifies in which countries a merchants shop must operate to offer the payment method
Currency	Specifies which currencies are supported by the payment method
Secure	Specifies whether the payment methods is inherently considered to be secure by lynck. This may be adapted using risk configuration
Recurring	Specifies whether the payment method can be offered in lynck subscriptions or recurring payments
Integration Type	Specifies which integration types support the payment method

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
AMAZON_PAY	Amazon Pay	yes	US, GB, AT, BE, CY, DK, FR, DE, HU, IE, IT, JP, LU, NL, PT, ES, SE, CH	Amazon Pay supported currencies	yes	yes	all, Express - See Amazon Pay
APPLE_PAY	Apple Pay	variable	Apple Pay supported countries	variable	yes	yes	API, SecureFields
BILL	Bill payment	no	all	all	no	no	all
BILL_SECURE	Bill secure / Billie	no	DE	EUR	yes	no	SecureFields, HostedPageAfter, HostedPageBefore
CC	Credit card	no	variable	variable	no	yes	all
CC3D	Credit card 3D-Secure	variable	variable	variable	yes	yes	all
COD	Cash on delivery	no	all	all	yes	no	all
DD	Direct debit	no	all	all	no	yes	all
DUMMY	Dummy	no	all	all	yes	no	all
EPS	eps	yes	all	EUR	yes	no	all
GIROPAY	giropay	yes	all	EUR	yes	no	all
GOOGLE_PAY	Google Pay™	variable	variable	variable	yes	yes	all
IDEAL	iDEAL	yes	all	EUR	yes	yes	all
PAYPAL	PayPal	variable	PayPal supported countries	PayPal supported currencies	yes	yes	SecureFields, HostedPageAfter, HostedPageBefore, Express - See PayPal Express
PREPAID	Cash in advance	no	all	all	yes	no	all
SU	Sofort	yes	all	EUR	yes	no	all
ZINIA_BNPL	Zinia Buy Now Pay Later	yes	DE	EUR	yes	no	all
ZINIA_INSTALLMENT	Zinia Splitpay	yes	DE	EUR	yes	no	all

Amazon Pay

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
AMAZON_PAY	Amazon Pay	yes	US, GB, AT, BE, CY, DK, FR, DE, HU, IE, IT, JP, LU, NL, PT, ES, SE, CH	Amazon Pay supported currencies	yes	yes	all, Express - See Amazon Pay

Description

Amazon Pay should mainly be offered to customers as a pure express payment method. This means that the customer may skip the regular payment process by clicking on an Amazon Pay button to almost immediately complete a purchase. Using this process the customer data, including the delivery address, is delivered by Amazon Pay to lynck and the merchant, so that the customer does not have to register manually in the store.

As an alternative, it is also possible to provide the customer data and delivery address upfront, and to use Amazon Pay like a conventional payment method, where the user is redirected to the Amazon Pay payment page at the end of the checkout. This checkout flow should be used for recurring payments and Pay By Link, where the express checkout is not an option. Amazon Pay specifies that the express checkout should be the main integration to complete orders using Amazon Pay.

Requirements

To offer Amazon Pay as a payment method, an Amazon Pay business account is required. Within the business account, lynck needs to be registered as a developer, so that they are able to create and manage payments in the name of the merchant. Additionally, lynck requires the seller ID, client ID and the MWS auth token of the Amazon Pay business account for configuration.

Integration specifics

Amazon Pay will behave as a redirect payment method when used in one-time or recurring transactions that were initiated using createTransaction, including Pay By Link. The express checkout, in which a transaction is initiated through use of an Amazon Pay button, should be the main integration for one-time payments in any shop. See Amazon Pay

Apple Pay

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
APPLE_PAY	Apple Pay	variable	Apple Pay supported countries	variable	yes	yes	API, SecureFields

Description

Apple Pay allows customers to pay with the press of a button, using payment methods saved to their Apple account.

The lynck system supports two different integration types, which offer different advantages:

Option	Supported channels	Benefits	Limitations
Option 1	Web only	Simplifies setup for merchants No Apple Developer account subscription required for merchants	Cannot be used for native in-app integrations
Option 2	Web, App	Native in-app integrations supported Merchants have full control over certificate management	Each merchant requires their own Apple Developer account and unique merchant ID/keys/certificate setup

Requirements

The requirements depend on which integration option is chosen.

Option 1

To offer Apple Pay as a payment method you will need to register the domains on which the Apple Pay button should be displayed in the merchant service area. To do so, please navigate to Settings -> Apple Pay -> Web, Hosted Pages & Subscriptions. Here you will find the option to add one or more domains and register them.

Option 2

To offer Apple Pay as a payment method, an Apple Pay Developer account is required. Depending on your integration you need to adhere to Apple Pay brand guidelines, and follow the Apple Pay integration checklist. It is required to create an Apple Pay Payment Processing Certificate and upload it in the Merchant Service Area to use Apple Pay in the production environment. To do so, please navigate to Settings -> Apple Pay -> Web & App Integration.

• Apple Pay design resources and guidelines
• Apple Pay App developer documentation
• Apple Pay Web developer documentation

Integration specifics

If you do not use a lynck plugin that supports Apple Pay, you will need to integrate the Apple Pay button into your checkout process.

Note that the Apple Pay button may only be rendered in supported browsers or devices. Before offering the payment method it should be verified that the customers' browser/device is supported. This may be done using the canMakePayments function of the official Apple Pay JS API.

Optimally the Apple Pay button should be displayed on the order confirmation page of the shop, so that the payment authorization with Apple Pay is the last step in the checkout process. This is important as the transaction amount provided when rendering the Apple Pay button should be the final amount for which the customer should be charged.

In a best case scenario the Apple Pay button would replace the "Buy" button of the store, when it was selected as a payment method.

How the Apple Pay button is integrated into the checkout depends on which integration option is chosen.

Option 1

//Apple Pay library

//For use on the production environment
<script src="https://api.crefopay.de/libs/3.0/apple-client.js"></script>

//For use on the sandbox environment
<script src="https://sandbox.crefopay.de/libs/3.0/apple-client.js"></script>

To render the Apple Pay button for a transaction, the lynck apple client JavaScript library needs to be included in the header of the page.

<script type="text/javascript" charset="utf-8">
  appleClient = new AppleClient(
  shopPublicKey,
  orderNo,
  sessionRequest,
  configuration,
  initializationCompleteCallback,
  cancelCallback,
  approveCallback
  );
appleClient.createButton();
</script>

To render the button, an instance of the AppleClient needs to be created first. This is done by providing the public key of your shop, the orderID of the transaction, a session request containing transaction details, a configuration object and three callback functions. Afterwards the createButton function of the AppleClient instance can be used, to insert the button on the page.

<div data-crefopay-placeholder="appleButton"></div>

This function will search for a placeholder field on the entire page, and render the button inside it. The placeholder should be a simple DIV-element with the attribute data-crefopay-placeholder=”appleButton”.

Argument	Description
shopPublicKey	Your public shop key. This key is shared during onboarding or can be found in the merchant service area at Settings - Shop Details - API Credentials
orderNo	The orderID of the transaction for which the Apple Pay button should be rendered
sessionRequest	An Apple Pay session request which contains some transaction data to be displayed during the Apple Pay payment authorization. Details follow below
configuration	This argument should be used to provide additional transaction information required for processing. Details follow below
initializationCompleteCallback	This function will be called right after the client initialization and receives the API response of lynck as argument
cancelCallback	This function will be called if the customer cancels the payment authorization process at Apple Pay
approveCallback	This function will be called when the payment authorization at Apple Pay was successful. The transaction may be reserved afterwards

session object

Value	Information
countryCode	ISO 3166 country code of the billing address country
currencyCode	Three-letter ISO 4217 currency code of the transaction currency
total	Object containing a label and an amount to be displayed during the Apple Pay payment authorization

total object

Value	Information
label	Short description of the basket as per Apple Pay documentation
amount	The total transaction amount as per Apple Pay documentation

configuration object

Value	Information
stagingSystemUrl	Base URL of the system for which the transaction should be created. Set to Sandbox if not provided. Possible values: Sandbox: https://sandbox.crefopay.de/ Production: https://api.crefopay.de/
nonce	The nonce will be passed on in the script tags for all libraries that are automatically fetched by the apple-client.js, so that the content security policy of shops can allow them to load
buttonstyle	Sets the color/style of the Apple Pay button. Possible values: black white white-outline
locale	Sets the language used to display the Apple Pay button. Most relevant options: de-DE en-GB en-US
type	Sets the Apple Pay button type which influences the text shown on the button. Most relevant options: buy pay plain continue subscribe

Initialization callback

The provided callback function initializationCompleteCallback will be called once the createButton function was executed, and the result will be provided to it. When resultCode=0 is returned then the button was successfully rendered. For any other resultCode the rendering failed, and an error message is provided.

Relevant fields for result processing:

Field	Description
resultCode	resultCode = 0 -> The Apple Pay button was successfully rendered. resultCode > 0 -> see errorcodes
message	If an error occurs, this field contains details about that error. Not set if resultCode = 0

Cancel callback

This function will be called if the customer cancels the payment authorization process at Apple Pay, or if the authorization failed due to any other reason. In this scenario the checkout process should not progress, and the transaction should not be reserved. The customer may re-attempt the authorization at Apple Pay.

Approve callback

This function will be called when the payment authorization at Apple Pay was successful. The payment token returned by Apple Pay is automatically stored for the transaction, so the transaction may be reserved without providing any additional parameters.

If the Apple Pay button replaced the "Buy" button of the shop, as is recommended, you may mark the order as accepted in your shop system, and immediately call the reserve API to complete the transaction.

Option 2

To process payments using Apple Pay on the lynck platform, you will need to present the Apple Pay button to your customer to collect a payment token. This payment token then needs to be passed in your reserve call in the field paymentToken when the customer confirmed their order.

For this option please follow the instructions provided by Apple Pay on how to include the Apple Pay button on the web or in app.

Recurring payments with Apple Pay

Whenever an Apple Pay transaction is successfully reserved, the card data collected from the payment token is stored as a payment instrument for the customer. The associated paymentInstrumentId can be returned as GET parameter in the callback, or it can be fetched from the field lastUsedPaymentInstrumentID using the getUser API.

If you wish to process your own recurring payments using Apple Pay, then only the initial transaction with recurringTransactionType=FIRST should be completed with payment method APPLE_PAY. For all recurring payments with recurringTransactionType=RECURRING, for which the customer is not present, the returned paymentInstrumentID should be used in combination with the payment method CC in the reserve call. Essentially the recurring payments are handled as regular recurring credit card payments based on the payment instrument that was created using Apple Pay.

Bill payments

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
BILL	Bill payment	no	DE, AT, CH	EUR, CHF	no	no	all

Description

Bill payments are the most basic solution to allow your customers to buy something now and pay later.

Per default settings this payment method is considered insecure and will therefore only be offered to customers if no risk rules are hit, or if a configured solvency check returns a positive result.

For this payment method a dunning and collection service can be enabled, which will automatically be informed if no payment is registered upon reaching the due date of the invoice.

Requirements

To allow lynck to automatically track and match incoming payments to lynck transactions, it is required to provide account permissions to the lynck finance department. It is also recommended to create/use a bank account that is dedicated for lynck transactions. To make use of dunning and collection services, a contract with a service provider is required.

Integration specifics

In contrast to most other payment methods no payment has been made yet when the merchant creates the invoice and ships the goods when using bill as payment method. Usually a capture collects the funds that were previously reserved in the checkout process, but for bill payments the capture serves to mark when a merchant triggered the shipment of the goods and therefore the point in time from which the debt is considered to be open. It is especially important to properly capture bill transactions when the dunning and collection service is enabled, as they heavily depend on them.

Bill secure

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
BILL_SECURE	Bill payment	no	DE	EUR	yes	no	SecureFields, HostedPageAfter, HostedPageBefore

Description

Bill payments are the most basic solution to allow your customers to buy something now and pay later. Bill secure is an alternative to regular bill payments in which the debt is bought by a third party (Billie) that pays out the merchant immediately. Therefore, it presents a more secure option for merchants that ensures liquidity.

Requirements

A business contract with Billie is required to offer bill secure as a payment method.

The payment method has the following restrictions which must be fulfilled to be offered in the checkout:

• A billing address with country=DE is set
• The transaction amount must include taxes (field netAmount)
• The userType of the customer is BUSINESS

Integration specifics

Billie requires customer identification via widget. For more details, see Billie.

Cash on delivery

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
COD	Cash on delivery	no	all	all	yes	no	all

Description

For this payment method no actual payment gateway or provider is contacted, and the customer is not prompted to perform any payment on order completion. Generally this payment method should be used for cash or alternative payments outside the lynck platform.

Requirements

None

Integration specifics

Whenever a COD transaction is captured by the merchant, it will automatically consider itself to be paid, and immediately transition into status DONE.

Credit card

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
CC	Credit card	no	variable	variable	no	yes	all

Description

This payment method enables customers to pay using their credit card without using 3D-Secure to verify their identity.

Due to PSD2 regulations it is no longer permitted within the EU to offer credit card payments without SCA(strong customer authentication). For shops outside the EU it is possible to still use this payment method, though it is recommended to use CC3D, or at least define conditions under which 3D-Secure should be applied.

Requirements

A contract with a partner acquirer of lynck is required to process credit card payments.

Integration specifics

Before a transaction can be reserved using CC as payment method, the credit card of the customer needs to be registered as a payment instrument in the lynck system. Merchants that are PCI certified may collect the card data themselves and provide it using the registerUserPaymentInstrument API. For all other merchants the credit card data may be collected using the SecureFields solution, which allows collection of the card data without it ever coming into direct contact with the merchant environment. When using a hosted pages solution, lynck will handle the registration of payment instruments.

Credit card 3D-Secure

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
CC3D	Credit card 3D-Secure	variable	variable	variable	yes	yes	all

Description

This payment method enables customers to pay using their credit card while verifying their identity using 3D-Secure.

Requirements

A contract with a partner acquirer of lynck is required to process credit card payments.

Integration specifics

Before a transaction can be reserved using CC3D as payment method, the credit card of the customer needs to be registered as a payment instrument in the lynck system. Merchants that are PCI certified may collect the card data themselves and provide it using the registerUserPaymentInstrument API. For all other merchants the credit card data may be collected using the SecureFields solution, which allows collection of the card data without it ever coming into direct contact with the merchant environment. When using a hosted pages solution, lynck will handle the registration of payment instruments.

When processing credit card payments with CC3D, then the 3D-Secure v2 process is applied, and in most cases the customer is asked to verify their identity. For this purpose the customer is redirected to an external page. Depending on the issuer/bank of the customer, the payment process may also be frictionless, in which case the customer is not required to be redirected at all. Hence, it is variable whether the customer must be redirected or not. The supported countries/currencies mostly depend on the acquirer that is used to process the payments.

Direct debit

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
DD	Direct debit	no	DE, AT, CH	EUR, CHF	no	yes	all

Description

Direct debit payments are a convenient solution to allow your customers to buy something now and pay later.

Per default settings this payment method is considered insecure and will therefore only be offered to customers if no risk rules are hit, or if a configured solvency check returns a positive result.

For this payment method a dunning and collection service can be enabled, which will automatically be informed if no payment is registered upon reaching the due date of the invoice.

Requirements

To allow lynck to automatically track and match incoming payments to lynck transactions, it is required to provide account permissions to the lynck finance department. It is also recommended to create/use a bank account that is dedicated for lynck transactions. To make use of dunning and collection services, a contract with a service provider is required.

Integration specifics

Before a transaction can be reserved using DD as payment method, the bank account of the customer needs to be registered as a payment instrument in the lynck system. Merchants may do so using the registerUserPaymentInstrument API, or alternatively using the SecureFields solution, which allows collection of the bank account data without it ever coming into direct contact with the merchant environment. When using a hosted pages solution, lynck will handle the registration of payment instruments.

In contrast to most other payment methods no payment has been made yet when the merchant creates the invoice and ships the goods when using direct debit as payment method. For direct debit, the capture will trigger the payment process, in which a SEPA file is generated and provided to the customers bank. Therefore, it is highly important that merchants properly capture their transactions, because both the actual payments and the potential dunning/collection processes depend on it. Captures may transition into status CHARGEBACK after they were already paid, if the customer triggers a payment reversal with their bank.

eps

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
EPS	eps	yes	all	EUR	yes	no	all

Description

Eps is a bank account based payment method that is popular in Austria.

Requirements

A contract with PPRO is required to process eps payments. Lynck requires the PPRO contract ID for configuration purposes, and also the account holder name/creditor ID of the merchant to process refunds.

Integration specifics

For any eps transaction, the actual payment/transfer of funds is immediately performed after the customer authorized the payment at their bank. Therefore, captures on an eps transaction do not actually trigger any collection of funds, and only serve to mark the transaction as being fulfilled when the goods are shipped.

Giropay

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
GIROPAY	Giropay	yes	all	EUR	yes	no	all

Description

Giropay is a bank account based payment method that is popular in Austria.

Requirements

A contract with PPRO is required to process Giropay payments. Lynck requires the PPRO contract ID for configuration purposes, and also the account holder name/creditor ID of the merchant to process refunds.

Integration specifics

For any Giropay transaction, the actual payment/transfer of funds is immediately performed after the customer authorized the payment at their bank. Therefore, captures on a Giropay transaction do not actually trigger any collection of funds, and only serve to mark the transaction as being fulfilled when the goods are shipped.

Google Pay™

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
GOOGLE_PAY	Google Pay™	variable	variable	variable	yes	yes	all

Description

Google Pay allows customers to pay with the press of a button, using payment methods saved to their Google account. It supports both Android™ application integrations and web integrations.

Requirements

To display the Google Pay button on your domain, a Google Pay business account is required. Depending on your integration you need to adhere to Google Pay brand guidelines, and follow the Google Pay integration checklist. In a final step you will need to request production access to use Google Pay in the production environment.

For solutions in which the payment method selection is done on either the crefopay.de or lynck.de domain, such as transactions and subscriptions using the integration type Hosted Page After and Pay By Link, no business account is required.

Google Pay Android integration:

• Google Pay Android developer documentation
• Google Pay Android integration checklist
• Google Pay Android brand guidelines

Google Pay Web integration:

• Google Pay Web developer documentation
• Google Pay Web integration checklist
• Google Pay Web brand guidelines

In case you want to use a plugin solution which renders the Google Pay button in your name, then your Google Pay merchant ID is required for configuration. You may register with the Google Pay and Wallet Console to receive your merchant ID. Further you must adhere to the Google Pay APIs Acceptable Use Policy and accept the terms that the Google Pay API Terms of Service defines.

Integration specifics

If you do not use a plugin that supports Google Pay or an integration that uses Hosted Page After, you will need to integrate the button into your checkout process. To do so please refer to the documentation listed in the 'Requirements' section. This brief video guide also provides on overview on how the button is to be integrated: Google Pay API Implementation Demo (Web)

The following description is only needed in case you integrate the button yourself:

To process payments using Google Pay on this platform, you will need to present the Google Pay button to your customer to collect a payment token. This payment token then needs to be passed in your reserve call in the field paymentToken when the customer confirmed their order.

When initializing the Google Pay button in your checkout process, you will need to set parameters to identify us as your payment provider:

Field	Value
gateway	lynck
gatewayMerchantId	The merchant ID you received in the onboarding process

Further notes:

• Only define card networks which are supported by your acquirer. This should be VISA and MASTERCARD.
• For allowedCardAuthMethods set PAN_ONLY. 3D-Secure checks for Google Pay are automatically enforced.
• Ensure the totalPriceStatus paymentDataRequest is set to FINAL if your business operates in the European Economoic Area.
• It is not required to receive and process any billing/shipping address through Google Pay, as they would already have been collected before createTransaction/createSubscription was called, or are not necessary for transactions with context PAY_BY_LINK.

Recurring payments with Google Pay

Whenever a Google Pay transaction is successfully reserved, the card data collected from the payment token is stored as a payment instrument for the customer. The associated paymentInstrumentId can be returned as GET parameter in the callback, or it can be fetched from the field lastUsedPaymentInstrumentID using the getUser API.

If you wish to process your own recurring payments using Google Pay, then only the initial transaction with recurringTransactionType=FIRST should be completed with payment method GOOGLE_PAY. For all recurring payments with recurringTransactionType=RECURRING, for which the customer is not present, the returned paymentInstrumentID should be used in combination with the payment method CC in the reserve call. Essentially the recurring payments are handled as regular recurring credit card payments based on the payment instrument that was created using Google Pay.

iDEAL

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
IDEAL	iDEAL	yes	all	EUR	yes	yes	all

Description

iDEAL is a bank account based payment method that is popular in the Netherlands.

Requirements

A contract with PPRO is required to process iDEAL payments. Lynck requires the PPRO contract ID for configuration purposes, and also the account holder name/creditor ID of the merchant to process refunds.

Integration specifics

For any iDEAL transaction, the actual payment/transfer of funds is immediately performed after the customer authorized the payment at their bank. Therefore, captures on an iDEAL transaction do not actually trigger any collection of funds, and only serve to mark the transaction as being fulfilled when the goods are shipped.

Recurring payments with iDEAL

Natively iDEAL does not support recurring payments, but the lynck system was adapted to support recurring payments based on the customer bank account that is returned when completing a purchase with iDEAL. For lynck subscriptions, lynck will automatically process all recurring payments using the payment method direct debit(DD).

Whenever an IDEAL transaction is successfully reserved, the bank account returned by iDEAL is stored as a payment instrument for the customer. The associated paymentInstrumentId can be returned as GET parameter in the callback, or it can be fetched from the field lastUsedPaymentInstrumentID using the getUser API. If you wish to process your own recurring payments using iDEAl, then only the initial transaction with recurringTransactionType=FIRST should be completed with payment method IDEAL. For all recurring payments the returned paymentInstrumentID should be used in combination with the payment method DD. If a customer completed an iDEAL transaction with recurringTransactionType=FIRST, then a recurring SEPA mandate is automatically generated and provided to the customer via email.

PayPal

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
PAYPAL	PayPal	variable	PayPal supported countries	PayPal supported currencies	yes	yes	SecureFields, HostedPageAfter, HostedPageBefore, Express - See PayPal Express

Description

Using this payment method allows the processing of payments through the PayPal platform. Additionally, lynck supports a multitude of PayPal services such as PayPal Express, PayPal subscriptions and PayPal disputes.

Requirements

To offer PayPal as a payment method, a PayPal business account is required. The merchant will need to grant lynck permissions to perform certain actions in their name, so that lynck can create and manage payments for them. Additionally, lynck requires the email associated to the PayPal business account for configuration purposes.

Integration specifics

Pending payments

In some cases PayPal will accept payment attempts from customers, but mark them as pending. This may be the case if PayPal performs some additional risk or fraud checks after the payment process, or if a bank based payment method was chosen by the customer. These transactions will transition into status CIAPENDING directly after being reserved, and will only go into status MERCHANTPENDING, after PayPal notified that the reservation was successful.

Merchants may ask the lynck support to disable pending payment methods in their configuration to avoid this scenario.

Redirection

Whether PayPal can be treated as a redirect payment method or not depends on the version of the PayPal gateway that is enabled for you. Generally, the latest version is not treated as a redirect payment method, but if you use lynck plugins, you may have to use an older version which still requires customer redirection.

Generally, it is recommended to dynamically react to the response code in the reserve response on whether to redirect the customer or not.

PayPal button and overlay

The latest integration type for PayPal requires that a PayPal button is rendered and displayed to the customer on the payment selection page. This PayPal button opens a window in which the customer is then able to authorize the payment, before actually completing the purchase within the shop. This type of integration is favorable as the customer will never be completely redirected outside the shop.

When using the SecureFields integration type, the merchant may decide the location and style of the PayPal button when by using a placeholder element with the attribute data-crefopay-placeholder=payPalButtons. Upon initializing the SecureFields library, the PayPal button will be rendered inside the placeholder, using the configuration values provided.

If no placeholder element for the PayPal button can be found upon initialization, then the SecureFields library will instead open an overlay if the customer triggers registerPayment() while PAYPAL was selected as payment method. Within this overlay the PayPal button will be rendered, so that the customer can log in and authorize the payment.

Overage limit and re-authorization

If a customer authorizes a certain transaction amount during the checkout process using the PayPal button, and the pop-up window which is triggered by the button, then it may be possible that the transaction amount is modified after the authorization. This may be due to last-minute changes in the shop basket, or due to delivery costs and other fees being added.

While PayPal allowed a certain amount of overcharge in the past, new regulations require that the customer re-authorizes the payment whenever the final amount is higher than the amount the payer was made aware of initially.

To allow for this, an optional flow may be enabled for your account. In this flow, when a reserve-attempt is performed, and PayPal rejects the transaction due to an overcharge, then our system will automatically initiate a process to re-authorize the new final transaction amount, and return a URL in the reserve-response, to which the customer should be redirected. When successful, the customer will be redirected to your configured success-URL, and otherwise to the configured failure-URL.

This flow is optional, and it may not be relevant to your integration, if it’s not possible to modify the transaction amount between selecting the payment method and completing the transaction.

Alternative payment methods

Additional buttons for alternative payment methods can be rendered next to the PayPal button. This will happen automatically if the relevant option was enabled by the lynck support.

Because a payment for the full transaction amount is immediately triggered upon authorization even before the reserve call was performed, it is no longer possible to modify the transaction amount in the reserve call. This makes it impossible to add or adjust delivery costs or modify the basket after the payment method was selected in the checkout process. Additionally, it is not possible to perform partial captures after a transaction was reserved using PayPal with additional payment methods enabled.

Which of the 4 enabled alternative payment methods are shown is controlled by PayPal, and it depends on the customer. PayPal attempts to identify whether the customer is from a certain country, and will offer payment methods depending on the result.

The following APMs are supported:

Name	Country
iDEAL	NL
eps	AT
bancontact	BE
Przelewy24	PL

Prepaid

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
PREPAID	Cash in advance	no	DE, AT, CH	EUR, CHF	yes	no	all

Description

Prepaid allows customers to pay their order upfront, so that the order is shipped only after the funds were received on the bank account.

Requirements

To allow lynck to automatically track and match incoming payments to lynck transactions, it is required to provide account permissions to the lynck finance department. It is also recommended to create/use a bank account that is dedicated for lynck transactions.

Integration specifics

All transactions reserved with PREPAID will transition into status CIAPENDING. They will remain in this status until a payment was added or matched to the transaction, and then transition into status MERCHANTPENDING._

Sofort

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
SU	Sofort	yes	all	EUR	yes	no	all

Description

Sofort is a bank account based payment method that is popular in Germany.

Requirements

A Sofort business account is required to process Sofort payments. Lynck requires the Sofort user ID, project ID and API key for configuration purposes, so that they are able to trigger payments in the name of the merchant.

Integration specifics

For any Sofort transaction, the actual payment/transfer of funds is immediately performed after the customer authorized the payment at Sofort. Therefore, captures on a Sofort transaction do not actually trigger any collection of funds, and only serve to mark the transaction as being fulfilled when the goods are shipped.

Zinia Buy Now Pay Later

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
ZINIA_BNPL	Zinia Buy Now Pay Later	yes	DE	EUR	yes	no	all

Description

Zinia Buy Now Pay Later (BNPL) allows customers to pay their debt within 30 days after they received their invoice and the delivery was triggered. To do so, they are redirected to a payment page on which they may be asked to confirm their user data and Zinia performs risk checks and either confirms or denies the customer. The merchant is paid out by Zinia when a capture is performed.

Requirements

A business contract with Zinia and their online platform provider Payever is required to offer Zinia BNPL. Lynck requires the client ID, client secret and business uuid as provided from Payever for configuration.

The payment method has the following restrictions which must be fulfilled to be offered in the checkout:

• A billing address with country=DE is set
• If a shipping address is set, it is equal to the billing address
• If a shippingRecipient is set, it is equal to the billingRecipient
• The transaction currency is EUR
• The userType is PRIVATE
• The transaction amount is between the minimum and maximum amount as dictated by Zinia
• Zinia sets these amounts per merchant contract, and they are negotiable
• The default minimum is 50€ and the default maximum is 750€
• The transaction context is not SUBSCRIPTION
• The transaction recurringTransactionType is not FIRST or RECURRING

Integration specifics

On reserve with ZINIA_BNPL as payment method, the responseCode will be 1 (redirect) and the response will contain a parameter redirectUrl, to which the customer must be redirected. On the page the customer is redirected to Zinia will ask for additional data and the user is able to confirm their payment method and review payment details.

Depending on the outcome, the customer will return to the redirect URL (API 2.0) or failure/success URL (API 2.1).

For ZINIA_BNPL, any capture will immediately trigger a payout from Zinia to the merchant. A capture can be a partial or full capture, and it will immediately transition into status PAID. If a merchant only intends to deliver a part of the order, because the customer partially cancelled it, then it is possible to inform Zinia about the cancellation by performing a finish call to cancel the remaining uncaptured amount at Zinia.

Example 1: Full capture

• A transaction of 40€ is successfully reserved using ZINIA_BNPL
• A partial capture C1 with 40€ is created
• The capture C1 automatically transitions into status PAID
• The transaction transitions into status DONE
• Zinia triggers a payout of 40€ to the merchant

Example 2: Partial captures

• A transaction of 40€ is successfully reserved using ZINIA_BNPL
• A partial capture C1 with 30€ is created
• The capture C1 automatically transitions into status PAID
• The transaction transitions into status DONE
• Zinia triggers a payout of 30€ to the merchant
• A partial capture C2 with 10€ is created
• The capture C2 automatically transitions into status PAID
• Zinia triggers a payout of 10€ to the merchant

Example 3: Partial capture and finish

• A transaction of 40€ is successfully reserved using ZINIA_BNPL
• A partial capture C1 with 30€ is created
• The capture C1 automatically transitions into status PAID
• The transaction transitions into status DONE
• Payever triggers a payout of 30€ to the merchant
• A finish call is performed for the transaction
• Zinia is notified that the remaining open 10€ of the order are cancelled

Zinia Splitpay

Payment method details

Identifier	Name	Redirect	Country	Currency	Secure	Recurring	Integration Type
ZINIA_INSTALLMENT	Zinia Splitpay	yes	DE	EUR	yes	no	all

Description

Zinia Splitpay allows customers to select a payment plan in which they pay off their debt within 3-36 months. To do so, they are redirected to a payment page on which they may be asked to confirm their user data and then select a payment plan. Zinia then performs risk checks and either confirms or denies the customer. The merchant is paid out by Zinia upon fully capturing the order.

Requirements

A business contract with Zinia and their online platform provider Payever is required to offer Zinia Splitpay. Lynck requires the client ID, client secret and business uuid as provided from Payever for configuration.

The payment method has the following restrictions which must be fulfilled to be offered in the checkout:

• A billing address with country=DE is set
• If a shipping address is set, it is equal to the billing address
• If a shippingRecipient is set, it is equal to the billingRecipient
• The transaction currency is EUR
• The userType is PRIVATE
• The transaction amount is between the minimum and maximum amount as dictated by Zinia
• Zinia sets these amounts per merchant contract, and they are negotiable
• The default minimum is 50€ and the default maximum is 750€
• The transaction context is not SUBSCRIPTION
• The transaction recurringTransactionType is not FIRST or RECURRING

Integration specifics

On reserve with ZINIA_INSTALLMENT as payment method, the responseCode will be 1 (redirect) and the response will contain a parameter redirectUrl, to which the customer must be redirected. On the page the customer is redirected to Zinia will ask for additional data and the user is able to confirm their payment method and review payment details.

Depending on the outcome, the customer will return to the redirect URL (API 2.0) or failure/success URL (API 2.1).

It is possible to perform partial captures and reductions by calling the capture and refund API, but each individual call will not trigger the payout by Zinia. They are treated as virtual captures and reductions, until the full transaction amount is accounted for. Only then will Zinia be informed about the final amount that needs to be paid out to the merchant.

Example 1: Multiple partial captures

• A transaction of 40€ is successfully reserved using ZINIA_INSTALLMENT
• A partial capture C1 with 20€ is created
• The capture C1 remains in status PAYPENDING
• A partial capture C2 with 20€ is created
• The full transaction amount of 40€ is accounted for
• Both captures C1 and C2 automatically transition into status PAID
• The transaction transitions into status DONE
• Zinia triggers a payout of 40€ to the merchant

Example 2: Partial capture and reduction

• A transaction of 40€ is successfully reserved using ZINIA_INSTALLMENT
• A partial capture C1 with 20€ is created
• The capture C1 remains in status PAYPENDING
• A refund of 10€ is created with no captureID provided
• The total transaction amount is reduced to 30€
• A partial capture C2 with 10€ is created
• The full transaction amount of 30€ is accounted for
• Both captures C1 and C2 automatically transition into status PAID
• The transaction transitions into status DONE
• Zinia triggers a payout of 30€ to the merchant

API

addChargeback

The addChargeback call may be used to simulate an incoming chargeback for transactions that were reserved using the payment methods CC, CC3D or DD. This functionality may only be used on transaction captures that have registered an incoming payment, which may be simulated using the addPayment API.

For CC and CC3D the chargeback amount should be set to the paid amount of the capture for which the chargeback should be simulated.

For DD the chargeback amount may be higher than the paid amount of the capture. The difference between the chargeback amount and the paid amount of the capture will then be added as a chargeback fee, which is usually added by banks. Example: If a DD transaction with a fully paid capture c1 of 10€ exists, and a chargeback of 12€ is simulated for this capture, then the capture will be fully reopened, and an additional 2€ fee amount is added to the capture. This sets the transaction balance to -12€.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/addChargeback

<?php
function addChargeback($orderID, $captureID, $amount) {
    global $requestUrl, $merchantID, $storeID;
​
    $amount = json_encode(array('amount' => $amount));
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'orderID' => $orderID,
        'captureID' => $captureID,
        'amount' => $amount
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "A chargeback was simulated for order {$orderID}. Amount: {$amount}\n\r";
        return true;
    } else {
        echo "Chargeback simulation failed: {$orderID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult addChargeback() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private String getAmount() {
    return Json.createObjectBuilder()
            .add("amount", "1200")
            .build()
            .toString();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-123");
    map.add("captureID", "capture-123");
    map.add("amount", getAmount());
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode": 0,
    "salt": "44b8b355a6c42a3a"
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.
captureID	AN (50)	yes	This is the unique reference of a capture or a partial capture (e.g. the invoice number).
amount	J (Amount)	yes	Amount in smallest possible denomination (e.g. 12399 for 123.99 Eur).
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

addressCheck

This API can be used to validate or correct a customers address. Both the mandatory fields in the request and the response to this call may vary depending on the product that is configured to perform the address check.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/addressCheck

Live: https://api.crefopay.de/2.0/addressCheck

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
address	J (Address)	yes	The address to be checked. While th address object in the request itself is mandatory, the exact fields which it should contain differ depending on the service that will be used. Independent of which service is used the field "country" is always mandatory.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
checkReferenceId	N	Unique reference to the performed check
responseData	J	Contains the raw response data of the address check provider in JSON format
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

addPayment

The addPayment call allows the merchant to add funds to a transaction, thereby informing lynck about incoming payments. This should generally be done in case a payment was received on an account or by other means to which lynck has no access and therefore cannot match the payment to a transaction.

If it should be possible to perform a refund on this payment later on, then it is mandatory that the bank data of the account from which the payment originated from is provided.

Payments can only be added to transaction in the following states: CIAPending, MerchantPending, InProgress, Done, Cancelled or FraudCancelled. Additionally for direct debit transactions, the transaction has to have at least one capture in the status Chargeback, InDunning or InCollection.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/addPayment

Live: https://api.crefopay.de/2.0/addPayment

public lynckResult addPayment() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private String getAmount() {
    return Json.createObjectBuilder()
            .add("amount", "500")
            .build()
            .toString();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-130");
    map.add("captureID", "capture-129");
    map.add("amount", getAmount());
    map.add("valutaDate", "2019-01-15");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode":0,
    "salt":"d5813e5feb22b47d"
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.
captureID	AN (50)	see description	This is the unique reference of a capture or a partial capture (e.g. the invoice number). Only mandatory for direct debit transactions.
amount	J (Amount)	yes	The amount of the received payment.
valutaDate	D (YYYY-MM-DD)	yes	Date on which the payment was received.
iban	AN (34)	no	IBAN of the bank account from which the payment was received. Required if a refund is to be performed on this payment.
accountHolder	AN (70)	no	The account holder of the bank account from which the payment was received. Required if a refund is to be performed on this payment later on.
message	AN (255)	no	Payment description
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> Error, see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

batch

Request Header

Field	Mandatory	Comments
X-API-Key	yes	Your public API key
Content-Type	yes	application/json

Sample batch/createAndReserveRecurringTransaction request body:

{
  "url": "https://notification.merchant.de/errors",
  "createAndReserveTransactionRequest": [
    {
      "orderID": "recurringOrder-500",
      "referenceOrderID": "initialOrder-10",
      "userID": "user-123",
      "merchantReference": "Additional reference text 1",
      "amount": 1000,
      "locale": "DE"
    },
    {
      "orderID": "recurringOrder-501",
      "referenceOrderID": "initialOrder-11",
      "userID": "user-321",
      "merchantReference": "Additional reference text 2",
      "amount": 500,
      "locale": "EN"
    }
  ]
}

batch createAndReserveRecurringTransaction

This endpoint starts, automatically reserves and captures one or more transactions in the lynck system. The purpose of this is to create batches of up to 1000 recurring transactions within one request, instead of performing individual requests for each charge. This increases the speed at which the recurring charges can be processed.

This API cannot be used to create transactions that require any sort of customer interaction. The transactions created here are only intended to charge existing customers based on an already existing payment agreement.

Every transaction created using this endpoint will be created with integrationType=API, recurringTransactionType=RECURRING and autoCapture=true and has to refer to the initial transaction in which the customer authorized the recurring charges.

While the formatting is validated upfront, the contents are only evaluated when each transaction is processed. Should an error occur while a transaction is processed, or should the payment be declined by a service provider, then a POST notification is sent to a URL provided in the initial request. Each notification should be answered with HTTP code 200 to confirm that it was received. Should the notification delivery fail for any reason, then it is possible to fetch all errors that occurred during processing using the batch errors endpoint.

Method	URL
POST	Sandbox: https://sandbox.crefopay.de/3.0/batch/createAndReserveRecurringTransaction Live: https://api.crefopay.de/3.0/batch/createAndReserveRecurringTransaction

POST createAndReserveRecurringTransaction Request Body

Field	Type	Mandatory	Comments
url	string	yes	This URL receives POST notifications about failed transactions, should any error occur. See MerchantNotificationMessage
createAndReserveTransactionRequest	J (CreateAndReserveTransactionRequest)	yes	Container object for one to 1000 create transaction and reserve requests

POST createAndReserveRecurringTransaction HTTP Response Code

Code	Comments
202	Request accepted, the system will attempt to process all provided transactions. Response body contains resultCode
400	Bad request
401	Unauthorized

POST createAndReserveRecurringTransaction Response Body

Field	Type	Comments
resultCode	N	0 -> OK Any other code -> see errorcodes

batch errors

This endpoint may be used to receive (Method=GET) a list of all errors that have occurred during batch transaction creation, in case the delivery of error notifications failed. Alternatively it can be used to clear (Method=DELETE) the list. No request body parameters are required.

Method	URL
GET DELETE	Sandbox: https://sandbox.crefopay.de/3.0/batch/errors Live: https://api.crefopay.de/3.0/batch/errors

GET errors HTTP Response Code

Code	Comments
200	OK. Response body may return one or multiple errors that may have occurred during batch transaction creation. See MerchantNotificationMessage
400	Bad request
401	Unauthorized

DELETE errors HTTP Response Code

Code	Comments
200	OK. Error list was cleared
400	Bad request
401	Unauthorized

cancel

The cancel call allows the merchant to cancel an transaction where no capture has been processed yet.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/cancel

Live: https://api.crefopay.de/2.0/cancel

<?php
function cancel($orderID) {
    global $requestUrl, $merchantID, $storeID;
​
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'orderID' => $orderID
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully cancelled the order {$orderID}.\n\r";
        return true;
    } else {
        echo "We failed to cancel the order: {$orderID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult cancel() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-130");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode":0,
    "salt":"d5813e5feb22b47d"
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> Error, see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

capture

The capture call allows the merchant to create orders or part-orders for already started transactions

URL:

Sandbox: https://sandbox.crefopay.de/2.0/capture

Live: https://api.crefopay.de/2.0/capture

<?php
function capture($orderID, $captureID, $transactionAmount) {
    global $requestUrl, $merchantID, $storeID;
​
    $amount = json_encode(array('amount' => $transactionAmount));
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'orderID' => $orderID,
        'captureID' => $captureID,
        'amount' => $amount
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully captured the order {$orderID}. Amount: {$transactionAmount}\n\r";
        return true;
    } else {
        echo "We failed to capture the order: {$orderID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult capture() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private String getAmount() {
    return Json.createObjectBuilder()
            .add("amount", "12399")
            .build()
            .toString();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-129");
    map.add("captureID", "capture-129");
    map.add("amount", getAmount());
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode":0,
    "salt":"39e01bcfcc9eabb1",
    "status":"PAYPENDING"
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.
captureID	AN (50)	yes	This is the unique reference of a capture or a partial capture (e.g. the invoice number).
amount	J (Amount)	yes	Amount in smallest possible denomination (e.g. 12399 for 123.99 Eur).
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
status	AN	The status of the order. PAID, PAYPENDING or PAYMENTFAILED
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

createSubscription

The createSubscription call creates a subscription in the lynck system and evaluates which paymentMethods are available for the given user and basket data under consideration of various risk management aspects. A subscription will charge a customer in defined intervals. If a trial period is set the customer will be charged afterwards. A subscription always has a reference to an existing plan, which sets the default rate, trial period and payment interval. Though the trial period and amount can be overwritten for an individual subscription. Plans are created in the merchant service area.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/createSubscription

Live: https://api.crefopay.de/2.0/createSubscription

<?php
function createSubscription($subscriptionID, $userID) {
    global $requestUrl, $merchantID, $storeID;

    // Enter all mandatory parameters for creating a transaction here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'subscriptionID' => $subscriptionID,
        'userID' => $userID,
        'planReference => 'daily basic subscription',
        'integrationType' => 'API',
        'autoCapture' => 'false',
        'context' => 'ONLINE',
        'userType' => 'PRIVATE',
        'userRiskClass' => '0',
        'amount' => json_encode(
            array(
                'amount' => '100',
            )
        ),
        'basketItems' => json_encode(
            array(
                array(
                    'basketItemText' => 'User Registration Item',
                    'basketItemCount' => '1',
                    'basketItemAmount' => array(
                        'amount' => '100',
                    ),
                ),
            )
        ),
        'locale' => 'DE'
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully created the subscription {$subscriptionID}. Amount: {$transactionAmount}\n\r";
        return true;
    } else {
        echo "We failed to created the subscription: {$subscriptionID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult createSubscription() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private String getUserData() {
    return Json.createObjectBuilder()
            .add("name", "Max")
            .add("surname", "Mustermann")
            .add("dateOfBirth", "1978-08-15")
            .add("email", "max@mustermann.de")
            .build()
            .toString();
}

private String getBillingAddress() {
    return Json.createObjectBuilder()
            .add("street", "Hauptstraße")
            .add("no", "1")
            .add("zip", "10827")
            .add("city", "Berlin")
            .add("country", "DE")
            .build()
            .toString();
}

private String getAmount() {
    return Json.createObjectBuilder()
            .add("amount", "12399")
            .build()
            .toString();
}

private String getBasketItems() {
    JsonArrayBuilder builder = Json.createArrayBuilder();
    builder.add(Json.createObjectBuilder().add("basketItemText", "Item1").add("basketItemCount", "1").add("basketItemAmount", Json.createObjectBuilder()
            .add("amount", "12399")).build());
    builder.add(Json.createObjectBuilder().add("basketItemText", "Item2").add("basketItemCount", "3").add("basketItemAmount", Json.createObjectBuilder()
            .add("amount", "12399")).build());
    return builder.build().toString();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("subscriptionID", "subscription-132");
    map.add("userID", "user-127");
    map.add("planReference", "daily basic subscription");
    map.add("context", "ONLINE");
    map.add("userType", "PRIVATE");
    map.add("userRiskClass", "0");
    map.add("userData", getUserData());
    map.add("billingAddress", getBillingAddress());
    map.add("amount", getAmount());
    map.add("basketItems", getBasketItems());
    map.add("locale", "DE");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
   "resultCode":0,
   "salt":"d9d59524d630930d",
   "userData":{
      "name":"Max",
      "surname":"Mustermann",
      "dateOfBirth":"1978-08-15",
      "email":"max@mustermann.de"
   },
   "billingAddress":{
      "street":"Hauptstraße",
      "no":"1",
      "zip":"10827",
      "city":"Berlin",
      "country":"DE"
   },
   "allowedPaymentMethods":[
      "DD"
   ],
   "allowedPaymentInstruments":[

   ],
   "additionalInformation":[
      {
         "paymentMethodType":"DD",
         "issuer":[

         ],
         "logos":[

         ],
         "customTranslations":{

         },
         "sepaPaymentType":"RCUR",
         "mandateReference":"535357",
         "creditorId":"DE39ZZZ00001385300",
         "merchantName":"DEMO",
         "date":"13.08.2018"
      }
   ]
}

Request

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
subscriptionID	AN (50)	yes	This is a unique identifier for a subscription which is created by the shop.
planReference	AN (15)	yes	ID of the plan that the subscription will be based upon.
startDate	D(YYYY-MM-DD)	no	Defines a future date on which the subscription will become active and trigger the first payment. If a trial period is defined, then the trial period will begin on the start date. If no start date is provided the subscription will start immediately upon user confirmation.
trialPeriod	N (3)	no	Trial period in days. Range from 1 to 366. The trial period begins when the subscription becomes active, and the first payment will be triggered when the trial period ends.
userID	AN (50)	yes	The unique user id of the user.
integrationType	V	no	The type of integration in the web shop. Possible Values: API (default) SecureFields HostedPageBefore HostedPageAfter
merchantReference	AN (30)	no	Optional/additional reference for the transaction. This parameter is returned with every call from lynck to the shop.
userType	V	yes	This parameter defines business or private customers. This value cannot be changed after user creation. Possible Values: PRIVATE BUSINESS
userRiskClass	N (1) / D (1.1)	no	Possible values are: 0 -> trusted user 1 -> default risk user 2 -> high risk user Decimal value between 0.0 and 2.0, eg. 1.3 Defaults to 1.0 if neither userRiskClass nor basketItemRiskClass were set. If basketItemRiskClass is set, userRiskClass will default to that value instead.
userIpAddress	AN (15)	no	The IP address of the customer
companyData	J (Company)	see comment	Contact data of the user's company. This field is mandatory if the userType is BUSINESS and the userID was not registered before
userData	J (Person)	see comment	Contact data of the user. This field is mandatory if the userType is PRIVATE and the userID was not registered before
billingRecipient	AN (80)	no	Recipient for the Bill.
billingAddress	J (Address)	see comment	The user's billing address. This field is mandatory if if user was not registered before with this userID
shippingRecipient	AN (80)	no	Recipient for shipping
shippingAddress	J (Address)	no	The customers shipping address
amount	J (Amount)	no	If provided, this amount will overwrite the amount set in the subscription plan. This is not permitted for subscription plans for which the option "Enable PayPal Subscriptions" was checked. If not provided, the amount of the subscription plan is used.
basketItems	JA (Basket Item)	yes	A detailed list of all basket items
basketValidity	AN (4)	no	m -> minutes, h -> hours, d -> days; Example: one hour: 1h, ten minutes: 10m, two days: 2d - only one unit of time can be provided
locale	V	yes	The locale determines the user’s communication language e.g. for e-mails which will be send to the user or for payment pages. See Languages
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK 1 -> redirect any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
userData	J (Person)	Data of the user
billingAddress	J (Address)	Address of the user
companyData	J (Company)	Data of the company
allowedPaymentMethods	JA (PaymentMethods)	List of payment methods that are allowed for this user
allowedPaymentInstruments	JA (PaymentInstrument)	List of valid payment instruments that are registered for this user
redirectUrl	AN (1024)	The URL of the page that should be shown to the user. This is only set if the resultCode is 1
additionalInformation	JA (PaymentMethodInformation)	List of additional information for presenting the payment instruments to the customer.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

createTransaction

This call starts a transaction in the lynck system. The workflow depends on the integrationType. For more information refer to Integration options. Further, this call can act both as registerUser and updateUser call if an unknown/known userID is provided, often making the implementation of these calls unnecessary

URL:

Sandbox: https://sandbox.crefopay.de/2.0/createTransaction

Live: https://api.crefopay.de/2.0/createTransaction

<?php
function createTransaction($orderID) {
    global $requestUrl, $merchantID, $storeID;

    // Enter all mandatory parameters for creating a transaction here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'orderID' => $orderID,
        'userID' => $userID,
        'integrationType' => 'API',
        'autoCapture' => 'false',
        'context' => 'ONLINE',
        'userType' => 'PRIVATE',
        'userRiskClass' => '0',
        'amount' => json_encode(
            array(
                'amount' => '100',
            )
        ),
        'basketItems' => json_encode(
            array(
                array(
                    'basketItemText' => 'User Registration Item',
                    'basketItemCount' => '1',
                    'basketItemAmount' => array(
                        'amount' => '100',
                    ),
                ),
            )
        ),
        'locale' => 'DE'
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully created the order {$orderID}. Amount: {$transactionAmount}\n\r";
        return true;
    } else {
        echo "We failed to created the order: {$orderID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult createTransaction() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private String getUserData() {
    return Json.createObjectBuilder()
            .add("name", "Max")
            .add("surname", "Mustermann")
            .add("dateOfBirth", "1978-08-15")
            .add("email", "max@mustermann.de")
            .build()
            .toString();
}

private String getBillingAddress() {
    return Json.createObjectBuilder()
            .add("street", "Hauptstraße")
            .add("no", "1")
            .add("zip", "10827")
            .add("city", "Berlin")
            .add("country", "DE")
            .build()
            .toString();
}

private String getAmount() {
    return Json.createObjectBuilder()
            .add("amount", "12399")
            .build()
            .toString();
}

private String getBasketItems() {
    JsonArrayBuilder builder = Json.createArrayBuilder();
    builder.add(Json.createObjectBuilder().add("basketItemText", "Item1").add("basketItemCount", "1").add("basketItemAmount", Json.createObjectBuilder()
            .add("amount", "12399")).build());
    builder.add(Json.createObjectBuilder().add("basketItemText", "Item2").add("basketItemCount", "3").add("basketItemAmount", Json.createObjectBuilder()
            .add("amount", "12399")).build());
    return builder.build().toString();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-124");
    map.add("userID", "user-127");
    map.add("context", "ONLINE");
    map.add("userType", "PRIVATE");
    map.add("userRiskClass", "0");
    map.add("userData", getUserData());
    map.add("billingAddress", getBillingAddress());
    map.add("amount", getAmount());
    map.add("basketItems", getBasketItems());
    map.add("locale", "DE");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
   "resultCode":0,
   "salt":"d9f7268bb493e51b",
   "userData":{
      "name":"Max",
      "surname":"Mustermann",
      "dateOfBirth":"1978-08-15",
      "email":"max@mustermann.de"
   },
   "billingAddress":{
      "street":"Hauptstraße",
      "no":"1",
      "zip":"10827",
      "city":"Berlin",
      "country":"DE"
   },
   "allowedPaymentMethods":[
      "CC",
      "PAYPAL",
      "BILL"
   ],
   "allowedPaymentInstruments":[
      {
         "paymentInstrumentID":"Aqc9O5SSJuQTDHC9KXFE0Q",
         "paymentInstrumentType":"CREDITCARD",
         "accountHolder":"Max Mustarmann",
         "number":"************1111",
         "validity":"2025-01",
         "issuer":"VISA",
         "mandatoryReserveFields":[
            "cvv"
         ]
      }
   ],
   "additionalInformation":[
      {
         "paymentMethodType":"CC",
         "issuer":[
            "VISA",
            "MC"
         ],
         "logos":[
            "VISA",
            "MC"
         ],
         "customTranslations":{

         }
      },
      {
         "paymentMethodType":"PAYPAL",
         "issuer":[

         ],
         "logos":[

         ],
         "customTranslations":{

         }
      },
      {
         "paymentMethodType":"BILL",
         "issuer":[

         ],
         "logos":[

         ],
         "customTranslations":{

         }
      }
   ]
}

Request

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.
userID	AN (50)	yes	The unique user id of the user.
integrationType	V	no	The type of integration in the web shop. Possible Values: API (default) SecureFields HostedPageBefore HostedPageAfter
autoCapture	B	no	Enable automatic capture directly after the successful reservation, if the parameter is not set, the default is "false"
merchantReference	AN (30)	no	Optional/additional reference for the transaction. This parameter is returned with every call from lynck to the shop.
context	V	no	Determines if the transaction was initiated during online-checkout process or offline where no direct user interaction happens. Will be set to ONLINE by default if not provided. Possible Values: ONLINE MAIL_ORDER TELEPHONE_ORDER PAY_BY_LINK
userType	V	yes	This parameter defines business or private customers. This value cannot be changed after user creation. Possible Values: PRIVATE BUSINESS
userRiskClass	N (1) / D (1.1)	no	Possible values are: 0 -> trusted user 1 -> default risk user 2 -> high risk user Decimal value between 0.0 and 2.0, eg. 1.3 Defaults to 1.0 if neither userRiskClass nor basketItemRiskClass were set. If basketItemRiskClass is set, userRiskClass will default to that value instead.
userIpAddress	AN (39)	no	The IP address of the customer. Supported formats are IPv4 and IPv6
restrictedPaymentMethods	V	no	The payment methods provided in this field will not be marked as available for this transaction, and will not be offered to the customer on the hosted payment pages. Should contain a comma separated string of payment method identifiers
companyData	J (Company)	see comment	Contact data of the user's company. This field is mandatory if the userType is BUSINESS and the userID was not registered before
userData	J (Person)	see comment	Contact data of the user. This field is mandatory if the userType is PRIVATE and the userID was not registered before
creditLimit	J (Amount)	no	If this field is provided then the value is saved as specific credit limit for this customer only. Any previously saved credit limit will be overwritten.
billingRecipient	AN (80)	no	Recipient for the Bill.
billingAddress	J (Address)	see comment	The user's billing address. This field is mandatory if if user was not registered before with this userID
shippingRecipient	AN (80)	no	Recipient for shipping
shippingAddress	J (Address)	no	The customers shipping address
amount	J (Amount)	yes	The amount of the basket
basketItems	JA (Basket Item)	yes	A detailed list of all basket items
basketValidity	AN (4)	no	m -> minutes, h -> hours, d -> days; Example: one hour: 1h, ten minutes: 10m, two days: 2d - only one unit of time can be provided
hostedPagesTexts	JA (HostedPages text)	no	A list of texts for the hosted page in for different languages for different payment methods
locale	V	yes	The locale determines the user’s communication language e.g. for e-mails which will be send to the user or for payment pages. See Languages
additionalPaymentOptions	J (Payment options)	no	additional options
solvencyCheckInformation	J (Solvency check information)	no	result of a solvency check done by the merchant.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK 1 -> redirect any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
userData	J (Person)	Data of the user
billingAddress	J (Address)	Address of the user
companyData	J (Company)	Data of the company
allowedPaymentMethods	JA (PaymentMethods)	List of payment methods that are allowed for this user
allowedPaymentInstruments	JA (PaymentInstrument)	List of valid payment instruments that are registered for this user
redirectUrl	AN (1024)	The URL of the page that should be shown to the user. This is only set if the resultCode is 1
additionalInformation	JA (PaymentMethodInformation)	List of additional informations for presenting the payment instruments to the customer.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

Handling of Packstation addresses

• These type of address is only valid for shipping address
• The “Postnummer” is expected in the field shippingRecipient
• The word “Packstation” is expected in field street of the shippingAddress
• The number of “Packstation” is expected in field number of shippingAddress

deleteUserPaymentInstrument

The deleteUserPaymentInstrument call adds the functionality to delete a payment instrument from a user.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/deleteUserPaymentInstrument

Live: https://api.crefopay.de/2.0/deleteUserPaymentInstrument

<?php
function deleteUserPaymentInstrument($paymentInstrumentID) {
    global $requestUrl, $merchantID;
​
    $param = array(
        'merchantID' => $merchantID,
        'paymentInstrumentID' => $paymentInstrumentID
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully deleted the paymentinstrument {$paymentInstrumentID}\n\r";
        return true;
    } else {
        echo "We failed to delete the paymentinstrument: {$paymentInstrumentID}\n\r Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult deleteUserPaymentInstrument() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("paymentInstrumentID", "b2z4aogwDQJbvH144Kwt8g");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode":0,
    "salt":"951733fa7ecc7a7e"
}

Request

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
paymentInstrumentID	AN (20)	yes	The unique identifier of the payment instrument
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response:

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

finish

The finish call allows the merchant to finish an transaction where at least one capture has been created. This signals lynck that all expected funds were captured and no further payment are expected.

The finish call will trigger the following actions:

• If there are any uncaptured funds matched to the transaction, they will be refunded to the customer
• The open amount of all existing captures is set to 0, meaning they will transition into status PAID
• The transaction will transition into status DONE, if it is not in this status already
• For CC/CC3D/PAYPAL: the reservation for the remaining uncaptured amount is revoked at the respective payment provider, which means no further captures are permitted

URL:

Sandbox: https://sandbox.crefopay.de/2.0/finish

Live: https://api.crefopay.de/2.0/finish

<?php
function finish($orderID) {
    global $requestUrl, $merchantID, $storeID;
​
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'orderID' => $orderID
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully finished the order {$orderID}.\n\r";
        return true;
    } else {
        echo "We failed to finish the order: {$orderID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult finish() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-129");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
   "resultCode":0,
   "salt":"39b83acd3064a20b"
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

getCaptureStatus

This call returns the status of a captured order.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/getCaptureStatus

Live: https://api.crefopay.de/2.0/getCaptureStatus

<?php
function getCaptureStatus($orderID, $captureID) {
    global $requestUrl, $merchantID, $storeID;
​
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'orderID' => $orderID,
        'captureID' => $captureID
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully received the status for the capture: {$captureID}.\n\r";
        return responseBody;
    } else {
        echo "We failed to get the status for capture: {$captureID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult getCaptureStatus() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-129");
    map.add("captureID", "capture-129");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
   "resultCode":0,
   "salt":"761493d8ca3ef46c",
   "captureStatus":"PAID",
   "additionalData":{
      "transactionAmount":12399,
      "capturedAmount":12399,
      "paidAmount":12276,
      "creditAmount":123,
      "reducedAmount":0,
      "guaranteedAmount":0,
      "returnedGuaranteeAmount":0,
      "feeAmount":0,
      "openAmount":0,
      "transactionCurrency":"EUR"
   }
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.
captureID	AN (50)	yes	This is the unique reference of a capture or a partial capture (e.g. the invoice number).
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
captureStatus	V	The status of a capture. Possible values: see capture process
additionalData	J (CaptureStatusDetail)	Additional information to the capture
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

getSubscriptionPlans

The getSubscriptionPlans call provides details of all subscription plans created in the lynck system. The result can be filtered using parameters. This call can be used to dynamically display subscription plans in a shop front-end or to receive a specific plan ID for use in the createSubscription call.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/getSubscriptionPlans

Live: https://api.crefopay.de/2.0/getSubscriptionPlans

<?php
function getSubscriptionPlans() {
    global $requestUrl, $merchantID, $storeID;
​
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully received the plans for store: {$storeID}.\n\r";
        return responseBody;
    } else {
        echo "We failed to get the plans for store: {$storeID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult getSubscriptionPlans() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
   "resultCode":0,
   "salt":"d53159b2fc5118e1",
   "pageNumber":2,
   "pageSize":100,
   "totalEntries":11,
   "subscriptionPlans":[
      {
         "planReference":"bas",
         "name":"basic",
         "description":"daily basic subscription",
         "interval":"DAILY",
         "hasSubscribers":true,
         "amount":{
            "amount":499
         }
      },
      {
         "planReference":"pre",
         "name":"premium",
         "description":"daily premium subscription",
         "interval":"DAILY",
         "hasSubscribers":true,
         "amount":{
            "amount":999
         }
      }
   ]
}

Request

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
interval	V	no	Possible values are: DAILY WEEKLY FORTNIGHTLY FOUR_WEEKLY MONTHLY QUARTERLY BIANNUALLY YEARLY
trialPeriodRange	J	no	Range object of numeric type with values between 1 and 366 ( {minimum: number, maximum: number} )
pageNumber	N	no	Number of the page that should be returned.
pageSize	N (3)	no	Amount of results returned per page. (1-100)
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
pageNumber	N	Number of the page that was returned.
pageSize	N (3)	Amount of results returned per page. (1-100)
totalEntries	N	The total amount of results.
subscriptionPlans	JA (SubscriptionPlan)	Contains information of all plans that fit the provided parameters.
salt	AN	A random number to guarantee the uniqueness of the message.

getSubscriptionStatus

This call returns the status of a subscription.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/getSubscriptionStatus

Live: https://api.crefopay.de/2.0/getSubscriptionStatus

<?php
function getSubscriptionStatus($subscriptionID) {
    global $requestUrl, $merchantID, $storeID;
​
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'subscriptionID' => $subscriptionID
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully received the status for subscription: {$subscriptionID}.\n\r";
        return responseBody;
    } else {
        echo "We failed to get the status for subscription: {$subscriptionID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult getSubscriptionStatus() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("subscriptionID", "S-100002");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode": 0,
    "salt": "520e21131977c584",
    "userType": "PRIVATE",
    "planReference": "subscrPlan1",
    "nextPayment": {
        "transactionAmount": {
            "amount": 500
        },
        "paymentDate": "2021-03-04"
    },
    "subscriptionStatus": "ACTIVE",
    "subscriptionID": "S-100002",
    "userID": "subscriptionUser1",
    "subscriptionCreationDate": "2021-02-04",
    "subscriptionAmount": {
        "amount": 500
    }
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
subscriptionID	AN (50)	yes	This is a unique identifier for a subscription which is created by the shop.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
salt	AN	A random number to guarantee the uniqueness of the message.
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
subscriptionStatus	V	The status of the subscription referred by the subscription ID. Possible values: NEW USER_PENDING START_PENDING PAUSED CANCELLED ACTIVE DONE
merchantReference	AN (30)	Optional/additional reference for the subscription.
userID	AN (50)	The unique user id of the user.
userType	V	This parameter defines business or private customers. This value cannot be changed after user creation. Type of the subscribed customer. Possible Values: PRIVATE BUSINESS
subscriptionAmount	J (Amount)	Current amount to be charged regularly.
subscriptionCreationDate	D (YYYY-MM-DD)	The date when the in subscription was created
subscriptionStartDate	D (YYYY-MM-DD)	The date when the subscription is scheduled to start. Only returned if the subscription is scheduled to start in the future. Will not be returned in status NEW or USER_PENDING.
firstPaymentDate	D (YYYY-MM-DD)	The date when the first subscription payment was performed, or will be performed. Will not be returned in status NEW or USER_PENDING.
trialPeriod	N (3)	Trial period set for the subscription in days.
planReference	AN (15)	Reference of the subscription plan used to create the subscription.
nextPayment	J (nextPayment)	Returns the amount and the payment date of the next scheduled payment for the subscription. This field will not be set, if no next payment is scheduled, which is the case when the subscription was not confirmed yet (subscriptionStatus=USER_PENDING) is paused (subscriptionStatus=PAUSED) or the subscription was cancelled (subscriptionStatus=CANCELLED).

Subscription status	Description
NEW	The subscription was created.
USER_PENDING	The subscription was created and the customer received an email with a link to complete the subscription.
START_PENDING	The subscription was confirmed by the user, and it is set to trigger the first payment at a future start date.
ACTIVE	The subscription was confirmed by the customer and it is now actively triggering payments in the scheduled interval.
PAUSED	The subscription was paused by the merchant. The regular payment cycle will continue once it was reactivated.
CANCELLED	The subscription was cancelled by the merchant. No further payments will be triggered.
DONE	All scheduled payments for the subscription were performed. Subscriptions with an endless payment cycle will never reach this status.

getSubscriptionTransactions

This call returns a list of all transactions related to a subscription and their status.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/getSubscriptionTransactions

Live: https://api.crefopay.de/2.0/getSubscriptionTransactions

<?php
function getSubscriptionTransactions($subscriptionID) {
    global $requestUrl, $merchantID, $storeID;
​
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'subscriptionID' => $subscriptionID
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully received the transactions for subscription: {$subscriptionID}.\n\r";
        return responseBody;
    } else {
        echo "We failed to get the transactions for subscription: {$subscriptionID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult getSubscriptionTransactions() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("subscriptionID", "1606830285083");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode": 0,
    "salt": "b5f617e981c4571b",
    "transactions": [
        {
            "orderID": "S-103819",
            "transactionStatus": "DONE",
            "creationDate": "2021-01-26",
            "lastStatusChange": "2021-01-26",
            "transactionAmount": {
                "amount": 500
            }
        },
        {
            "orderID": "S-103786",
            "transactionStatus": "DONE",
            "creationDate": "2020-12-29",
            "lastStatusChange": "2020-12-29",
            "transactionAmount": {
                "amount": 500
            }
        },
        {
            "orderID": "1606830285083",
            "transactionStatus": "DONE",
            "creationDate": "2020-12-01",
            "lastStatusChange": "2020-12-01",
            "transactionAmount": {
                "amount": 500
            }
        }
    ]
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
subscriptionID	AN (50)	yes	This is a unique identifier for a subscription which is created by the shop.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
transactions	J (Subscription transactions)	Contains basic information for one or multiple transactions associated to the subscription
salt	AN	A random number to guarantee the uniqueness of the message.
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)

getTransactionPaymentInstruments

This call gets a refreshed list of payment instruments. This is useful if the reserve call fails because of problems with a specific payment instrument or because of fraud rules. This call will only work in TransactionStatus 'NEW' The list of payment instruments returned by this call is the same or less like the list returned by create transaction.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/getTransactionPaymentInstruments

Live: https://api.crefopay.de/2.0/getTransactionPaymentInstruments

<?php
function getTransactionPaymentInstruments($orderID) {
    global $requestUrl, $merchantID, $storeID;
​
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'orderID' => $orderID
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully received the paymentinstrument for order: {$orderID}.\n\r";
        return responseBody;
    } else {
        echo "We failed to get the paymentinstrument for order: {$orderID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult getTransactionPaymentInstruments() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-131");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
   "resultCode":0,
   "salt":"8d83157f738bca24",
   "userData":{
      "name":"Max",
      "surname":"Mustermann",
      "dateOfBirth":"1978-08-15",
      "email":"max@mustermann.de"
   },
   "billingAddress":{
      "street":"Hauptstraße",
      "no":"1",
      "zip":"10827",
      "city":"Berlin",
      "country":"DE"
   },
   "allowedPaymentMethods":[
      "CC",
      "PAYPAL"
   ],
   "allowedPaymentInstruments":[

   ],
   "additionalInformation":[
      {
         "paymentMethodType":"CC",
         "issuer":[
            "VISA",
            "MC"
         ],
         "logos":[
            "VISA",
            "MC"
         ],
         "customTranslations":{

         }
      },
      {
         "paymentMethodType":"PAYPAL",
         "issuer":[

         ],
         "logos":[

         ],
         "customTranslations":{

         }
      },
   ],
   "billingRecipient":"Max Mustermann"
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
userData	J (Person)	Data of the user
billingAddress	J (Address)	Billing address of the user
shippingAddress	J (Address)	Shipping address of the user
companyData	J (Company)	Data of the company
allowedPaymentMethods	JA (PaymentMethods)	List of payment methods that are allowed for this user
allowedPaymentInstruments	JA (PaymentInstrument)	List of valid payment instruments that are registered for this user
redirectUrl	AN (1024)	The URL of the page that should be shown to the user. This is only set if the resultCode is 1
additionalInformation	JA (PaymentMethodInformation)	List of additional informations for presenting the payment instruments to the customer.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

getTransactionStatus

This call returns the status of a transaction.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/getTransactionStatus

Live: https://api.crefopay.de/2.0/getTransactionStatus

<?php
function getTransactionStatus($orderID) {
    global $requestUrl, $merchantID, $storeID;
​
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'orderID' => $orderID
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully received the status for order: {$orderID}.\n\r";
        return responseBody;
    } else {
        echo "We failed to get the status for order: {$orderID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult getTransactionStatus() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-129");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
   "resultCode":0,
   "salt":"9bbc1ca20347517d",
   "transactionStatus":"DONE",
   "additionalData":{
      "paymentMethod":"BILL",
      "paymentReference":"PCB-0000668890",
      "accountHolder":"Max Mustermann",
      "iban":"DE06000000000023456789",
      "bankname":"Postbank",
      "bic":"SFRTDE20000",
      "customerEmail":"max@mustermann.de",
      "transactionAmount":12399,
      "transactionCurrency":"EUR",
      "transactionBalance":0
   },
   "billingAddress": {
      "street": "Teststraße",
      "no": "123",
      "zip": "10961",
      "city": "Berlin",
      "country": "DE",
      "name": "Max Mustermann"
  },
   "shippingAddress": {
      "street": "Teststraße",
      "no": "123",
      "zip": "10961",
      "city": "Berlin",
      "country": "DE",
      "name": "Max Mustermann"
  }
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.
returnRiskData	B	no	Set to 'true' if solvency-check information should be returned in the response
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
transactionStatus	V	The status of the transaction referred by the order ID. Possible values: see Transaction process
riskData	J (RiskData)	This array contains data of all solvency-checks that are connected to the transaction
additionalData	J (TransactionStatusDetail)	Additional information to the transaction. Only set after the transaction was reserved.
billingAddress	J (Address)	The customer's billing address
shippingAddress	J (Address)	The customer's shipping address
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

getUser

This call returns relevant user data. Optionally it may return solvency check information or the balance of the user.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/getUser

Live: https://api.crefopay.de/2.0/getUser

<?php
function getUser($userID) {
    global $requestUrl, $merchantID, $storeID;
​
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'userID' => $userID
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully received the user: {$userID}.\n\r";
        return responseBody;
    } else {
        echo "We failed to get the user: {$userID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult getUser() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("userID", "user-127");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
   "resultCode":0,
   "salt":"c1d5c2585402b44a",
   "userData":{
      "name":"Max",
      "surname":"Mustermann",
      "dateOfBirth":"1978-08-15",
      "email":"max@mustermann.de"
   },
   "billingRecipient":"Max Mustermann",
   "billingAddress":{
      "street":"Hauptstraße",
      "no":"1",
      "zip":"10827",
      "city":"Berlin",
      "country":"DE"
   },
   "shippingRecipient":"Max Mustermann",
   "shippingAddress":{
      "street":"Hauptstraße",
      "no":"1",
      "zip":"10827",
      "city":"Berlin",
      "country":"DE"
   },
   "locale":"DE"
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
userID	AN (50)	yes	The unique user id of the user.
returnUserBalance	B	no	Set to 'true' if the balance of the user should be returned in the response
returnRiskData	B	no	Set to 'true' if solvency-check information should be returned in the response
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
companyData	J (Company)	Contact data of the user's company
userBalance	J (userBalance)	Contains the current balance and total transaction amount of the user
userData	J (Person)	Contact data of the user
billingRecipient	AN	Recipient for the billing address
billingAddress	J (Address)	The person's billing address
shippingRecipient	AN	Recipient for shipping address
shippingAddress	J (Address)	The person's shipping address
lastUsedPaymentInstrumentID	AN	The ID of the payment instrument that was last used by the user
userStatus	V	Possible values: NEW IN_DUNNING IN_COLLECTION NEGATIVE_PAYMENT_EXPERIENCE SUCCESSFUL_DUNNING . This value will only be set if the merchant/shop uses the accredis dunning and collection interface.
riskData	J (RiskData)	This array contains data of all solvency-checks that were requested for this user
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

getUserPaymentInstrument

The getUserPaymentInstrument call adds the functionality to get a user‘s PaymentInstruments.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/getUserPaymentInstrument

Live: https://api.crefopay.de/2.0/getUserPaymentInstrument

<?php
function getUserPaymentInstrument($userID) {
    global $requestUrl, $merchantID, $storeID;
​
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'userID' => $userID
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully received the paymentinstruments for user: {$userID}.\n\r";
        return responseBody;
    } else {
        echo "We failed to get the paymentinstruments for user: {$userID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult getUserPaymentInstrument() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("userID", "user-127");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
   "resultCode":0,
   "salt":"140e15d63d36eba6",
   "paymentInstruments":[
      {
         "paymentInstrumentID":"Aqc9O5SSJuQTDHC9KXFE0Q",
         "paymentInstrumentType":"CREDITCARD",
         "accountHolder":"Max Mustarmann",
         "number":"************1111",
         "validity":"2025-01",
         "issuer":"VISA"
      }
   ]
}

Request

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
userID	AN (50)	yes	The unique user id of the user.
mac	AN 40	yes	Message Authentication Code. See: MAC calculation

Response:

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
paymentInstruments	JA (PaymentInstrument)	List of valid payment instruments that are registered for this user
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

getUserTransactions

This call returns basic information for all transactions of a user.

The result may contain a maximum of 100 transactions. If more than 100 transactions exist for the customer, pagination can be used to fetch more entries.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/getUserTransactions

Live: https://api.crefopay.de/2.0/getUserTransactions

<?php
function getUserTransactions($userID) {
    global $requestUrl, $merchantID, $storeID;
​
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'userID' => $userID
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully received the user transaction data";
        return responseBody;
    } else {
        echo "We failed to get the user transaction data: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult getUserTransactions() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("userID", "user-127");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode": 0,
    "salt": "5f79aa38348dd07b",
    "pageNumber": 1,
    "pageSize": 100,
    "totalEntries": 2,
    "transactions": [
        {
            "orderID": "1709635019797",
            "transactionStatus": "DONE",
            "transactionAmount": 500,
            "transactionBalance": 0,
            "creationDate": "2024-05-03",
            "lastStatusChangeDate": "2024-05-03"
        },
        {
            "orderID": "1709633438801",
            "transactionStatus": "INPROGRESS",
            "transactionAmount": 500,
            "transactionBalance": -500,
            "creationDate": "2024-05-03",
            "lastStatusChangeDate": "2024-05-03"
        }
    ]
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
userID	AN (50)	yes	The unique user id of the user.
pageNumber	N	no	Number of the page that should be returned
pageSize	N (3)	no	Amount of results returned per page (1-100)
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
transactions	J (UserTransactions)	Contains basic information for one or multiple transactions associated to the user
pageNumber	N	Number of the page that was returned
pageSize	N (3)	Amount of results returned per page (1-100)
totalEntries	N	The total amount of results
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

identificationCheck

This API can be used to identify and validate customer data. Both the mandatory fields in the request and the response to this call may vary depending on the product that is configured to perform the identification check.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/identificationCheck

Live: https://api.crefopay.de/2.0/identificationCheck

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
userType	V	yes	This parameter defines business or private customers. This value cannot be changed after user creation. This value cannot be changed after user creation. Possible Values: PRIVATE BUSINESS
userData	J (Person)	see comment	Data of a PRIVATE customer. This field is mandatory if the userType is PRIVATE.
companyData	J (Company)	see comment	Data of a BUSINESS customer. This field is mandatory if the userType is BUSINESS.
address	J (Address)	yes	The address to be checked. While th address object in the request itself is mandatory, the exact fields which it should contain differ depending on the service that will be used. Independent of which service is used the field "country" is always mandatory.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
checkReferenceId	N	Unique reference to the performed check
responseData	J	Contains the raw response data of the address check provider in JSON format
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

payByLink

The PayByLink via API solution allows the creation of payment links based on the provided parameters and to optionally send these automatically to the customer.

Similar to other integration types the createTransaction call is used to initiate a transaction, with the main difference being that less parameters are required. After providing the data several risk checks are performed, which make decisions on which payment methods the customer will be able to select from. Depending on the amount of data provided some risk checks may not be performed.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/createTransaction

Live: https://api.crefopay.de/2.0/createTransaction

<?php
function createTransactionPayByLink($orderID) {
    global $requestUrl, $merchantID, $storeID;

    // Enter all mandatory parameters for creating a transaction here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'orderID' => $orderID,
        'integrationType' => 'HostedPageAfter',
        'context' => 'PAY_BY_LINK',
        'amount' => json_encode(
            array(
                'amount' => '100',
            )
        )
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully created the payByLink order {$orderID}. Amount: {$transactionAmount}\n\r";
        return true;
    } else {
        echo "We failed to created the payByLink order: {$orderID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult createTransactionPayByLink() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 1) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private String getAmount() {
    return Json.createObjectBuilder()
            .add("amount", "12399")
            .build()
            .toString();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-133");
    map.add("integrationType", "HostedPageAfter");
    map.add("context", "PAY_BY_LINK");
    map.add("amount", getAmount());
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode":1,
    "salt":"1647a342d1917ae3",
    "redirectUrl":"https://sandbox.crefopay.de/hosted-pages/5b719933bca0266009608be6"
}

Request

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.
sendPayByLinkEmail	B	no	Decides whether to automatically send the payment link via email to the customer. If set to 'true', it is mandatory to provide an email address of the customer. If set to 'false', no mail delivery will be triggered and no email address is required. If the value is not provided it is set to 'false' by default.
userID	AN 50	no	The unique user id of the user.
integrationType	V	yes	Possible Values: HostedPageAfter A PayByLink transaction requires the integrationType to be set to 'HostedPageAfter'.
autoCapture	B	no	Enable automatic capture directly after the successful reservation, if the parameter is not set, the default is "false"
merchantReference	AN (30)	no	Optional/additional reference for the transaction. This parameter is returned with every call from lynck to the shop.
context	V	yes	Determines if the transaction was initiated during online-checkout process or offline where no direct user interaction happens. Possible Values: PAY_BY_LINK A PayByLink transaction requires the context to be set to 'PAY_BY_LINK'
userType	V	no	This parameter defines business or private customers. This value cannot be changed after user creation.. This value cannot be changed after user creation. Possible Values: PRIVATE BUSINESS If no value is provided it defaults to PRIVATE
userRiskClass	N (1) / D (1.1)	no	Possible values are: 0 -> trusted user 1 -> default risk user 2 -> high risk user Decimal value between 0.0 and 2.0, eg. 1.3 Defaults to 1.0 if the parameter was not provided and also no basketItemRiskClass is set.
userIpAddress	AN (15)	no	The IP address of the customer
companyData	J (Company)	no	Contact data of the user's company. If automatic payment emails should be triggered at least the parameter 'email' has to be provided in the J (Company) object.
userData	J (Person)	no	Contact data of the user. If automatic payment emails should be triggered at least the parameter 'email' has to be provided in the J (Person) object. The field "date of birth" is not mandatory. It's needed for solvency checks and the payment method "bill secure". An absent "date of birth" could cause less payment methods to be offered to the user.
billingRecipient	AN (80)	no	Recipient for the billing address
billingAddress	J (Address)	no	The user's billing address. This field is mandatory if the user was not registered before with this userID
shippingRecipient	AN (80)	no	Recipient for the shipping address
shippingAddress	J (Address)	no	The user's shipping address
amount	J (Amount)	yes	The amount of the basket
basketItems	JA (Basket Item)	no	A detailed list of all basket items
basketValidity	AN (4)	no	m -> minutes, h -> hours, d -> days; Example: one hour: 1h, ten minutes: 10m, two days: 2d - only one unit of time can be provided
hostedPagesTexts	JA (HostedPages text)	no	A list of texts for the hosted page in for different languages for different payment methods
locale	V	no	The locale determines the user’s communication language e.g. for e-mails which will be send to the user or for payment pages. See Languages
additionalPaymentOptions	J (Payment options)	no	additional options
solvencyCheckInformation	J (Solvency check information)	no	result of a solvency check done by the merchant.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK 1 -> redirect any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
redirectUrl	AN	The url of the hosted page that should be shown to the user. This is only set if the resultCode is 1
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

Handling of Packstation addresses

• These type of address is only valid for shipping address
• The “Postnummer” is expected in the field shippingRecipient
• The word “Packstation” is expected in field street of the shippingAddress
• The number of “Packstation” is expected in field number of shippingAddress

refund

The refund call allows the merchant to return money to the user. At least one capture on a transaction is required to perform a refund; therefore the call cannot be used on transactions in status NEW, ACKNOWLEDGEPENDING or MERCHANTPENDING.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/refund

Live: https://api.crefopay.de/2.0/refund

<?php
function refund($orderID, $captureID, $transactionAmount, $refundDescription) {
    global $requestUrl, $merchantID, $storeID;
​
    $amount = json_encode(array('amount' => $transactionAmount));
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'orderID' => $orderID,
        'captureID' => $captureID,
        'refundDescription' => $refundDescription,
        'amount' => $amount
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully refunded the order {$orderID}. Amount: {$transactionAmount}\n\r";
        return true;
    } else {
        echo "We failed to refund the order: {$orderID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult refund() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private String getAmount() {
    return Json.createObjectBuilder()
            .add("amount", "12399")
            .build()
            .toString();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-129");
    map.add("captureID", "capture-129");
    map.add("refundDescription", "refund");
    map.add("amount", getAmount());
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode":0,
    "salt":"b414f1f508e0d653"
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.
captureID	AN (50)	yes	This is the unique reference of a capture or a partial capture (e.g. the invoice number).
refundDescription	AN (256)	yes	Description to be shown to the end user on the refund
amount	J (Amount)	yes	The amount of the refund
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

registerUser

The registerUser call adds the functionality to register a new user.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/registerUser

Live: https://api.crefopay.de/2.0/registerUser

public lynckResult registerUser() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private String getUserData() {
    return Json.createObjectBuilder()
            .add("name", "Max")
            .add("surname", "Mustermann")
            .add("dateOfBirth", "1978-08-15")
            .add("email", "max@mustermann.de")
            .build()
            .toString();
}

private String getBillingAddress() {
    return Json.createObjectBuilder()
            .add("street", "Hauptstraße")
            .add("no", "1")
            .add("zip", "10827")
            .add("city", "Berlin")
            .add("country", "DE")
            .build()
            .toString();
}


private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("userID", "user-123");
    map.add("userType", "PRIVATE");
    map.add("userRiskClass", "0");
    map.add("userData", getUserData());
    map.add("billingAddress", getBillingAddress());
    map.add("email", "max@mustermann.de");
    map.add("locale", "DE");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode":0,
    "salt":"029ebe3a1ea785e0"
}

Request

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
userID	AN (50)	yes	The unique user id of the user.
userType	V	yes	This parameter defines business or private customers. This value cannot be changed after user creation.. This value cannot be changed after user creation. Possible Values: PRIVATE BUSINESS
companyData	J (Company)	see comment	Information about the user's company. This field is mandatory if the userType is BUSINESS and the userID was not registered before
userData	J (Person)	see comment	Information about the user. This field is mandatory if the userType is PRIVATE and the userID was not registered before
creditLimit	J (Amount)	no	If this field is provided then the value is saved as specific credit limit for this customer only.
billingRecipient	AN (80)	no	Recipient for the billing address.
billingAddress	J (Address)	see comment	The user's billing address. This field is mandatory if the user was not registered before with this userID
shippingRecipient	AN (80)	no	Recipient for the shipping address
shippingAddress	J (Address)	no	The user's shipping address
solvencyCheckInformation	J (Solvency check information)	no	Result of a solvency check done by the merchant.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

registerUserPaymentInstrument

The registerUserPaymentInstrument call adds the functionality to register a payment instrument to a user.

Anyone involved with the processing, transmission, or storage of credit card data must comply with the Payment Card Industry Data Security Standards PCI DSS. If your system is not compliant please a different ingetration type, see: Integration options.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/registerUserPaymentInstrument

Live: https://api.crefopay.de/2.0/registerUserPaymentInstrument

public lynckResult registerUserPaymentInstrument() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private String getPaymentInstrumentString() {
    return Json.createObjectBuilder()
            .add("paymentInstrumentType", "CREDITCARD")
            .add("accountHolder", "John Doe")
            .add("number", "4111111111111111")
            .add("validity", "2025-01")
            .add("issuer", "VISA")
            .build()
            .toString();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("userID", "user-127");
    map.add("paymentInstrument", getPaymentInstrumentString());
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode":0,
    "salt":"17cb8cb80c38a7c8",
    "paymentInstrumentID":"Aqc9O5SSJuQTDHC9KXFE0Q"
}

Request

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
userID	AN (50)	yes	The unique user id of the user.
paymentInstrument	J (PaymentInstrument)	yes	The payment instrument to register. The PaymentInstrumentID has to be empty
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response:

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
paymentInstrumentID	AN 20	Unique ID for this payment instrument, to be used in the reserve API
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

reportFraudUser

The reportFraudUser call reports a customer as fraudulent. This will set their status to "FRAUD" and prevent them and all users that can be associated to them to complete any further purchases. Optionally you may chose to close all open transactions of this customer. If this is done, then all open or pending transactions of this customer will be closed, and all dunning and collection processes will be stopped. All transactions in status CIAPENDING, MERCHANTPENDING or INPROGRESS are considered open transactions.

For transactions which have an open dunning or collection file at Accredis, the closure of the transaction and the dunning/collection file will be pending and may take up to 2 business days.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/reportFraudUser

Live: https://api.crefopay.de/2.0/reportFraudUser

<?php
function reportFraudUser($userID, $closeTransactions) {
    global $requestUrl, $merchantID, $storeID;
​
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'userID' => $userID,
        'closeTransactions' => $closeTransactions
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully reported the user: {$userID}.\n\r";
        return responseBody;
    } else {
        echo "We failed to report the user: {$userID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult reportFraudUser() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("userID", "exampleUser111");
    map.add("closeTransactions", true);
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode": 0,
    "salt": "0b466141b307ec76",
    "closedTransactions": [
        {
            "orderId": "1612465866966",
            "closureStatus": "SUCCESS",
            "previousTransactionStatus": "INPROGRESS",
            "newTransactionStatus": "FRAUDCANCELLED",
            "creationDate": "2021-02-04",
            "transactionAmount": {
                "amount": 0
            }
        },
        {
            "orderId": "1612465852295",
            "closureStatus": "SUCCESS",
            "previousTransactionStatus": "CIAPENDING",
            "newTransactionStatus": "FRAUDCANCELLED",
            "creationDate": "2021-02-04",
            "transactionAmount": {
                "amount": 500
            }
        },
        {
            "orderId": "1612465761342",
            "closureStatus": "SUCCESS",
            "previousTransactionStatus": "MERCHANTPENDING",
            "newTransactionStatus": "FRAUDCANCELLED",
            "creationDate": "2021-02-04",
            "transactionAmount": {
                "amount": 500
            }
        }
    ]
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
userID	AN (50)	yes	The unique user id of the user.
closeTransactions	B	no	Set to 'true' if all open transactions of the user should be closed. Default value: false
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.
closedTransactions	J (closedTransactions)	Contains basic information about all closed transactions related to the customer. Only provided if transactions were closed

reserve

A reserve call on a transaction signals that the customer confirmed their purchase and selected a specific payment method and/or payment instrument.

If the call succeeds with resultCode 0, the transaction will transition into status MerchantPending or CIAPending, depending on the selected payment method, and whether the funds are immediately available for capture.

If the call succeeds with resultCode 1, the customer needs to be redirected to the provided redirectUrl, usually for further authentication. On success, they will be redirected to the success URL configured for the shop, and the transaction will transition into status MerchantPending or CIAPending. On failure they will be redirected to the failure URL configured for the shop. For more information about callbacks see: Callback

If a reserve call failed with resultCode not being 0 or 1, then it is required to call getTransactionPaymentInstruments if another purchase attempt is to be made using the same transaction. This returns an updated list of the available payment methods and payment instruments of the transaction.

If the option "autoCapture" was enabled within the createTransaction call of the transaction being reserved, a capture call does not have to be performed afterwards; instead the lynck system will automatically create a capture with the orderID as captureID.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/reserve

Live: https://api.crefopay.de/2.0/reserve

<?php
function reserve($orderID, $paymentMethod) {
    global $requestUrl, $merchantID, $storeID;
​
    // Enter all mandatory parameters here
    $param = array(
        'merchantID' => $merchantID,
        'storeID' => $storeID,
        'orderID' => $orderID,
        'paymentMethod' => $paymentMethod
    );
​
    // Add calculated MAC to params
    $param['mac'] = getMac($param);
​
    // Create POST body
    $postData = http_build_query($param);
    // Build your own communication function
    $responseBody = sendRequest($postData, $requestUrl); // Returns an object
    if($responseBody === false) {
        return false;
    }
​
    // Collect resultCode from response object
    $resultCode = $responseBody->resultCode;
​
    if ($resultCode === 0) {
        echo "We successfully reserved the order: {$orderID}.\n\r";
        return responseBody;
    } else {
        echo "We failed to reserve the order: {$orderID}\n\rlynck Errormessage: {$responseBody->message}\n\r";
        return false;
    }
}
?>

public lynckResult reserve() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-125");
    map.add("paymentMethod", "BILL");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
   "resultCode":0,
   "salt":"cae2f36e6c251692",
   "additionalData":{
      "bankname":"Postbank",
      "bic":"SFRTDE20000",
      "iban":"DE06000000000023456789",
      "bankAccountHolder":"Max Mustermann",
      "paymentReference":"PCB-0000668888"
   }
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.. The subscriptionID of a subscription will be accepted as well.
paymentMethod	V	yes	The payment method that should be used. See: supported PaymentMethods
paymentInstrumentID	AN (20)	no	The unique ID of the payment instrument. This ID is created by lynck. Required for payment method CC, CC3D, DD.
paymentToken	JSON	no	Payment token as provided by Google Pay. Mandatory when reserving transactions with payment method GOOGLE_PAY.
additionalInformation	J (ReserveInformationRequest)	no	Additional information needed for some payment methods.
returnExternalErrorDetails	B	no	If set to true, then the response may contain a field externalErrorDetails. This field contains error codes from the related service provider which may be used to identify why the reservation failed. Only supported for payment methods CC, CC3D and PAYPAL.
amount	J (Amount)	no	The amount of the basket. If this field is set, it will overwrite the amount that was set in the createTransaction call
basketItems	JA (Basket Item)	no	A detailed list of all basket items. If this field is set, it will overwrite the basketItems that were set in the createTransaction call
cvv	AN (4)	no	CVV for credit card transactions.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response:

Field	Type	Comments
resultCode	N	0 -> OK 1 -> redirect any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
redirectUrl	AN	Will only be returned if the user has to be redirected to the website of a third party payment provider like CC3D, PAYPAL or SU (Sofort)
additionalData	J (ReserveInformationResponse)	Additional information will be set only in case of PREPAID, BILL and BILL_SECURE Payments
errorDetails	J (ErrorDetails)
externalErrorDetails	J (ExternalErrorDetails)	This field contains error codes from the related service provider which may be used to identify why the reservation failed
salt	AN	A random number to guarantee the uniqueness of the message.

solvencyCheck

The solvencyCheck call allows the merchant to perform solvency checks on business customers independent of the transaction workflow.

The response to the solvencyCheck call will contain a score that is returned based on the solvency check configuration in the lynck system. If exact check report data is required, the results can be fetched using the getUser call. Similar to createTransaction, this call will act as registerUser or updateUser call if an unknown/known userID is provided.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/solvencyCheck

Live: https://api.crefopay.de/2.0/solvencyCheck

public lynckResult solvencyCheck() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private String getUserData() {
    return Json.createObjectBuilder()
            .add("name", "Max")
            .add("surname", "Mustermann")
            .add("dateOfBirth", "1978-08-15")
            .add("email", "max@mustermann.de")
            .build()
            .toString();
}

private String getBillingAddress() {
    return Json.createObjectBuilder()
            .add("street", "Hauptstraße")
            .add("no", "1")
            .add("zip", "10827")
            .add("city", "Berlin")
            .add("country", "DE")
            .build()
            .toString();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("userID", "user-127");
    map.add("userType", "PRIVATE");
    map.add("userData", getUserData());
    map.add("billingAddress", getBillingAddress());
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode":0,
    "checkResult":0,
    "salt":"e59bb022501b780c",
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
userID	AN (50)	yes	The unique user id of the user.
userType	V	yes	This parameter defines business or private customers. This value cannot be changed after user creation. This value cannot be changed after user creation. Possible Values: PRIVATE BUSINESS
companyData	J (Company)	see comment	Contact data of the user's company. This field is mandatory if the userType is BUSINESS and the userID was not registered before
userData	J (Person)	see comment	Contact data of the user. This field is mandatory if the userType is PRIVATE and the userID was not registered before
billingAddress	J (Address)	see comment	The user's billing address. This field is mandatory if if user was not registered before with this userID
billingRecipient	AN (80)	no	Recipient for the Bill.
returnRiskData	B	no	Set to 'true' if solvency-check information should be returned in the response
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
checkResult	N	0 -> Low risk, accept user 1 -> Medium risk, restrict user 2 -> High risk, decline user
riskData	J (RiskData)	Contains data of the solvency-check that was performed for this solvencyCheck API request
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

status

This call returns the status of the lynck system and can be used as health-check. If the status is UP, all core systems are running.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/status

Live: https://api.crefopay.de/2.0/status

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response:

Field	Type	Comments
status	AN	UP -> All core services running DOWN -> One or more core services are down. transaction processing is interrupted
degradation	JA	If this Json array is present, one or more minor systems have problems, but the main transaction processing does still work. Possible values are: Processing of order status changes delayed Sending of notifications interrupted Merchant Service Area not or only partially available Statistics updates delayed Processing of subscriptions interrupted Processing of terminal transactions interrupted Secure fields checkout interrupted Credit card processing interrupted

updateInvoice

With updateInvoice, it is possible to send additional invoice information for an existing transaction, if e.g. the invoice data for a transaction is only generated by the ERP system after checkout. The provision of invoice date is necessary, if you also want to process dunning and debt collection via the lynck partner, since the call centre of the debt collection agency requires this data for information provision purposes. Furthermore, you can also transmit the due date for account purchases and overwrite the preset due date individually for every transaction.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/updateInvoice

Live: https://api.crefopay.de/2.0/updateInvoice

public lynckResult updateInvoice() {
    final LinkedMultiValueMap<String, Object> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendMultipartPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private String getAmount() {
    return Json.createObjectBuilder()
            .add("amount", "12399")
            .build()
            .toString();
}

private FileSystemResource getInvoice() {
    return new FileSystemResource("/tmp/file.pdf");
}

private LinkedMultiValueMap<String, Object> getRequestMap() {
    LinkedMultiValueMap<String, Object> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-129");
    map.add("captureID", "capture-129");
    map.add("invoiceNumber", "invoice-1");
    map.add("invoiceDate", "2018-01-01");
    map.add("originalInvoiceAmount", getAmount());
    map.add("dueDate", "2018-03-01");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));

    //the invoicePDF is not part of the mac
    map.add("invoicePDF", getInvoice());
    return map;
}

Response:
{
    "resultCode":0,
    "salt":"b3035fc8a72cb252"
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.
captureID	AN (50)	yes	This is the unique reference of a capture or a partial capture (e.g. the invoice number).
invoiceNumber	AN (50)	yes	The invoice number
invoiceDate	D (YYYY-MM-DD)	no	The date when the in voice was created. Is set to capture date if not provided
originalInvoiceAmount	J (Amount)	no	The original amount of the invoice. Please refer also to the information box below
dueDate	D (YYYY-MM-DD)	no	Payment date of the invoice. The due date cannot be smaller or equal to the invoice date
paymentTarget	D (YYYY-MM-DD)	no	Only relevant, if payment method is Bill: payment target to pay the invoice. Please refer also to the information box below
shippingDate	D (YYYY-MM-DD)	no	The shipping date of the order
trackingID	AN (50)	no	The tracking ID of the sending
remark	AN (500)	no	Free text field to pass additional information like article numbers etc. so that the collection agency can see, which item is associated with the dunning process
invoicePDF	Multipart attachment	no	The original invoice as PDF. This parameter has to be ignored for the mac calculation
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

updateSubscription

The updateSubscription call is used to update the charge rate or interval, cancel an active subscription or request the customer to change their payment method.

For subscriptions that were completed using the PayPal Subscriptions solution, only the action CANCEL is available.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/updateSubscription

Live: https://api.crefopay.de/2.0/updateSubscription

public lynckResult updateSubscription() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("subscriptionID", "subscription-134");
    map.add("action", "CHANGE_RATE");
    map.add("rate", "200");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode":0,
    "salt":"01ebbd8ccb51b8d9"
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
subscriptionID	AN (50)	yes	This is a unique identifier for a subscription which is created by the shop.
action	V	yes	Possible Values: CHANGE_RATE CHANGE_INTERVAL RETRY_PAYMENT CANCEL UPDATE_PAYMENT_EMAIL UPDATE_PAYMENT_LINK UPDATE_PAYMENT_SECURE_FIELDS
changeIntervalTime	V	no	Defines when the interval change should apply. Only required if the action is CHANGE_INTERVAL. Possible Values: IMMEDIATE AFTER_NEXT_PAYMENT
interval	V	no	Interval to which the subscription interval should be updated to. Only required if the action is CHANGE_INTERVAL. Possible values: DAILY WEEKLY FORTNIGHTLY THREE_WEEKLY FOUR_WEEKLY MONTHLY QUARTERLY BIANNUALLY YEARLY
rate	N (9)	no	Amount to which the subscription rate should be updated to. Only required if the action is CHANGE_RATE
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
redirectUrl	AN	Only returned for action UPDATE_PAYMENT_LINK.
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

Retrying failed payments

The action RETRY_PAYMENT will trigger new payments for all previous payment attempts which failed. Therefore this action can be used to collect all outstanding payments for a single subscription.

RETRY_PAYMENT is only allowed for subscription in status active, paused and done. Once the action was used, it cannot be used again until the resulting payments are resolved.

Changing the subscription interval

The action CHANGE_INTERVAL will apply depending on the selected changeIntervalTime.

After next payment

If changeIntervalTime was set to AFTER_NEXT_PAYMENT, then the selected interval will be applied only after the next scheduled payment was executed.

Immediate

If changeIntervalTime was set to IMMEDIATE, then selected interval will be applied immediately. If the new interval is smaller than the previously set interval, then it is possible that multiple payments can be triggered in a row. The next payment date will be set using the newly selected interval based on the last successful payment.

Changing the payment method

To change the payment method of an active subscription it is required that the customer selects and confirms their new payment method. To this end three different actions can be triggered, which allow the customer to do so in different ways. With all three methods a new 0-amount transaction is automatically created in the lynck system which serves to register and authorize the new payment method or payment instrument.

UPDATE_PAYMENT_EMAIL

This action will trigger an email to the customer associated with the subscription. In this email the customer will receive a link that can be used to change the payment method of the subscription. No further action is required by the merchant.

UPDATE_PAYMENT_LINK

This action will return a link to a payment page directly in the response to the updateSubscription call. This link is identical to the link provided in the email triggered by the action UPDATE_PAYMENT_EMAIL. It should be provided to the customer to select and confirm their new payment method. This could be done by either delivering the link through a messaging service or by loading the link within an iFrame inside the shop.

Example response for action UPDATE_PAYMENT_SECUREFIELDS:
{
    "resultCode": 0,
    "salt": "196cfb042e979ba9",
    "orderID": "S-100002",
    "userData": {
        "salutation": "M",
        "name": "Max",
        "surname": "Mustermann",
        "email": "mustermann@lynck.de"
    },
    "billingAddress": {
        "street": "Schloßstr.",
        "no": "20",
        "zip": "12163",
        "city": "Berlin",
        "country": "DE"
    },
    "allowedPaymentMethods": [
        "PAYPAL",
        "CC3D",
        "DD"
    ],
    "allowedPaymentInstruments": [],
    "additionalInformation": [
        {
            "paymentMethodType": "PAYPAL"
        },
        {
            "paymentMethodType": "CC3D",
            "issuer": [
                "VISA",
                "MC"
            ],
            "logos": [
                "VISA",
                "MC"
            ]
        },
        {
            "paymentMethodType": "DD",
            "sepaPaymentType": "RCUR",
            "mandateReference": "10",
            "creditorId": "DE98ZZZ09999999999",
            "merchantName": "TestMerchant",
            "date": "May 17, 2021"
        }
    ],
    "billingRecipient": "Max Mustermann"
}

UPDATE_PAYMENT_SECUREFIELDS

This action will cause the updateSubscription response to return transaction details similar to the createTransaction API, including an orderID, allowed payment methods and allowed payment instruments. The returned orderID should be used to initialize the SecureFields library in a shop frontend. After the customer selected their preferred payment method or payment instrument using the SecureFields, the transaction needs to be reserved using the reserve API, similar to a regular lynck transaction.

updateTransactionData

With updateTransactionData the merchantReference of a transaction can be set or updated. The merchantReference can be used as an alternative for automated payment matching if the paymentReference provided by lynck can not be forwarded to customers. In this case it is advisable to update the merchantReference of the transaction to whatever value was given to the customer as payment reference for their bank transfer.

This call may be extended in the future to allow further modification of transaction data.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/updateTransactionData

Live: https://api.crefopay.de/2.0/updateTransactionData

public lynckResult updateTransactionData() {
    final LinkedMultiValueMap<String, Object> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendMultipartPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private LinkedMultiValueMap<String, Object> getRequestMap() {
    LinkedMultiValueMap<String, Object> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("orderID", "order-129");
    map.add("merchantReference", "bill-501234");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode": 0,
    "salt": "250ffaf62f444faa",
    "updatedData": {
        "merchantReference": {
            "oldValue": "oldMerchantReference",
            "newValue": "bill-501234"
        }
    }
}

Request:

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
orderID	AN (50)	yes	This is a unique identifier for a transaction which is created by the shop.
merchantReference	AN (30)	no	Optional/additional reference for the transaction. This parameter is returned with every call from lynck to the shop.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
updatedData	J (UpdatedData)	Contains the fields that were updated, their new values (newValue), and the old values if any were overwritten (oldValue). Only set if any fields were updated.
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

updateUser

The updateUser call adds the functionality to update a user's details like billing and or delivery address.

URL:

Sandbox: https://sandbox.crefopay.de/2.0/updateUser

Live: https://api.crefopay.de/2.0/updateUser

public lynckResult updateUser() {
    final MultiValueMap<String, String> map = getRequestMap();
    ResponseEntity<lynckResult> response = restTemplateService.sendPostRequest(url, map);
    if (response.getStatusCode() != HttpStatus.OK || response.getBody().getResultCode() > 0) {
        throw new RuntimeException(response.getBody().getMessage());
    }
    return response.getBody();
}

private String getBillingAddress() {
    return Json.createObjectBuilder()
            .add("street", "Hauptstraße")
            .add("no", "3")
            .add("zip", "10827")
            .add("city", "Berlin")
            .add("country", "DE")
            .build()
            .toString();
}


private MultiValueMap<String, String> getRequestMap() {
    MultiValueMap<String, String> map = new LinkedMultiValueMap<>();
    map.add("merchantID", merchantID);
    map.add("storeID", storeID);
    map.add("userID", "user-127");
    map.add("userType", "PRIVATE");
    map.add("userRiskClass", "0");
    map.add("billingAddress", getBillingAddress());
    map.add("email", "max@mustermann.de");
    map.add("locale", "DE");
    map.add("mac", macCalculator.calculateAndGetMAC(map, merchantPassword));
    return map;
}

Response:
{
    "resultCode":0,
    "salt":"d8bff4bbec235087"
}

Request

Field	Type	Mandatory	Comments
merchantID	N (16)	yes	This is the merchant ID assigned by lynck.
storeID	AN (60)	yes	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
userID	AN (50)	yes	The unique user id of the user.
userType	V	yes	This parameter defines business or private customers. This value cannot be changed after user creation.. This value cannot be changed after user creation. Possible Values: PRIVATE BUSINESS
userRiskClass	N (1)	no	Possible values are: 0 -> trusted user 1 -> default risk user 2 -> high risk user Defaults to 1.0 if neither userRiskClass nor basketItemRiskClass were set. If basketItemRiskClass is set, userRiskClass will default to that value instead.
companyData	J (Company)	see comment	Contact data of the user's company. This field is mandatory if the userType is BUSINESS and the userID was not registered before
userData	J (Person)	see comment	Contact data of the user. This field is mandatory if the userType is PRIVATE and the userID was not registered before
creditLimit	J (Amount)	no	If this field is provided then the value is saved as specific credit limit for this customer only. Any previously saved credit limit will be overwritten.
billingRecipient	AN (80)	no	Recipient for the billing address
billingAddress	J (Address)	see comment	The user's billing address. This field is mandatory if if user was not registered before with this userID
shippingRecipient	AN (80)	no	Recipient for the shipping address
shippingAddress	J (Address)	no	The user's shipping address
locale	V	yes	The locale determines the user’s communication language e.g. for e-mails which will be send to the user or for payment pages. See Languages
solvencyCheckInformation	J (Solvency check information)	no	Result of a solvency check done by the merchant.
mac	AN (40)	yes	Message Authentication Code. See: MAC calculation

Response

Field	Type	Comments
resultCode	N	0 -> OK any other code -> see errorcodes
message	AN	This parameter contains details about an error, otherwise it will left as empty.
errorDetails	JA (ErrorDetails)
salt	AN	A random number to guarantee the uniqueness of the message.

SecureFields

Prerequisites

The JavaScript library must be included in the page using the following snippet:

//For use on the production environment
<script src="https://api.crefopay.de/libs/3.0/secure-fields.js"></script>

//For use on the sandbox environment
<script src="https://sandbox.crefopay.de/libs/3.0/secure-fields.js"></script>

//For use on the production environment (deprecated)
<script src="https://libs.crefopay.de/3.0/secure-fields.js"></script>

SecureFields process description

The SecureFields Solution can be used in with the Integration option "SecureFields". This includes the usual process of creating a transaction and reserving it with the PaymentInstrument. After creating the transaction the SecureFields JavaScript library needs to be initialized. This is usually done when the customer enters the payment selection page. As soon as the initialization of the library and the creation of a session for submitting credit card and bank data with the HostedFields is completed, you will receive a response in the registered callback function.

After the customer selected the payment method the registerPayment function of the library should be called. It's not necessary to actively pass the selected payment method, because the library will recognize and transfer the selection based on the set data-attributes. After selecting and registering the payment the API response contained in the callback function needs to be handled. As mentioned, the response of the API might not always be a successful message. In case of an error it will contain information about missing data or any other errors that may occur during payment method/instrument registration. In case of a successful payment method selection the checkout process can be continued. Now the reserve call can be performed on the transaction, after the customer confirmed their purchase on the order confirmation page.

Registration of new payment instruments

The most important feature of the SecureFields solution is to securely collect bank account and credit card data from the customer, without storing them on the merchants shop environment. This severely reduces the security measures required for the shop and allows the merchant to accept credit card payments without full PCI certification.

The SecureFields library offers two methods to collect this data:

• Placeholder elements which are filled with hosted fields/iframes and marked input fields
  • Allows for a seamless integration into the shop
  • Requires implementation of field validation error handling
• An overlay input form
  • Allows for an easier integration by handling validation and form frontend
  • Requires an overlay form to be displayed

Placeholder elements and input fields

<div>
  <label><input type="radio" data-crefopay="paymentMethod" name="paymentMethodSelect" value="PREPAID">Cash in advance</label><br>
</div>
<div>
  <label><input type="radio" data-crefopay="paymentMethod" name="paymentMethodSelect" value="BILL">Bill payment</label><br>
</div>
<div>
  <label><input type="radio" data-crefopay="paymentMethod" name="paymentMethodSelect" value="DD">Direct debit</label><br>
  <label>Account holder: <input type="text" data-crefopay="paymentInstrument.bankAccountHolder" placeholder="John Doe"></label><br>
  <label>IBAN: <input type="text" data-crefopay="paymentInstrument.iban" placeholder="DE12 3456 7890 1112 1314"></label><br>
  <label>BIC: <input type="text" data-crefopay="paymentInstrument.bic" placeholder="SFRTDE20000"></label><br>
  <label><input type="radio" data-crefopay="paymentInstrument.id" name="savedPaymentInstrumentSelect" value="Aqc9O5SSJuQTDHC9KXFE0Q">Registered bank account (IBAN: DE12 3456 7890 1112 1314)</label>
  <label><input type="radio" data-crefopay="paymentInstrument.id" name="savedPaymentInstrumentSelect" value="y6hijnZJt38FeNPUFM2E6g">Registered bank account (IBAN: DE65 4321 4131 2111 5432)</label>
</div>
<div>
  <label><input type="radio" data-crefopay="paymentMethod" name="paymentMethodSelect" value="CC">Creditcard</label><br>
  <span>Accountholder: </span>
  <div data-crefopay-placeholder="paymentInstrument.accountHolder"></div>
  <span>Number: </span>
  <div data-crefopay-placeholder="paymentInstrument.number"></div>
  <span>Validity: </span>
  <div data-crefopay-placeholder="paymentInstrument.validity"></div>
  <span>CVV: </span>
  <div data-crefopay-placeholder="paymentInstrument.cvv"></div>
  <label><input type="radio" data-crefopay="paymentInstrument.id" name="savedPaymentInstrumentSelect" value="lt-vfbxBlSffx0e6QQ_hpg">Registered creditcard (Number: 12***********3456)</label>
  <label><input type="radio" data-crefopay="paymentInstrument.id" name="savedPaymentInstrumentSelect" value="t_QOm8SvkGWaChoYeI0rrg">Registered creditcard (Number: 65***********4321)</label>
</div>
<div>
  <label><input type="radio" data-crefopay="paymentMethod" name="paymentMethodSelect" value="PAYPAL">PayPal</label><br>
</div>
<div>
  <label><input type="radio" data-crefopay="paymentMethod" name="paymentMethodSelect" value="SU">Sofort</label><br>
</div>
<div>
  <label><input type="radio" data-crefopay="paymentMethod" name="paymentMethodSelect" value="CC3D">Creditcard 3D-secure</label><br>
  <span>Accountholder: </span>
  <div data-crefopay-placeholder="paymentInstrument.accountHolder"></div>
  <span>Number: </span>
  <div data-crefopay-placeholder="paymentInstrument.number"></div>
  <span>Validity: </span>
  <div data-crefopay-placeholder="paymentInstrument.validity"></div>
  <span>CVV: </span>
  <div data-crefopay-placeholder="paymentInstrument.cvv"></div>
</div>
<div>
  <label><input type="radio" data-crefopay="paymentMethod" name="paymentMethodSelect" value="COD">Cash on delivery</label><br>
</div>

For the SecureFields library to find the selected payment method as well as the placeholders for the secure fields, several HTML-data-attributes have to be set. These should generally begin with data-crefopay. The following attributes can be set:

data-crefopay

Attribute value	Description
paymentMethod	Marks PaymentMethods, should be used in combination with a radio button input or similar, as only one payment method can be selected.
paymentInstrument.id	Identifies an existing PaymentInstrument ( bank account / credit card ). Can be used to allow customers to re-use already registered payment instruments.
paymentInstrument.bankAccountHolder	Marks the field for the bank account holder.
paymentInstrument.iban	Marks the fields for the IBAN.
paymentInstrument.bic	Marks the field for the BIC.

data-crefopay-placeholder

Attribute value	Description
paymentInstrument.accountHolder	Placeholder for the card-holder name.
paymentInstrument.number	Placeholder for the credit card number.
paymentInstrument.validity	Placeholder for the credit card validity date.
paymentInstrument.cvv	Placeholder for the CVV of the credit card.

Overlay with input fields

As an alternative to the paymentInstrument placeholders and input fields, it is possible to collect both credit card and bank account data using an overlay widget, in which a pre-built input form is displayed to the customer. To use the overlay solution the fields ccOverlay or ddOverlay must be set to 'true' in the configuration object used to initialize the SecureFields library.

The overlay is displayed to the customer once their payment method selection was confirmed using secureFieldsClientInstance.registerPayment().

The overlay will handle field validation and also allow customers to select previously registered payment instruments. Once a valid new payment instrument was registered, or an existing payment instrument was selected, the paymentRegisteredCallback function is called with resultCode=0. If the user closed the overlay window without selecting a payment instrument, the paymentRegisteredCallback function is called with resultCode=6005 and message="cancelled by user".

Initialization

To initialize the library, an instance of the SecureFieldsClient needs to be created. An example and a list of arguments for the initialization follow:

var secureFieldsClientInstance =
    new SecureFieldsClient(shopPublicKey,
                           orderID,
                           paymentRegisteredCallback,
                           initializationCompleteCallback,
                           configuration);

Argument	Description
shopPublicKey	Will be provided by lynck
orderID	Reference to the transaction, set by the merchant in createTransaction. Alternatively the subscriptionID of a subscription, set in createSubscription, can be provided as well.
paymentRegisteredCallback	This function will be be called after registration of a payment method and receives the API response of lynck as argument.
initializationCompleteCallback	This function will be called right after the secure fields initialization and receives the API response of lynck as argument.
configuration	This argument may be used to provide placeholders for the secure fields or select a different endpoint for the requests. Details follow below (see Secure Fields Configuration)

Registering the payment method

After initialization of an instance of the SecureFieldsClient and successful session creation a payment method can be registered as follows:

secureFieldsClientInstance.registerPayment();

Upon calling the registerPayment function the SecureFields library will scan the page for any elements with the data-crefopay attribute set to "paymentMethod". If more than one element can be found, it will only recognize the "checked" element. Therefore it should be ensured that only one element with the attribute data-crefopay="paymentMethod" can be selected at any time. If only one element can be found, it does not need to be "checked"/selected.

After executing this function the paymentRegisteredCallback function will be called automatically to process the lynck API response. It's recommended to check the resultCode of the response first, to differentiate between failure and success:

function paymentRegisteredCallback(response) {
    if (response.resultCode === 0) {
        // Successful registration, continue to next page using JavaScript
    } else {
        // Error during registration, check the response for more details and dynamically show a message for the customer or perform other actions
    }
}

Display and selection of already registered credit cards and bank accounts

<div>
  <label><input type="radio" data-crefopay="paymentMethod" name="paymentMethodSelect" value="DD">Direct debit</label><br>
  <label>Account holder: <input type="text" data-crefopay="paymentInstrument.bankAccountHolder" placeholder="John Doe"></label><br>
  <label>IBAN: <input type="text" data-crefopay="paymentInstrument.iban" placeholder="DE12 3456 7890 1112 1314"></label><br>
  <label>BIC: <input type="text" data-crefopay="paymentInstrument.bic" placeholder="SFRTDE20000"></label><br>
  <label><input type="radio" data-crefopay="paymentInstrument.id" name="savedPaymentInstrumentSelect" value="Aqc9O5SSJuQTDHC9KXFE0Q">Registered bank account (IBAN: DE12 3456 7890 1112 1314)</label>
  <label><input type="radio" data-crefopay="paymentInstrument.id" name="savedPaymentInstrumentSelect" value="y6hijnZJt38FeNPUFM2E6g">Registered bank account (IBAN: DE65 4321 4131 2111 5432)</label>
</div>
<div>
  <label><input type="radio" data-crefopay="paymentMethod" name="paymentMethodSelect" value="CC">Creditcard</label><br>
  <span>Accountholder: </span>
  <div data-crefopay-placeholder="paymentInstrument.accountHolder"></div>
  <span>Number: </span>
  <div data-crefopay-placeholder="paymentInstrument.number"></div>
  <span>Validity: </span>
  <div data-crefopay-placeholder="paymentInstrument.validity"></div>
  <span>CVV: </span>
  <div data-crefopay-placeholder="paymentInstrument.cvv"></div>
  <label><input type="radio" data-crefopay="paymentInstrument.id" name="savedPaymentInstrumentSelect" value="lt-vfbxBlSffx0e6QQ_hpg">Registered creditcard (Number: 12***********3456)</label>
  <label><input type="radio" data-crefopay="paymentInstrument.id" name="savedPaymentInstrumentSelect" value="t_QOm8SvkGWaChoYeI0rrg">Registered creditcard (Number: 65***********4321)</label>
</div>

This section is only relevant if you use your own placeholder elements and input fields, as the overlay solution will automatically handle this step.

For a better checkout experience it is recommended to display already registered payment instruments such as credit cards and bank accounts, so that customers do not have to repeatedly enter their data. To submit existing payment instruments the attribute data-crefopay="paymentInstrumentId" should be set, with the value being the paymentInstrumentId of the registered card or bank account.

Upon calling the registerPayment function the SecureFields library will scan the page for any elements with the data-crefopay attribute set to "paymentMethod" and "paymentInstrument.id". Specifically for "paymentMethod" and "paymentInstrument.id" it will only recognize those elements that are "checked", therefore it is recommended to keep all payment methods and payment instruments in separate radio-button groups. This will ensure that only one payment method and one payment instrument can be selected at any given time. The separation can be achieved by giving the form elements different name attributes.

Inclusion of multiple CVV fields

For any transaction for which the payment method credit card "CC" is offered, either by registering a new payment instrument or using an existing payment instrument, it is required to also provide a CVV. The CVV field is a hosted field which is designated by the attribute data-crefopay-placeholder="paymentInstrument.cvv". Compared to the other fields which use the attribute data-crefopay-placeholder, the CVV field can be included multiple times on one page, but only one of them should be visible at any give time. This allows the shop to display the field right next to either the input fields for a new credit card, or alternatively to already registered cards.

It is sufficient if a parent element of the element containing the CVV field is hidden, to make it unrecognizable for the SecureFields library.

Secure Fields Configuration

The following values should be set in the configuration object for the SecureFields:

Value	Information
ccOverlay	If the customer selects CC or CC3D as payment method, and registerPayment() is triggered, the credit card overlay will be displayed to collect card data if this field is set to 'true'. Set to 'false' if not provided
ddOverlay	If the customer selects DD as payment method, and registerPayment() is triggered, the direct debit overlay will be displayed to collect bank account information if this field is set to 'true'. Set to 'false' if not provided
nonce	The nonce will be passed on in the script tags for all libraries that are automatically fetched by the secure-fields.js, so that the content security policy of shops can allow them to load
placeholders	Placeholders object. Contains values with which the placeholder fields will be pre-filled with. See below for object structure
paypal	Allows to customize the PayPal button, if it is rendered
url	API endpoint (If this value is not set, it will default to the lynck production system)

URL

Sandbox: https://sandbox.crefopay.de/secureFields/

Live: https://api.crefopay.de/secureFields/

Placeholders

The placeholders object may contain the following values:

Value	Information
accountHolder	Pre-filled values for the cardholder name field
number	Pre-filled values for the credit card number field
cvv	Pre-filled values for the CVV field

var configuration = {
    url: "https://sandbox.crefopay.de/secureFields/",
    ddOverlay: true,
    ccOverlay: false,
    placeholders: {
        accountHolder: "Your Name",
        number: "0123456789101112",
        cvv: "000"
    },
    paypal: {
        layout: "horizontal",
        color: "silver"
    }
}

Paypal customization

The paypal object may contain the following values:

Value	Information
layout	Possible values: horizontal, vertical
color	Possible values: gold, blue, silver, white, black
shape	Possible values: rect, pill
height	Numerical height in pixel
label	Possible values: paypal, checkout, buynow, pay, installment
tagline	Possible values: true, false

See the PayPal documentation for examples of the options.

Error handling

Errors or exceptions should be properly handled by the callback functions. The field resultCode is the main indicator used to recognize whether something went wrong. In general, if a resultCode higher than 0 is returned, it can be assumed that something went wrong. At errorcodes you may find general errors that may occur during payment method registration. In case of any error an error message will be provided to give more detailed information. Most errors will occur due to either validation or missing data-attributes. In those cases the user should be asked to check his inputs.

If a reserve call failed due to the resultCode not being 0 or 1, then it is required to call getTransactionPaymentInstruments if another purchase attempt is to be made using the same transaction. This returns an updated list of the available payment methods and payment instruments of the transaction.

Billie

To be able to reserve a SecureFields transaction using Billie as payment method, the customer needs to go through an identification process using the Billie widget. Generally this payment method is treated as a secure payment method by lynck, as Billie perform their own risk checks for each transaction/customer. As such lynck risk checks will not influence whether Billie can be offered as a payment method or not.

The Billie widget will be automatically initialized in the customer browser, when registerPayment() of the SecureFields library is called and Billie was selected as payment method. This requires that the latest version of the SecureFields library is used within the shop. Billie specifically uses the payment method BILL_SECURE, which can be offered using radio buttons, just like any other payment method.

<input type="radio" data-crefopay="paymentMethod" value="BILL_SECURE">Billie</label>

Billie success case handling

If the registerPayment() function returned resultCode=0 then the identification process was successful and the checkout can continue.

{
    "resultCode": 0,
    "salt": "8ad7ea63c2fecd63",
    "orderNo": "1603709147671",
    "paymentMethod": "BILL_SECURE"
}

During the identification process in the Billie-widget, the customer may provide a company/billing address that can differ from the billing address that was originally provided in the shop environment. To make sure that the address in the shop is correct, the billing address with which Billie successfully identified the merchant should be used within the shop.

It is recommended to call the getTransactionStatus API after every registerPayment() execution using BILL_SECURE that returned resultCode=0, and to compare the returned billing address to the address stored in the shop. If these differ, then the shop should update the billing address of the order before redirecting the customer to the order confirmation page.

After successful identification with the Billie widget, the transaction can be reserved like any other regular SecureFields transaction.

Billie failure case handling

If the response to registerPayment() is anything else but resultCode=0, then the checkout process should not continue, and the user should remain on the payment selection page.

Specifically for Billie, the following resultCodes can be returned:

{
    "resultCode": 3005,
    "message": "Financing limit of debtor currently exceeded."
}

resultCode	Message	Hard decline
3001	Debtor address or name mismatch.	no
3002	Debtor could not be identified with the information given.	no
3003	Risk decline.	yes
3004	Not enough data available to make a decision.	no
3005	Financing limit of debtor currently exceeded.	yes
3006	User rejected suggested company.	no
3099	Unknown decline: (variable reason)	no

The resultCodes 3003 and 3005 represent so called "hard declines". If either of those resultCodes is returned, then Bille should not be offered as an available payment method, as the customer was identified and not accepted by Billie. Optimally this would result in the payment method BILL_SECURE being hidden for this specific order.

Express Checkout

Amazon Pay Express

Payment Process

Amazon Pay should be integrated into shops as an express payment method. This means compared to conventional payment methods, it is not offered on the payment method selection page, but on different pages before that. Compared to other payment methods offered by lynck, using Amazon Pay does not require the merchant to create a transaction upfront.

Given that the payment method can be offered on the product pages or the basket page in the shop, the customer may not yet have provided any customer data with which a lynck transaction can be created. To create and process a lynck transaction with Amazon Pay, the customer needs to log into the Amazon system and then select a delivery address and a payment method using the Amazon Pay button.

After successful authentication with Amazon Pay, the customer would then be redirected back to the shop, where the shop has the chance to request all relevant customer data from lynck and display the order confirmation page of the shop. On order confirmation by the customer, the transaction should be reserved using the lynck reserve API, which finalizes the payment.

Prerequisites

//lynck library
//For use on the production environment
<script src="https://api.crefopay.de/libs/3.0/amazon-client.js"></script>

//For use on the sandbox environment
<script src="https://sandbox.crefopay.de/libs/3.0/amazon-client.js"></script>

//Amazon Pay library
//For use on any environment (EU)
<script src="https://static-eu.payments-amazon.com/checkout.js"></script>

To render the Amazon Pay button for a lynck transaction, the lynck amazon client JavaScript library and the Amazon checkout JavaScript library need to be included in the header of any given page.

Rendering the Amazon Pay button

<script type="text/javascript" charset="utf-8">
  amazonClient = new AmazonClient(
  shopPublicKey,
  configuration,
  initializationCompleteCallback,
  onButtonClickCallback
  );
amazonClient.createButton();
</script>

To render the button, an instance of the AmazonClient needs to be created first. This is done by providing the public key of your shop, provided by lynck, a configuration object and two callback functions. Afterwards the createButton function of the AmazonClient instance can be used, to insert the button on the page.

<div data-crefopay="amazonPayButton"></div>

This function will search for a placeholder field on the entire page, and render the button inside it. The placeholder should be a simple DIV-element with the attribute data-crefopay=”amazonPayButton”.

Argument	Description
shopPublicKey	Will be provided by lynck
configuration	This argument should be used to provide transaction information required for processing. Details follow below (see Configuration options)
initializationCompleteCallback	This function will be called right after the client initialization and receives the API response of lynck as argument.
onButtonClickCallback	This function will be called right after the customer clicked the Amazon Pay button and receives the name of the placeholder element as argument.

Rendering multiple buttons on one page

In certain cases it may be required to render multiple Amazon Pay buttons on a single page in a shop. This can be relevant in case the button should be displayed next to multiple products which are displayed on the same page.

<script type="text/javascript" charset="utf-8">
  //Rendering 3 buttons simultaneous
  amazonClient.createButton("button1","button2","button3");
</script>

//Placeholder elements for the 3 buttons
<div data-crefopay="button1"></div>
<div data-crefopay="button2"></div>
<div data-crefopay="button3"></div>

To render multiple buttons at once, the createButton function can be while providing the names of the placeholder elements. By doing so the amazon-client will scan the page for elements for which the data-crefopay attribute are set to the provided names, and render the buttons inside them.

<script type="text/javascript" charset="utf-8">
  function onButtonClickCallback(button) {
    switch(button){
      case "button1":
        //action for button 1
        break;
      case "button2":
        //action for button 2
        break;
      case "button3":
        //action for button 3
        break;
    }
  }
</script>

When one of the buttons was clicked, the name of the placeholder in which the button was rendered will be provided to the onButtonClickCallback function as an argument. With this it is possible to perform different actions, depending on which of the buttons was clicked.

Amazon JS Configuration options

The configuration object maybe contain the following fields:

Value	Information
url	Base URL of the lynck system for which the transaction should be created. Set to Sandbox if not provided. Possible values: Sandbox: https://sandbox.crefopay.de/secureFields/ Production: https://api.crefopay.de/secureFields/
buttonColor	Sets the color of the Amazon Pay button. Set to "Gold" per if not provided. Possible values: Gold LightGray DarkGray
placement	Informs Amazon Pay about the location in which the button is displayed. Set to "Cart" if not provided. Possible values: Home Product Cart Checkout Other
checkoutLangage	Sets the preferred language displayed on the Amazon Pay page. Set to English if not provided. Possible values: en_GB de_DE fr_FR it_IT es_ES
sandbox	Decides if test transactions or real transactions are created in the Amazon Pay system. For transactions performed on any lynck test/staging system, this should be set to "true". Only set this to "false" when you use the lynck production system to perform real payments. Set to "false" if not provided. Possible values: true false
autoCapture	Indicates whether the lynck system should automatically capture all funds immediately after successful authorization with Amazon Pay.
deliverySpecifications	Specifies which addresses the customer is allowed to select at Amazon Pay. Details follow below (see Delivery address restrictions)
orderId	Unique reference to the lynck transaction that will be created if the user clicks on the button and authorizes with Amazon Pay. Lynck will generate a random orderID if none was provided. A maximum of 30 characters are allowed. Not mandatory.
userId	Unique reference to the customer in the lynck system. Providing this field is useful to improve risk detection by the lynck risk engine. Lynck will generate a random userID if none was provided. A maximum of 50 characters are allowed. Not mandatory.

Initialization callback

The provided callback function initializationCompleteCallback will be called once the createButton function was executed, and the result will be provided to it. When resultCode=0 is returned then one or multiple buttons were successfully rendered. For any other resultCode the rendering failed, and a message and further error details are provided.

Relevant fields for result processing:

Field	Description
resultCode	resultCode = 0 -> The Amazon Pay button was successfully rendered. resultCode > 0 -> see errorcodes
salt	A random number to guarantee the uniqueness of the message.
message	If an error occurs, this field contains details about that error. Not set if resultCode = 0.
errorDetails	Structured information about any invalid request values.

Button click callback

The provided callback function onButtonClickCallback will be called immediately after the customer clicked on a rendered Amazon Pay button. This function can be used to prepare the basket of the customer in the shop by adding new basket items, or to store other relevant data in the customer session. After execution of the function the customer will be redirected to Amazon Pay to authenticate.

Delivery address specifications

//Example: restrict packstation addresses
{
  \"specialRestrictions\": [\"RestrictPackstations\"]
}

//Example: only allow delivery to Austria and Germany
{
  \"addressRestrictions\": {
    \"type\": \"Allowed\",
    \"restrictions\": {
      \"AT\":{},
      \"DE\":{}
      }
    }
}

//Example: specifically disallow delivery to France
{
  \"addressRestrictions\": {
    \"type\": \"NotAllowed\",
    \"restrictions\": {
      \"FR\":{}
      }
    }
}

//Example: only allow delivery to a certain zip code in Germany and restrict packstation addresses
{
  \"specialRestrictions\": [\"RestrictPackstations\"],
  \"addressRestrictions\": {
    \"type\": \"Allowed\",
    \"restrictions\": {
      \"DE\":{
        \"zipCodes\": [\"10317\"]
        }
      }
    }
}

As the customer selects their delivery address on the Amazon Pay page, it needs to be ensured that they are not able to select addresses in locations/countries which are not supported by the shop. For this the deliverySpecifications field in the configuration should be set accordingly. The field can be used to restrict delivery addresses to specific, zones, countries, zip codes and even disallow PO boxes and packstation addresses.

The see official Amazon Pay documentation on how the deliverySpecifications can be set.

Fetching customer data & order confirmation page

After the customer successfully logged in with Amazon Pay and authenticated the order, they are redirected to the “checkout review URL”. Using the GET-parameters provided in this redirection, the shop should now fetch the relevant user data, such as customer name and address, so that the order in the shop can be updated accordingly.

The following GET-parameters can be provided:

Parameter	Information
-MERCHANTID-	This is the merchant ID assigned by lynck.
-STOREID-	This is the store ID of a merchant assigned by lynck as a merchant can have more than one store.
-ORDERID-	This is a unique identifier for a lynck transaction. Will be set to the value provided in the configuration when initializing the Amazon Pay button. Otherwise it is automatically generated.
-PAYMENTMETHOD-	The payment method selected by the customer. This will always be AMAZON_PAY in case of a redirection from Amazon Pay to the shop.
-PAYMENTREFERENCE-	Amazon Pay session ID. This ID can be used to render buttons which allow the customer to change their address on the order confirmation page.

Example of a checkout review URL: https://www.example.com/testshop/review?merchantID=-MERCHANTID-&storeID=-STOREID-&orderID=-ORDERID-&paymentMethod=-PAYMENTMETHOD-&sessionID=-PAYMENTREFERENCE-

Afterwards the user should be redirected to the order confirmation page of the shop, if they were not redirected there immediately. The order confirmation page should contain a summary of the order, with all relevant user and transaction data being displayed, the same as for any other payment method in the shop.

Changing the address

Customers should have the option to change the address on the order confirmation page. As the customer initially selected these addresses on the Amazon Pay page, they must be redirected back to the page to change it again. This can be done by binding click events to HTML elements on the order confirmation page using the Amazon Pay library.

<script src="https://static-eu.payments-amazon.com/checkout.js"></script>
Then the action can be bound to elements on the page:
<script type="text/javascript" charset="utf-8">
  amazon.Pay.bindChangeAction('#changeButton1', {
    amazonCheckoutSessionId: 'xxxx',
    changeAction: 'changeAddress'
  });
</script>

First, same as for displaying the Amazon Pay button, the Amazon Pay JavaScript library needs to be included in the header of the order confirmation page.

Upon triggering the event, the customer will then be redirected back to the Amazon Pay page, where they will be able to modify their address.

After the customer selected their new address they will be redirected back to the “checkout review URL”, same as they were initially. Upon re-entry, the customer data should be fetched again from lynck to update the order in the shop.

Finalizing the transaction

When the customer confirms their purchase on the order confirmation page of the shop, the lynck reserve API should be called, same as for any other payment method. On success, the response will contain resultCode=1, which signifies that the customer should be redirected to a specific url, which is provided in the field redirectUrl. This redirection is required by Amazon to perform last risk checks to authorize the payment. Depending on the outcome, the user will then be redirected back to the configured success URL of the shop, or on failure to the configured failure URL of the shop. This is identical behavior to all other payment methods that require a redirection on the lynck platform.

Transaction management

After successful reservation of the Amazon Pay transaction, the transaction may be in one of two states. If Amazon Pay notified that the authorization for the payment is still pending, then the transaction will be in status CIAPending. At this stage, the transaction cannot be captured yet, but it may be cancelled. When Amazon Pay confirmed that the authorization is successful, the lynck transaction will be in status MerchantPending. This signifies that the funds are ready to be captured.

Generally an Amazon Pay transaction in the lynck system can be managed identically to any other payment method, in that captures and refunds can be created, and that they can be cancelled.

PayPal Express

Payment Process

The inclusion of a PayPal Express button in the shop will allow customers to skip parts of the checkout process to have an easier and faster checkout experience. Compared to conventional payment methods, PayPal Express should not be offered on the payment method selection page, but on different pages before that. The button could be included directly on product pages or the basket overview for example. Using PayPal Express does not require the merchant to create a lynck transaction upfront, as would be the case for regular lynck integrations.

Given that the payment method can be offered on the product pages or the basket page in the shop, the customer may not yet have provided any customer data with which a lynck transaction can be created. To create and process a lynck transaction with PayPal Express, the customer needs to log into the PayPal system and then select a delivery address and a payment method using the PayPal Express button.

After successful authentication with PayPal, the customer would then be redirected back to the shop, where the merchant is able to request all relevant customer data from lynck and display the order confirmation page of the shop. On order confirmation by the customer, the transaction should be reserved using the lynck reserve API, which finalizes the payment.

Prerequisites

//lynck library
//For use on the production environment
<script src="https://api.crefopay.de/libs/3.0/paypal-client.js"></script>

//For use on the sandbox environment
<script src="https://sandbox.crefopay.de/libs/3.0/paypal-client.js"></script>

To render the PayPal Express button for a lynck transaction, the PayPal client JavaScript library needs to be included in the header of any given page.

Rendering the PayPal Pay button

<script type="text/javascript" charset="utf-8">
  paypalClient = new PaypalClient(
    shopPublicKey,
    configuration,
    initializationCompleteCallback,
    cancelCallback,
    approveCallback);
  paypalClient.createButton();
</script>

To render the button, an instance of the PayPal client needs to be created first. This is done by providing the public key of your shop, provided by lynck, a configuration object and three callback functions. Afterwards the createButton function of the PayPal client instance can be used, to insert the button on the page.

<div data-crefopay-placeholder="payPalExpressButton"></div>

This function will search for a placeholder field on the entire page, and render the button inside it. The placeholder should be a simple DIV-element with the attribute data-crefopay=”payPalExpressButton”.

Argument	Description
shopPublicKey	Will be provided by lynck
configuration	This argument should be used to provide transaction information required for processing. Details follow below (see Configuration options)
initializationCompleteCallback	This function will be called right after the client initialization and receives the API response of lynck as argument.
cancelCallback	This function will be called if the customer either cancels the PayPal login or closes the PayPal window.
approveCallback	This function will be called if the customer successfully logged in with PayPal and authorized the payment.

PayPal JS configuration options

The configuration object maybe contain the following fields:

Value	Type	Mandatory	Information
stagingSystemUrl	V	yes	Base URL of the lynck system for which the transaction should be created. Set to production if not provided. Possible values: Sandbox: https://sandbox.crefopay.de/ Production: https://api.crefopay.de/
color	V	no	Sets the color of the PayPal Express button. Set to "gold" if not provided. Possible values: gold blue silver white black
shape	V	no	Sets the shape of the PayPal Express button. Set to "rect" if not provided. Possible values: rect pill
tagline	B	no	Decides whether a tagline is displayed below the button or not. Set to "true" if not provided.
shippingAddress	J (Address)	no	Shipping address of the customer, can be provided if known.
basketItems	JA (Basket Item)	yes	List of current basket items of the customer. Required to create the PayPal order. If a shipping address was provided, it is mandatory that the basketItems JSON contains an item with basketItemType = SHIPPINGCOSTS.
orderID	AN (50)	yes	If provided, the value will be used as orderID in the lynck transaction if the user successfully authorized with PayPal. The orderID must be unique.
userID	AN (50)	yes	If provided, the value will be used as userID in the lynck transaction if the user successfully authorized with PayPal.
autoCapture	B	no	If true, the resulting lynck transaction will be captured automatically after it was reserved. Set to "false" if not provided.
nonce	AN	no	The nonce will be passed on in the script tags for all libraries that are automatically fetched by the paypal-client.js, so that the content security policy of shops can allow them to load

Initialization callback

The provided callback function initializationCompleteCallback will be called once the createButton function was executed, and the result will be provided to it. When resultCode=0 is returned then the button was successfully rendered. For any other resultCode the rendering failed, and a message and further error details are provided.

Relevant fields for result processing:

Field	Description
resultCode	resultCode = 0 -> The PayPal Express button was successfully rendered. resultCode > 0 -> see errorcodes
salt	A random number to guarantee the uniqueness of the message.
message	If an error occurs, this field contains details about that error. Not set if resultCode = 0.
errorDetails	Structured information about any invalid request values.

Cancel callback

The provided callback function cancelCallback will be called if the customer cancels the process by closing the PayPal Express popup window. In this case the user did not grant authorization to perform any payments and the user should not progress in the checkout.

Approve callback

The provided callback function approveCallback will be called if the customer successfully authorized the payment inside the PayPal Express popup window. The function will receive the following data which will be needed for further processing:

Field	Description
orderID	OrderID of the lynck transaction associated to this purchase. The orderID will be required in the reserve API call, which should be performed to finalize the transaction one the customer confirmed the purchase on the order confirmation page.
userID	UserID of the customer associated to this purchase.
customerEmail	The customers email address that was returned by PayPal.
shippingAddress	The shipping address associated to this purchase, including the name of the recipient. If no shipping address was provided when the PayPal Express button was initialized, the shipping address which the customer selected at PayPal will be returned.

Order confirmation page

After the customer successfully logged in with PayPal and authorized the order, they should be redirected to the order confirmation page of the shop on which they can review the order details and provide final confirmation. The order confirmation page should contain a summary of the order, with all relevant user and transaction data being displayed, the same as for any other payment method in the shop.

Finalizing the transaction

When the customer confirms their purchase on the order confirmation page of the shop, the lynck reserve API should be called, same as for any other payment method. No further redirection of the customer is required, meaning the reserve API will respond with resultCode=0 in case the transaction amount was reserved successfully at PayPal

Transaction management

After successful reservation of the PayPal Express transaction, the transaction may be in one of two states. If PayPal notified that the authorization for the payment is still pending, then the transaction will be in status CIAPending. At this stage, the transaction cannot be captured yet, but it may be cancelled. When PayPal confirmed that the authorization is successful, the lynck transaction will be in status MerchantPending. This signifies that the funds are ready to be captured. If the parameter autoCapture=true was provided in the configuration, then the transaction would be captured automatically as well, which would transition it into status Done.

Generally a PayPal Express transaction in the lynck system can be managed identically to any other payment method in the system, in that captures and refunds can be created, and that they can be cancelled.

Data Structures

Address

The address object only contains the street address. It can be used in combination with a person or company to send a complete address.

Field	Type	Mandatory	Comments
street	AN (80)	yes	street
no	AN (32)	no	house number
additional	AN (80)	no	additional information
zip	AN (16)	yes	zip
city	AN (80)	yes	city
state	AN (80)	no	state, e.g. NRW
country	AN (2)	yes	2 letter country code according ISO 3166
name	AN (153)	no	Full name (PRIVATE user) or company name (BUSINESS user) of the customer. Can be set using the fields billingRecipient and shippingRecipient in createTransaction or createSubscription. Only returned in getTransactionStatus.

Amount

Field	Type	Mandatory	Comments
amount	N (9)	yes	Amount in smallest possible denomination (e.g. 12399 for 123.99 Eur). (including taxes)
netAmount	N (9)	no	Amount in smallest possible denomination (e.g. 12399 for 123.99 Eur). (excluding taxes)

Amount (deprecated, do not use)

Field	Type	Mandatory	Comments
amount	N (9)	yes	Amount in smallest possible denomination (e.g. 12399 for 123.99 Eur).
vatAmount	N (9)	no	Amount in smallest possible denomination (e.g. 12399 for 123.99 Eur).
vatRate	N (2.2)	no	floating point number with two decimals, e.g (19.00 or 32.75)

Basket Item

Field	Type	Mandatory	Comments
basketItemText	AN (500)	yes	Description of the basket item
basketItemID	AN (20)	no	Unique ID for a single article of the basket
basketItemCount	N (5)	yes	Number of basket items of this kind
basketItemAmount	J (Amount)	yes	The subtotal of the basket item. This is the product of the price per item times the item count: basketItemAmount = basketItemCount x pricePerItem. This amount must always be a positive amount, even for the type COUPON
basketItemRiskClass	V	no	Risk class of this basket item. Possible values are: 0 -> trusted user 1 -> default risk user 2 -> high risk user Either the useRiskClass or the basketItemRiskClass in the basket items has to be set.
basketItemType	V	no	Possible values are: DEFAULT SHIPPINGCOSTS COUPON

Boniversum

Field	Type	Mandatory	Comments
requestDate	D (YYYY-MM-DD)	yes	Date of the original request
identification	V	yes	One of the following constants: PERSON_HOUSEHOLD_NOT_IDENTIFIED PERSON_HOUSEHOLD_IDENTIFIED PERSON_IDENTIFIED HOUSEHOLD_IDENTIFIED PERSON_NOT_IDENTIFIED BUILDING_IDENTIFIED PERSON_DECEASED
addressValidationStatus	V	yes	One of the following constants: SUCESSFULLY_VALIDATED CORRECTED_AND_VALIDATED NOT_CORRECTED_OR_VALIDATED
trafficLightColor	V	yes	One of the following constants: NONE RED YELLOW GREEN
score	N	yes	Score value

CaptureStatusDetail

Field	Type	Comments
transactionAmount	N	The amount which has been confirmed by the user during the checkout process
capturedAmount	N	The capturedAmount delivers the captured value for this specific (partial) order. If no reference number has been passed capturedAmount contains the sum of all captured amounts for all orders of the transaction
paidAmount	N	The paidAmount delivers the paid value for this specific (partial) order. If no reference number has been passed paidAmount contains the sum of all paid amounts for all orders of the transaction.
creditAmount	N	The creditAmount delivers the refunded value for this specific (partial) order. If no reference number has been passed creditAmount contains the sum of all refunds for all orders of the transaction
reducedAmount	N	Describes how much of the openAmount was reduced via the refund call.
guaranteedAmount	N	Describes how much was paid out to the merchant from payment guarantee.
returnedGuaranteedAmount	N	Describes the amount of paid out payment guarantee that was refunded.
feeAmount	N	Set in case of chargeback. Describes the fees issued by banks or service providers.
openAmount	N	Describes the incoming amount which the lynck system expects for this order.
transactionCurrency	AN	Currency code according to ISO4217

ClosedTransactions

Field	Type	Mandatory	Comments
orderID	AN	yes	Unique identifier of the transaction
closureStatus	V	yes	Shows if the closure of the transaction was successful, failed or is still pending. Possible values: SUCCESS PENDING FAILURE
previousTransactionStatus	V	yes	The status of the transaction before closure was triggered. Possible values: see Transaction process
newTransactionStatus	V	yes	The status of the transaction after the closure was triggered. Possible values: see Transaction process
transactionAmount	J (Amount)	yes	The total amount of the transaction
creationDate	D (YYYY-MM-DD)	yes	Date on which the transaction was created

Company

Field	Type	Mandatory	Comments
companyName	AN (100)	yes	The name of the company
email	AN (254)	yes	Company e-mail address
companyRegisterType	V	no	The register type of the company. A list of valid values can be found in the section Company register type
companyRegistrationID	AN (30)	no	The registration number
companyVatID	AN (30)	no	The VAT id of the company
companyTaxID	AN (30)	no	The tax id of the company

CreateAndReserveTransactionRequest

Field	Type	Mandatory	Comments
orderID	AN (50)	yes	Unique identifier for the transaction to be created
referenceOrderId	AN (50)	yes	Order ID of the initial transaction (recurringTransactionType=FIRST) with which the payment agreement was created
userID	AN (50)	yes	The unique user ID of the customer for which the recurring transaction is created
merchantReference	AN (30)	no	Optional/additional reference for the transaction
amount	N (99999999)	yes	The numerical transaction amount in the smallest denomination
locale	V	yes	Should the transaction result in any communication to the customer, such as a SEPA prenotification email, then the locale will determine the language in which they are contacted. See Languages

Crediconnect

Field	Type	Mandatory	Comments
requestDate	D (YYYY-MM-DD)	yes	Date of the original request
trafficLightColor	V	yes	One of the following constants: NONE RED YELLOW GREEN

Creditreform

Field	Type	Mandatory	Comments
requestDate	D (YYYY-MM-DD)	yes	Date of the original request
crefoProductName	V	yes	One of the following constants: IDENTIFICATION RISK_CHECK TRAFFIC_LIGHT_REPORT COMPACT_REPORT
blackWhiteResult	B	no	Result of the black/white check: true -> black false -> white
trafficLightResult	V	no	Result of the traffic light check: NONE RED YELLOW GREEN
compactScore	N	no	Result of a compact report: score between 1 - 600.
dateOfFoundation	V	no	Result of a compact report: company foundation date
legalForm	V	no	Result of a compact report: company legal form
lineOfBusiness	V	no	Result of a compact report: company line of business
companyEmail	V	no	Result of a compact report: company email address

ErrorDetails

Field	Type	Mandatory	Comments
message	V	yes	Key for failure reason (e.g. "field.invalid", "fieldName.invalid")
field	AN	yes	Name of the invalid field. This is exactly the name of the field in the interface. (e.g. userData.dateOfBirth). This value can be used to mark the invalid field in the user interface.
number	N	yes	Error number
description	AN	yes	Human readable message in English

ExternalErrorDetails

Field	Type	Mandatory	Comments
externalCode	AN	yes	Error code as provided by the service provider
externalMessage	AN	no	Error message as provided by the service provider
recoverable	V	no	Provides information on whether the reservation may be re-attempted. Options: yes no unknown

HostedPages text

Field	Type	Mandatory	Comments
paymentMethodType	V	yes	The identifier of the payment method. See PaymentMethods
fee	N (16)	no	The fee of a payment method in smallest possible denomination e.g. 199 for 1.99 Eur. The fee will be displayed next to the payment method on the Hosted Page, where the user selects his payment method.
description	AN (255)	yes	Additional text/explanation of a payment method. This text will be displayed next to the payment method on the Hosted Page, where the user selects his payment method
locale	V	yes	The locale determines the user’s communication language e.g. for e-mails which will be send to the user or for payment pages. See Languages

MerchantNotificationMessage

Field	Type	Comments
merchantID	N (16)	Merchant ID to which the transaction belongs
storeID	AN (60)	Shop ID to which the transaction belongs
orderID	AN (50)	Order ID for which the error occurred
resultCode	N	Related error code. See errorcodes
message	AN	Contains details about the error

nextPayment

Field	Type	Mandatory	Comments
transactionAmount	J (Amount)	yes	Total amount of the next payment that will be tiggered for the subscription.
paymentDate	D (YYYY-MM-DD)	yes	Date on which the next payment for the subscription will be triggered.

OldNewValuePair

Field	Type	Mandatory	Comments
newValue	Same type as updated field	Yes	Contains the updated field value.
oldValue	Same type as updated field	No	Contains the overwritten field value. Not set if no value was overwritten.

Payment options

Field	Type	Mandatory	Comments
recurringTransactionType	V	no	Possible values: FIRST RECURRING This parameter can be used to control recurring transactions without using the lynck subscription module. If an initial transaction is created with recurringTransactionType 'FIRST' it is possible to create follow-up transactions with type 'RECURRING', for which the customer does not need to be present. In case of direct debit, the second transaction will use the same mandate as the initial transaction and in case of credit card it does not require a cvv to be processed. This option is available for all payment methods that are listed as "Recurring" in the payment method overview. If type RECURRING is used, a reference (referenceOrderId) to the initial transaction is required in the reserve call.

PaymentInstrumentRequest

Field	Type	Comments	Mandatory for credit card	Mandatory for bank account
paymentInstrumentType	V	Possible values: BANKACCOUNT CREDITCARD	yes	yes
accountHolder	AN (70)	The account holder of the payment instrument	yes	yes
number	AN (16)	Credit card number	yes	no
validity	D (YYYY-MM)	Validity date of the credit card	yes	no
issuer	V	Possible values: VISA MC	yes	no
iban	AN (34)	Bank account number	no	yes
bic	AN (11)	Bank identifier - mandatory for non-German bank accounts	no	no

PaymentInstrumentResponse

Field	Type	Comments	Provided for credit card	Provided for bank account
paymentInstrumentID	AN (20)	The unique ID of the payment instrument. This ID is created by lynck.	yes	yes
paymentInstrumentType	V	Possible values: BANKACCOUNT CREDITCARD	yes	yes
accountHolder	AN (70)	The account holder of the payment instrument	yes	yes
number	AN (16)	Masked credit card number	yes	no
validity	D (YYYY-MM)	Validity date of the credit card	yes	no
issuer	V	Credit card issuer. Possible values: VISA MC	yes	no
iban	AN (34)	Masked bank account number	no	yes
unmaskedIban	AN (34)	Unmasked bank account number. Only provided in response to createTransaction.	no	yes
bic	AN (11)	Bank identifier	no	yes
mandatoryReserveFields	J(AN)	Array of parameters that are required for the reserve call, such as CVV. Only provided in response to createTransaction.	if required	if required

Person

Field	Type	Mandatory	Comments
salutation	V	no	Possible values: F -> Female M -> Male V -> Various The field 'salutation' is not mandatory, but it is required to perform most solvency checks for the payment methods direct debit and bill payment. If no salutation is provided the available payment methods may be restricted.
name	AN (50)	yes	Person's name
surname	AN (50)	yes	Person's surname
dateOfBirth	D (YYYY-MM-DD)	no	Date of birth. The field 'dateOfBirth' is not mandatory, but it is required to perform most solvency checks for the payment methods direct debit and bill payment. If no date of birth is provided the available payment methods may be restricted.
email	AN (254)	yes	Person's e-mail address
phoneNumber	AN (30)	no	Person's phone number
faxNumber	N (30)	no	Person's fax number with leading zero

PaymentMethodInformation

Field	Type	Mandatory	Payment methods	Comments
paymentMethodType	AN	yes	all	Name payment method
sepaPaymentType	V	no	DD	Describes whether the SEPA mandate is recurring or one-off. Possible values: RCUR OOFF
issuer	V	no	CC, CC3D	List of supported issuers. Possible values: VISA MC
logos	V	no	CC, CC3D, BILL_SECURE	List of possible logos for presenting the payment method or payment instrument.
mandatoryReserveFields	Array of AN	no		Array of fields the reserve call is expecting for this payment method
mandateReference	AN	no	DD	Information for displaying SEPA mandate reference
creditorId	AN	no	DD	The creditor ID of the merchant
merchantName	AN	no	DD	The merchant's name
date	AN	no	DD	Date when the SEPA mandate was created

RawReportData

Field	Type	Mandatory	Comments
identificationReportData	J	no	Identification report data coming from solvency check provider Creditreform
checkReportData	J	no	Solvency check report data coming from solvency check Creditreform

ReserveInformationRequest

Field	Type	Mandatory	Comments
dateOfBirth	D (YYYY-MM-DD)	no	Date of birth. The field 'dateOfBirth' is not mandatory, but it is required to perform most solvency checks for the payment methods direct debit and BILL payment. If no date of birth is provided the available payment methods may be restricted.
referenceOrderId	AN (50)	no	Only mandatory for recurring/subscription transactions (recurringTransactionType=RECURRING). Order ID of the initial transaction (recurringTransactionType=FIRST) with which the payment agreement was created.
salutation	V	no	Possible values: F -> Female M -> Male V -> Various The field 'salutation' is not mandatory, but it is required to perform most solvency checks for the payment methods direct debit and bill payment. If no gender is provided the available payment methods may be restricted.

ReserveInformationResponse

Field	Type	Comments
bankname	AN	Bankname of the bankaccount the customer has to transfer the money to
bic	AN	BIC of the bank account to which the user should remit the money. For bill payments with payment guarantee it is the BIC of their bank account.
iban	AN	IBAN of the bank account to which the user should remit the money. For bill payments with payment guarantee it is the IBAN of their bank account.
bankAccountHolder	AN	Name of the bank account holder to whom the user should remit the money.
paymentReference	AN	The reference text to which the user needs to refer within his remittance so that lynck can link the incoming payments with the outstanding amounts of a transaction.

RiskData

Field	Type	Comments
solvencyData	JA(SolvencyData)	Information about different solvency checks

SolvencyCheckInformation

Field	Type	Mandatory	Comments
boniversumResult	J (Boniversum)	no	Data coming from solvency check provider Boniversum
crediConnectResult	J (Crediconnect)	no	Data coming from solvency check credi connect
crefoResult	J (Creditreform)	no	Data coming from solvency check provider Creditreform

SolvencyData

Field	Type	Mandatory	Comments
solvencyInterface	V	yes	Possible values are: BONIMA BUERGEL CREDICONNECT CREDITREFORM CUBE FLEXCONNECT VERITA
lastRequestDate	D (yyyy-MM-dd'T'HH:mm:ss'Z')	yes	Date of last request to the third party provider
pdfReportDownloadLink	URL	no	Link to download a ZIP file containing a PDF version of the solvency check report. Only available for Creditreform Webservices products.
rawReportData	J (Raw report data)	no	Contains the raw response from the solvency check provider. Only available for Creditreform Webservices products.
checkDate	D (yyyy-MM-dd'T'HH:mm:ss'Z')	yes	Date of the last solvency check request. As the third party provider is not called every time the solvency check is called, this date can differ from the lastRequestDate
checkType	V	yes	Possible values are: FIRST_LEVEL_CHECK SECOND_LEVEL_CHECK USER_LEVEL_CHECK
paymentMethod	V	no	The identifier of the payment method. See PaymentMethods. Only set for checkType SECOND_LEVEL_CHECK
actions	JA(V)	yes	All actions that were triggered by the lynck system because of this check. Possible values are: DECLINED HIGH RESTRICTION RESTRICTION_AND_MANUAL_CHECK MANUAL_CHECK NONE
thirdPartyRequested	B	yes	Indicates if the SolvencyCheck information has been refreshed at the third party provider or if it is historical data.
orderID	AN	no	Only in the response to getUser. The order which was the trigger for the solvency check
score	N	no	The score of this solvency check. Different number formats will be returned for different providers
trafficLight	V	no	Optional for solvencyInterface except BUERGEL, not set for BUERGEL. Possible values are: GREEN YELLOW RED NONE
identification	V	no	Only optional for solvencyInterface BONIMA and VERITA, not set for all other types. Possible values are: PERSON_HOUSEHOLD_NOT_IDENTIFIED PERSON_HOUSEHOLD_IDENTIFIED PERSON_IDENTIFIED HOUSEHOLD_IDENTIFIED PERSON_NOT_IDENTIFIED BUILDING_IDENTIFIED PERSON_DECEASED
addressValidation	V	no	Only optional for solvencyInterface BONIMA and VERITA, not set for all other types. Possible values are: SUCCESSFULLY_VALIDATED CORRECTED_AND_VALIDATED NOT_CORRECTED_OR_VALIDATED
correctedAddress	AN	no	Only optional for solvencyInterface BONIMA, CUBE, and VERITA, not set for all other types. Structure: <street> <houseNo>, <zip> <city>, <countryCode>
addressOrigin	AN	no	Only set optional solvencyInterface BUERGEL, not set for all other types
addressOriginCode	N	no	Only optional for solvencyInterface BUERGEL, not set for all other types
decisionMessage	AN	no	Only optional for solvencyInterface BUERGEL, not set for all other types
statusCode	AN	no	Only optional for solvencyInterface CREDICONNECT, not set for all other types
productName	V	no	Only optional for solvencyInterface CREDITREFORM, not set for all other types. Possible values are: IDENTIFICATION RISK_CHECK TRAFFIC_LIGHT_REPORT E_CREFO BRIEF_REPORT COMPACT_REPORT
checkResult	V	no	Only optional for solvencyInterface CREDITREFORM, not set for all other types. Possible values are: BLACK WHITE
identificationNumber	AN	no	Only optional for solvencyInterface CREDITREFORM, not set for all other types
negativeIndicator	B	no	Only optional for solvencyInterface CUBE, not set for all other types
status	V	no	Only optional for solvencyInterface CUBE, not set for all other types Possible values are: ACTIVE INSOLVENCY STOP_DISTRIBUTION UNKNOWN UNDER_DISABILITY DEAD
specialAddress	V	no	Only optional for solvencyInterface VERITA , not set for all other types. Possible values are: S1 S2 S3 S4 S5 S6 S7 S8

SubscriptionPlan

Field	Type	Mandatory	Comments
planReference	AN (15)	yes	Plan reference/identification. Used in createSubscription.
name	AN (25)	yes	Subscription plan name
description	AN (100)	yes	Subscription plan description provided on plan creation
amount	J (Amount)	yes	Default subscription rate of the plan
interval	V	yes	Possible values are: DAILY WEEKLY FORTNIGHTLY FOUR_WEEKLY MONTHLY QUARTERLY BIANNUALLY YEARLY
trialPeriod	N (3)	no	Trial period set on plan creation. Possible values: 1 to 366
basicPaymentsCount	N (3)	no	Total amount of subscription payments to be done. Possible values: 1 to 999. Unlimited payments if not set.
contactDetails	AN (100)	no	Contact details set on plan creation
hasSubscribers	B	yes	Shows whether the plan has subscriptions associated with it

SubscriptionTransactions

Field	Type	Comments
orderID	AN(30)	OrderID of the transaction as set by the merchant
transactionStatus	V(NEW, ACKNOWLEDGEPENDING, FRAUDPENDING, MERCHANTPENDING, CIAPENDING, EXPIRED, CANCELLED, FRAUDCANCELLED, DONE)	Current status of the transaction
transactionAmount	J (Amount)	Total amount of the transaction
creationDate	D (YYYY-MM-DD)	Date on which the transaction was created
lastStatusChangeDate	D (YYYY-MM-DD)	Date on which the last status change occurred

UserTransactions

Field	Type	Comments
orderID	AN(30)	OrderID of the transaction as set by the merchant
transactionStatus	V(NEW, ACKNOWLEDGEPENDING, FRAUDPENDING, MERCHANTPENDING, CIAPENDING, EXPIRED, CANCELLED, FRAUDCANCELLED, DONE)	Current status of the transaction
transactionAmount	N	Total amount of the transaction
transactionBalance	N	Current balance of the transaction
creationDate	D (YYYY-MM-DD)	Date on which the transaction was created
lastStatusChangeDate	D (YYYY-MM-DD)	Date on which the last status change occurred

TransactionStatusDetail

Field	Type	Only cash in advance or bill	Only direct debit	Comments
transactionAmount	N	No	No	The amount which has been confirmed by the user during the checkout process
transactionBalance	N	No	No	The sum of all received payments minus the sum of all captured amounts plus all reductions. This value is negative when still waiting for payments, positive in case a transaction was overpaid, and zero when the debt is paid exactly or no capture was performed yet.
transactionCurrency	AN	No	No	Currency code according to ISO4217
customerEmail	AN	No	No	E-mail address of the customer related to the transaction.
paymentDescriptor	AN	No	No	Description of the payment method selected by a customer at Amazon Pay
paymentMethod	AN	No	No	The identifier of the payment method. See PaymentMethods
bankname	AN	Yes	No	Name of the bank where the user should remit the money.
bic	AN	Yes	No	BIC of the bank to which the user should remit the money.
iban	AN	Yes	No	IBAN of the bank to which the user should remit the money.
accountHolder	AN	Yes	No	Name of the bank account holder to whom the user should remit the money.
paymentReference	AN	Yes	No	The reference text to which the user needs to refer within his remittance so that lynck can link the incoming payments with the outstanding amounts of a transaction.
sepaMandate	AN	No	Yes	Reference Number of the SEPA Mandate, only available if Payment method was DD
debitAccountHolder	AN	Yes	Yes
debitIban	AN	No	Yes	IBAN of the bankaccount that will be debited
debitBic	AN	No	Yes	BIC of the bankaccount that will be debited

UpdatedData

Field	Type	Mandatory	Comments
merchantReference	J (OldNewValuePair)	No	Contains the updated merchantReference and the previous merchantReference if any value was overwritten. Only set if the merchantReference was updated.

UserBalance

Field	Type	Comments
balance	N	The sum of the last 100 transaction balances of the user
transactionAmount	N	The sum of transaction amounts of the last 100 transactions of the user

Additional services

SmartSignup

The Smart Sign-Up JavaScript library is designed to help your business customers complete the checkout process far quicker, and make sure you always have accurate data about your business customers, which greatly enhances the chances of a successful B2B solvency check. The data returned by Smart Sign-Up comes from Creditreform databases for business information reports. The Creditreform data is collected decentralised by 130 German branch offices.

User flow

After your business customer types the first three letters of his business name, we call the 'Firmenwissen' Smart Sign-Up API to query the Creditreform database.The user will see a drop-down with possible selection options displayed based on his input. A new query is performed after the user changes his input and pauses for 300 milliseconds.

After the user selects his company from the drop-down list, the address fields (street, number, ZIP, county and country) are automatically populated. We can also return the CrefoNummer, which you can store in your ERP or database for later use.

To understand the user flow better, have a look at the 'Firmenwissen' Smart Sign-Up website https://www.firmenwissen.de/index.html.

SmartSignup Prerequisites

Before you can use Smart Sign-Up you need to add this option to your contract with lynck. If you did not register for this option yet just contact the support team at service@lynck.de. You will need a public key to initialize the library.

The JavaScript Library should be included in the page using the following snippet:

 <script src="https://libs.crefopay.de/3.0/smart-sign-up.js"></script>

URL:

Sandbox: https://sandbox.crefopay.de/autocomplete/

Live: https://api.crefopay.de/autocomplete/

SmartSignup Configuration

let configuration = {
    "url": "https://sandbox.crefopay.de/autocomplete/",
    "itemCount": 10,
    "suggestion": {"zip": true, "city": true, "county": true, "country": true}
};

The following values can be set in the configuration object for the SmartSignup client:

Field	Type	Mandatory	Comments
url	AN	no	API endpoint (If this value is not set, it will default to the lynck production system.)
itemCount	N	yes	Number of suggestions that are shown in the drop-down
suggestion	J	no	configuration of the content that is shown in the suggestion drop-down. As a default only the company name is shown in the droptown. To add additional information following parameter can be added to this Json object: zip city county country and set to 'true'. Example: {"city": true, "country": true }

SmartSignup Initialization

To initialize the library, an instance of the SecureFieldsClient needs to be created.

function SmartSignUpClient(shopPublicToken, onInit, configuration)

new SmartSignUpClient("6bebbcabf03b937c05d1db9f0af98b29363880ba903fab10c4f5d4d96d58193f", function (data) {
    $("#result-content").html('');
    if (data.resultCode === 0) {
        $("#result-content").append('<p>Successfully initialized</p>');
    }
    $("#result-content").append(JSON.stringify(data, null, 4));
}, configuration);

Field	Type	Mandatory	Comments
shopPublicToken	AN	yes	The key you get from the support team after successfully registering with SmartSignup
onInit	JS function	yes	This function will be called right after the SmartSignup initialization and receives the API response of lynck as argument.
configuration	JS object	yes	The configuration object for the SmartSignup client

Display the result of the search

<div>
    <label for="companyName">Company Name</label>
    <input data-crefopay-placeholder="address.name" type="text" name="companyName"/>
</div>
<div>
    <label for="street">streetWithNumber</label>
    <input data-crefopay-placeholder="address.street" type="text" name="street"/>
</div>
<div>
    <label for="zip">Zip</label>
    <input data-crefopay-placeholder="address.zip" type="text" name="zip"/>
</div>
<div>
    <label for="city">City</label>
    <input data-crefopay-placeholder="address.city" type="text" name="city"/>
</div>
<div>
    <label for="country">Country</label>
    <input data-crefopay-placeholder="address.country" type="text" name="country"/>
</div>
<div>
    <label for="crefoNo">Crefo No</label>
    <input data-crefopay-placeholder="crefoNo" type="text" name="crefoNo"/>
</div>

The attribute data-crefopay-placeholder is used in all input input that should be used be autocompleted by SmartSignup. Following values can be used:

Value	Description
address.name	Company name. The input field with this tag is parsed by the SmartSignup client library to present suggestions. After at least 3 letters have been typed, the client library starts to show suggestions
address.street	Street name
address.streetNo	Street number
address.streetWithNumber	Street name with number
address.zip	ZIP code
address.city	City name
address.state	State of county
address.country	2 letter country code according ISO 3166
crefoNo	The crefo number of the company

SmartSignup Example

This example shows a minimal HTML page that uses SmartSignup to autocomplete all address-fields and show the result of the initialization of the initialization of the client library.

<!DOCTYPE html>
<html>
<head>
    <link rel="stylesheet" href="https://sandbox.crefopay.de/smart-sign-up.css">
    <script src="https://libs.crefopay.de/3.0/smart-sign-up.js"></script>
</head>

<body onload="configureSmartSignup()" >

<h1>Smart SignUp</h1>
<div>
    <label for="companyName">Company Name</label>
    <input data-crefopay-placeholder="address.name" type="text" name="companyName"/>
</div>
<div>
    <label for="street">Street</label>
    <input data-crefopay-placeholder="address.street" type="text" name="street"/>
</div>
<div>
    <label for="streetNo">Street No</label>
    <input data-crefopay-placeholder="address.streetNo"  type="text" name="streetNo"/>
</div>
<div>
    <label for="zip">Zip</label>
    <input data-crefopay-placeholder="address.zip" type="text" name="zip"/>
</div>
<div>
    <label for="city">City</label>
    <input data-crefopay-placeholder="address.city" type="text" name="city"/>
</div>
<div>
    <label for="state">State</label>
    <input data-crefopay-placeholder="address.state" type="text" name="state"/>
</div>
<div>
    <label for="country">Country</label>
    <input data-crefopay-placeholder="address.country" type="text" name="country"/>
</div>
<div>
    <label for="crefoNo">Crefo No</label>
    <input data-crefopay-placeholder="crefoNo" type="hidden" name="crefoNo"/>
</div>


<div id="result-container">
    <h1>Result</h1>
    <div id="result-content" class="result form"></div>
</div>


<script>
    function configureSmartSignup() {

        let configuration = {
            "url": "https://sandbox.crefopay.de/autocomplete/",
            "itemCount": 20,
            "suggestion": {"city": true, "country": true, "zip": true, "county": true}
        };

        new SmartSignUpClient("abcdefghijkjmnopqrstuvwxyz", function (data) {
            $("#result-content").html('');
            if (data.resultCode === 0) {
                $("#result-content").append('<p>Successfully initialized</p>');
            }
            $("#result-content").append(JSON.stringify(data, null, 4));

        }, configuration);
    }
</script>
</body>
</html>

Additional resources

Company register type

Value	Description
UNKNOWN	Not specified
HRA	German trade register department A
HRB	German trade register department B
PARTR	German partnership register
GENR	German cooperative society register
VERR	German register of associations
FN	Austrian commercial register
LUA	Luxembourg trade registry A
LUB	Luxembourg trade registry B
LUC	Luxembourg trade registry C
LUD	Luxembourg trade registry D
LUE	Luxembourg trade registry E
LUF	Luxembourg trade registry F
LUG	Luxembourg trade registry G

Currency codes

Supported ISO 4217 currency codes

Code	Name
EUR	Euros
USD	United States Dollar
GBP	United Kingdom Pound
CHF	Switzerland Franc
SEK	Sweden Krona
NOK	Norway Krone
CZK	Czech Republic Koruna
DKK	Denmark Krone
HRK	Croatian kuna
HUF	Hungarian forint
ISK	Icelandic króna
PLN	Polish złoty
RUB	Russian ruble
AUD	Australian dollar
BRL	Brazilian real
CAD	Canadian dollar
MXN	Mexican peso
ARS	Argentine peso
ILS	Israeli new shekel
INR	Indian rupee
JPY	Japanese yen
KRW	South Korean won
SGD	Singapore dollar
ZAR	South African rand
HKD	Hong Kong dollar
RON	Romanian leu
ALL	Albanian lek
MKD	Macedonian denar
MDL	Moldovan leu

Errors

Successful call

Code	Description
0...999	See documentation of request methods for more information. These codes are reserved for different uses

Technical or interface errors

Code	Description
1000	An unknown error occurred, please contact the lynck Support to find out details.
1001	The calculated MAC is invalid.
1002	The request is invalid. Please refer to the message for further explanation of the cause.

Status codes for rejected requests

Code	Description
2000	The payment method is not available. Please use another payment method.
2001	The payment has been rejected. Please use another payment method.
2002	Method call is not allowed in this state of transaction.
2003	The transaction is expired.
2004	The requested order number does not exists.
2005	Method call already in process for this transaction.
2006	No shop found with this shopID.
2007	Shop is not activated.
2008	Order ID already exist:
2010	The credit card is expired.
2011	The credit card number does not match the issuer.
2012	The credit card is already stored for this user.
2013	The bank account is already stored for this user.
2014	The user already exist.
2015	The user does not exist.
2016	Refund amount must not be greater than capture amount.
2017	Payment declined by fraud check. Please use another payment method.
2018	Refund failed.
2019	The provided captureID is unknown.
2020	Reduce/Refund failed partially.
2021	The MSA user already exists.
2022	The Shop already exists.
2023	Transaction is already finished.
2024	Invalid token,
2025	Merchant doesn't have the right to do this call.
2026	The provided paymentInstrumentID is unknown.
2027	No payment method available due to configuration.
2028	This order was already captured.
2029	This order was already captured with different Amount.
2030	Capture is not allowed in this state of transaction.
2031	"Payment Instrument is not a Bank Account." or "Payment Instrument is not a Credit Card."
2032	Merchant notification failed.
2033	The payment instrument is invalid.
2034	The payment instrument does not support SEPA direct debit.
2035	Bank account or routing number do not match.
2036	Non PCI compliant merchant is not allowed to send CVV.
2037	Capture rejected.
2038	Multiple captures not allowed.
2039	Issuer is not supported by the shop. Please try another one.
2040	The issuer of the credit card could not be detected. Please use another card.
2041	The credit card number is empty. Please enter a credit card number.
2042	The validity month of the credit card is empty. Please enter a validity month.
2043	The validity year of the credit card is empty. Please enter a validity year.
2044	The name of the credit card holder is empty. Please enter an account holder.
2045	Error in sending email.
2046	Invalid card number.
2047	No active dunning configuration for transaction.
2048	No plan found with this planReference.
2049	Transaction type not allowed.
2050	Subscription ID already exists.
2051	The provided subscription id is unknown.
2052	Method call is not allowed in this state of subscription.
2053	No changes were performed. Please provide at least one optional parameter.
2054	Refund not allowed.
2055	The payment has been rejected. Please use another payment method.
2056	The provided paymentInstrumentID incorrect.
2057	The credit card is expiring soon.
2058	Solvency checks are not configured.
2059	Add Payment Failed.
2060	An external payment provider is not available.
2062	Check is not configured.
2063	Non PCI compliant merchant is not allowed to register credit cards.

Additional status codes for notification callbacks

Code	Description
6001	parameter or format error
6002	unknown
6003	transaction or payment method not allowed
6004	system error, no response, time-out
6005	cancelled by user
6006	authentication failed
6007	expired, blocked, stolen, declined with no specific reason
6008	no JavaScript in user's browser
6009	overload, merchant busy, processing temporarily not possible
6010	invalid amount
6011	fraud
6012	communication error
6013	reservation outdated
6014	configuration error
6015	partial capture not allowed
6016	third party gateway returned an error or declined transaction, details will be in the error description
6017	no funds
6018	partial refund failed
6025	Invalid Amazon Pay payment method

Testdata

Amazon Pay:

Customer E-Mail	amazonmerchant+sandbox@crefopay.de
Password	test123

Apple Pay:

To test Apple Pay on the sandbox environment, a "Sandbox Tester Account" is required. Please review the following resource regarding Apple Pay Sandbox Testing: https://developer.apple.com/apple-pay/sandbox-testing/

Credit Card:

Owner	Any name
Card Number	4321123443211234
CVV	Any three digit number
Expiration Date	Any valid date in the future

Request	Amount	Result code	Description
Reserve (CC)	1.11 €	2060	Authorization error
Reserve (CC3D)	1.12 €	2060	Authorization error before redirection to 3D-secure check
Reserve (CC3D)	1.19 €	6012	Authorization error after redirection to 3D-secure check
Capture	1.13 €	2037	Capture rejected
Capture	1.22 €		Capture transitions to status PENDING before changing to status PAID
Capture	1.23 €		Capture transitions to status PENDING before changing to status FAILED
Capture	1.24 €		Capture transitions to status PENDING and remains in this status
Refund	1.14 €	2018	Refund failed
Refund	1.20 €		Refund transitions to status PENDING before changing to status DONE
Refund	1.21 €		Refund transitions to status PENDING before changing to status FAILED

Direct Debit:

Account owner	Any name
IBAN	DE06000000000023456789
BIC	SFRTDE20000

eps / giropay / iDEAL:

Bank name or BIC	Testbank
Account Number	Any
PIN	Any
TAN	1234

Google Pay:

Customer E-Mail	googlepay-test@lynck.de
Password	GoogleTest123!

To test Google Pay you may add test cards to your own Google account. Please review this resource regarding Google Pay testing: https://developers.google.com/pay/api/web/guides/resources/test-card-suite

Paypal:

Username	testing@crefopay.de
Password	#vaS7Rjt

Sofort:

Bankname	88888888
Bank Routing Number	88888888
PIN	8888

Zinia:

Please keep the payment method restrictions for Zinia Buy Now Pay Later and Zinia Splitpay in mind when testing.

To receive approval for your transaction in the Zinia sandbox environment, please use the following user data:

First name	Jan
Last name	ZINIA_AP

When you are prompted for a phone number by Zinia, provide any valid German phone number and confirm it with the one time password 9999.

Languages

Lynck support the following languages within the checkout process

Code	Name
EN	English
DE	German
ES	Spanish
FR	French
IT	Italian
NL	Dutch

Cookies

The Cookies that are set by different lynck products can be found in the table below:

Merchant Service Area

Name	Domain	Path	Expires	Description
JSESSIONID	service.crefopay.de	/	Session	ID to identify the user during the session
language	service.crefopay.de	/msa3	Session	Stores the language of the user
locale	service.crefopay.de	/msa3	Session	Stores the locale of the user

HostedPages

No Cookies are set

SecureFields

No Cookies are set
